Spectre 3.0 Integra Specifications

Water-cooling Integration
Ports
Pump
Electronics Integration
Cables
LED strips
Motherboard Form Factor
Expansion Slots
Case Form Factor
Package Dimensions &
Weight
Case Dimensions & Weight
Storage
Radiators
Maximum GPU Length
Maximum GPU Height
Revision 2.2
Spectre 3.0 Integra, Integra Umbra Limited Edition &
Integra Umbra Chrome Elite Limited Edition Assembly Manual
Reservoir, Pump Top, Pump Cover, Fill Port, Drain Port, Parts of water-cooling
loop.
6x G1/4" BSPP | 1x Fill Port | 1x Drain Port
Compatible with all D5 pumps (Not included)
Core Component Cable Connections: 24pin x1 | 8pin PCIe x6 | 8pin EPS x4
(As many inputs must be used as outputs).
Hubs: PWM: x6. ARGB: x10 (Single input for each).
LEDs: x20 Integrated ARGB 90-degree LEDs and x15 UV 90-degree LEDs facing
around the internal and external perimeter of the PowerBoard
There are two switches on the PowerBoard one switches the ARGB on or off and
the other switches the UV on or off.
Touch sensing Power Button.
Extra Power and Reset Buttons.
PowerBoard LED on/off switch. (Requires reboot for setting to take effect).
PowerBoard 2.5" SATA 3.0 6Gb/s Direct Mount x1.
PowerBoard Linking Cables Standard Set: 24pin x1| 8pin EPS x2| 8pin PCIe x3
18AWG Black Heatshrinkless Sleeve.
Linking cables and PSU Side Cables available here.
Adaptors for motherboards with 90-degree connectors available here.
PWM Female to Female 50cm Black Sleeved x1.
ARGB Female to Female 50cm Black Sleeved x1.
Integra: 2x 50cm ARGB LED Strips with 50cm cables.
Integra Umbra (all variants): 3x 50cm ARGB LED Strips with 50cm cables.
(1x 30cm LED strip pre-installed into PSU Side Shroud.)
Attach to case panels on specific mounting points for front and top panel glow.
XL-ATX (Up to: 285mm Wide & 343.5mm High) E-ATX, ATX, Mini-DTX, Mini-ITX.
8x
Mid Tower
640 mm(L) x 620 mm(W) x 110 mm(H)
(Flat-packed Case | Partial assembly required) | 17 Kg
545 mm(L) x 254 mm(W) x 595 mm(H) | 15 Kg
7x 2.5" Drive
x2 are on top of the PSU shroud and cannot be used when the GPUs are
vertically mounted.
x4 are inside of the PSU Shroud.
x1 is on the PowerBoard behind the PSU.
360mm x 60mm with x1 set of standard 25mm fans.
Or 360mm x 40mm with x2 sets of standard 25mm fans (Push/Pull).
500 mm
170 mm in standard orientation | Unlimited in vertical orientation
Page | 6
