Table 6.2. DIP Switch and LED Behavior
Switch Setting
DIP_SW[1] 0 (Down)
1 (Up)
DIP_SW[2:4] 001
011
111
Others
WARNING: Do not connect the board to your PC before you follow the driver installation procedure of this section.
Communication between the board and a PC, through the USB connection cable, requires installation of the FTDI chip
USB hardware drivers. Loading these drivers enables the computer to recognize and program the board. Drivers can be
loaded as part of the installation of Lattice Diamond design software or Diamond Programmer, or as a stand-alone
package.
© 2014-2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
14
LED Behavior
External 12.0 MHz (X1)
Internal 12.09 MHz (OSCH)
1 Hz Sweep
1 Hz Left-Right
1 Hz Blink
1 Hz Alternating
FPGA-EB-02036-1.4
