Step 12: Install D5 Pump (Not included).

Pieces Involved
It is easier to do this when the Case or Distribution Plate is horizontal because then you can
sustain downward pressure on the pump while tightening the pump cover to prevent the O-ring
moving out of position.
Position the O-ring in the D5 Pump Top O-ring Groove, make sure that it is not twisted, kinked, or
damaged. Push the pump into the pump top and twist side to side until you feel the O-ring has
settled into the O-ring groove. Then tighten the pump cover firmly onto the pump. Position the
pump cables where you need to for the best cable routing.
Revision 2.2
Integra Umbra Chrome Elite Limited Edition Assembly Manual
• Spectre 3.0 Integra Case
• D5 Pump Cover
Spectre 3.0 Integra, Integra Umbra Limited Edition &
• D5 O-Ring
• D5 Pump (Not Included)
Page | 23
