Table 6.1 describes the components on the board and the interfaces it supports.
Table 6.1. Starter Kit Components and Interfaces
Component/Interface
Circuits
USB Controller
USB Mini-B Socket
Components
LCMXO2, LCMXO3L, or
LCMXO3LF
Interfaces
LED Array
Push Button Switch
4-position DIP Switch
Four 2 x 20 Header
Landings
1 x 8 Header Landing
1 x 6 Header Landing
4 x 10 40-Hole Prototype
Area
Test Points

Run the Demonstration Design

Upon power-up, the pre-programmed demonstration design automatically loads and drives the LED array in a 1-hertz
pattern. The program shows a clock divider driven either by the MachXO2/MachXO3 internal oscillator or the external
FTDI clock chip. The divider modules (heartbeat.v and kitcar.v) are clocked at the default frequency of 12 MHz which
divides the clock to cycle the LED display approximately once per second. The resulting light pattern is determined by
the DIP Switch (SW2) setting as shown in
