- Page 1 INSTRUCTION MANUAL AIR 57 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
- Page 3 TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M3.5x50mm SCREW 16PCS+1 spare 2PCS+1 spare M3.5x25mm SCREW M3.0x12mm SCREW 28PCS+1 spare 30PCS+1spare Latch Bowl 4PCS Chewing Toy...
- Page 4 PARTS Front Panel of Small House Side Panel of Small House Back Panel of Small House Roof of Small House 2PCS Front Panel- Down Left Side Panel Back Panel- Down Right Side Panel Front Panel- Upper Back Casters with brake Back Panel- Upper Side Panel 2PCS...
- Page 5 PARTS Front Casters without brake Bottom Floor Layer Tray 2PCS Bottom Ramp Middle Floor Divider Panel Middle Ramp 1PCS Roof 2PCS...
- Page 6 PRODUCT ASSEMBLY Attach the small house,attach part A,B,C,D by 12XP3 screws. Attach the part E,F,G,H by 8XP2 screws.
- Page 7 PRODUCT ASSEMBLY Attach the part J,K,I by 8XP2 screws. ① Attach the upper and down parts by 2XP1 screws. Screw the casters with brake part L in back by 8XP3 screws. ② Screw the casters without brake part M in front by 8XP3 screws. ③ ...
- Page 8 PRODUCT ASSEMBLY Slide in the bottom floor part N. Slide in the tray part O. ① Put the part P inside the cage as show on the picture. ② Hang on the ramp part Q to part P as show on the picture. ③ ...
- Page 9 PRODUCT ASSEMBLY Put the part R inside the cage as show on the picture. ① Screw the ramp part T to the part R by 2XP4 screws as show on the ② picture. Put the part S inside the cage as show on the picture. ③ ...
- Page 10 PRODUCT ASSEMBLY Put the small house,P7,P6 inside the cage anywhere you want. Attach the roof part U by 12XP4 screws...
- Page 11 PRODUCT ASSEMBLY Screw the latch 4XP5 to the roof and tray by 16XP4 screws.(Pls pay attention the position of latch) Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
