- Page 1 INSTRUCTION MANUAL AIR 38 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.0x25mm SCREW M3.5x40mm SCREW 16PCS+1spare PCS+1 spare M3.0x16mm SCREW 10PCS+1 spare 1PCS Che ing To Lock... - Page 4 PARTS Back panel Left panel Down Front panel Right panel Down Right panel Upper Left panel pper Tray...
- Page 5 PARTS Back panel of small house 4PCS Top panel of small house Side panels of small 2PCS 2PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the small house,attach the Part K,L & N by 8XP2 screws. Attach the top panel Part M by 4XP2 screws. - Page 7 PRODUCT ASSEMBLY ①Attach the back panel Part B, Left panel Part E and Part C (With "Aivituvin" logo by 4X P1 screws. ②NOTICE: Do not reverse the back panel and side panels Line up the same level Small Wooden Slat With "AIVITUVIN"...
- Page 8 PRODUCT ASSEMBLY ①Attach the right panel Part F and Part D by 4X P1 screws. NOTICE: Do not reverse the side panel Part F The wooden ② slat downward . Line up the same level...
- Page 9 PRODUCT ASSEMBLY Attach the 2PCS of right platforms Part I in the Right and Back corners by 6XP2 screws as show on the picture. Attach the 2PCS of left platforms Part O in the Left and Back corners by 6XP2 screws as show on the picture.
- Page 10 PRODUCT ASSEMBLY Connect 4PCS of Platform by 4PCS Ramp Part J. Attach the Front panel Part A by 8XP1 screws.
- Page 11 PRODUCT ASSEMBLY ① Attach the top cover panel Part G to the house by 4XP3 screws.
- Page 12 PRODUCT ASSEMBLY Slide in the tray part H...
- Page 13 PRODUCT ASSEMBLY Attach the tray to the hutch with the lock P7 by 6 X P3screws.
- Page 14 PRODUCT ASSEMBLY Screw the eye hook P4 to the left panel,tie the rope on one side of roof, the other side of hook to make the roof open.
- Page 15 PRODUCT ASSEMBLY ① Put the small house above the tray. ② Put the chewing toy P5 and bowl P6 into the cage anywhere you want. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or lo ss,whe ther direct ,indir ect,or incid ental ,resul ting f rom th e inc orrect attachment,improper use,inadequate miantenance,or neglect of this product.
