- Page 1 INSTRUCTION MANUAL AIR 18 AIR 800 AIR 34 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x25mm SCREW M3.5x40mm SCREW 16PCS+1 spare 18PCS+1 spare M3.0x10mm SCREW M3.0x16mm SCREW 2PCS+1 spare 22PCS+1 spare Latch 1 PC 2PCS Chewing Toy for gift 1 PC... - Page 5 PARTS Back Panel - Upper Front Panel - Down Front Panel - Upper Back Panel - Down Left Panel Right Panel The Middle Tray Wood Layer- Up & Down Ramp Supporting Layer 2PCS...
- Page 6 PARTS The Bottom Tray Divider T op Cover Panel Ramp - Upper Ramp - Down Casters without brake 1 PC 2PCS Brake Casters Tray Supporting bar Folding Metal feeder 2PCS 2PCS...
- Page 7 PARTS Bottom Wire Netting...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Attach the back first, screw back panel Part D with right panel Part F, left panel Part E by 2xP1 screws each side. ① Attach Part C by 2XP1 screws each side. ② Then screw the divider Part K to Part C by 1xP1 screw. - Page 9 PRODUCT ASSEMBLY ① Attach the front panel Part B to the sides by 4xP1 screws. Put inside the bottom wire netting Part S to be UPWARDS ② to seperate the urine & poop. ③ Put Part H inside the cage as show on picture. ① Put the tray supporting bars 2 part Q into the side groove.
- Page 10 PRODUCT ASSEMBLY Slide in the middle tray Part G and the bottom tray Part L. Screw the down ramp Part N to the tray surpporting bar Part Q as show on picture by 4xP3 screws.
- Page 11 PRODUCT ASSEMBLY Put the ramp supporting layer Part I and another wood layer Part H inside the cage as show on picture. ① Screw the upper ramp Part M to the layer by 4xP3 screws. ② Screw the metal feeder Part R to the right panel Part F by 2xP4 screws.
- Page 12 PRODUCT ASSEMBLY Attach top cover panel Part J to the hutch by 6xP3 screws. Screw the hook P5 to the Part E, tie the rope on one side of roof and the other side of hook to make the roof open.
- Page 13 PRODUCT ASSEMBLY ① Screw 1pc of latch P6 to the left panel Part E by 4xP3 screws. ② Screw 1pc of latch P6 to connect the top cover and front panel by 4XP3 screws. Screw two casters without brake Part O to the front of hutch legs by P2x4 each.
- Page 14 PRODUCT ASSEMBLY Screw two brake casters Part P to the back of hutch legs by P2x4 each. P x2...
-
Page 15: Help Center
Once the items are received, opened, and deemed to be faulty or other problems. Pls contact us at service@aivituvin.com for the solution. We will feedback to you within 24 hours. If you are happy with the shopping ,welcome to share photos and thoughts with others . - Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
