6. Installation types
6.1 Installation on auto-coupling
Pumps for permanent installation can be mounted on a stationary
auto-coupling guide rail system or a hookup auto-coupling
system.
Auto-coupling guide rail system
Guide rail installation
Fig. 2
Hookup auto-coupling
Hookup auto-coupling installation
Fig. 3
6
6.2 Free-standing submerged installation
Pumps for free-standing submerged installation can stand freely
on the bottom of the pit or similar location.
Free-standing submerged installation
Fig. 4
