EVAL-ADM8832

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty Reference Designator
1 U1
2 J1, J2
1 SK1
2 T1 to T2,
7 T4 to T10
6 C2 to C4, C8 to C9
5 C1, C5 to C7
1 R1
1 R2
1 R3
1 R4
1 R5
1 R6
1 R7

ORDERING GUIDE

Model
1
ADM8832-EVALZ
1
Z = RoHS Compliant Part.
Description
20-lead LFCSP socket (ADM8832 inside)
Power connector, 5 mm pitch
SMB connector
Test point
Test point
Capacitor, 1 μF, 50 V, 1206, X7R
Capacitor, 2.2 μF, 25 V, 1206, X7R
Resistor, 620 Ω, 0805 1%
Resistor, 1 kΩ, 0805 1%
Resistor, 24.9 kΩ, 0805 1%
Resistor, 150 kΩ, 0805 1%
Resistor, 1.5 MΩ, 0805 1%
Resistor, 100 kΩ,0805 1%
Resistor, 1 M Ω, 0805 1%
Description
Evaluation Board
Rev. 0 | Page 6 of 8
Manufacturer
Loranger
Weidmuller
Emerson
Vero
Vero
TDK
TDK
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo

ESD CAUTION

Part Number
03714-201-6217
1716120000
SMB 131-3701-266
20-313137
20-313137
C3216X7R1H105M
C3216X5R1E225K
RC0805FR-07620RL
RC0805FR-071KL
RC0805FR-0725KL
RC0805FR-07150L
RC0805FR-071M5L
RC0805FR-07100KL
RC0805FR-071ML
