- Page 1 INSTRUCTION MANUAL AIR 10 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm BOLT M3.5x50mm SCREW 4PCS+1spare 18PCS+1spare M3.5x25mm SCREW M3.0x16mm SCREW 14PCS+1spare 16PCS+1spare M3.0x10mm SCREW 2PCS+1spare... - Page 5 PARTS Right panel of hutch Front panel of hutch Back panel of hutch Front panel of pen Left side panel of pen Back panel of pen Upper tray Bottom wire netting Divider panel 2PCS...
- Page 6 PARTS Hutch roof Lower tray Pen roof - UV proof Ramp Folding metal feeder Small ramp outside the hutch Brake casters Casters without brake PVC curtain 2PCS 2PCS...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Attach Part A, Part B and Part C by 6pcs of P2 screws. Attach Part G to Part A and Part B by 4pcs of P2 screws. - Page 8 PRODUCT ASSEMBLY Attach the pen Part D, Part E, Part F by 4pcs of P2 screws. Attach the pen to hutch by 2pcs of P1 screws.
- Page 9 PRODUCT ASSEMBLY Repeat on the other side. Slide in the tray Part J.
- Page 10 PRODUCT ASSEMBLY ① Put in 2pcs of Part H to be UPWARDS direction to seperate the urine & poop. ② Then slide in the tray Part I. ① Screw the feeder to Part C by 2pcs of P5 screws. ② Then put in the rabbit chewing toy P6.
- Page 11 PRODUCT ASSEMBLY ① Screw the ramp Part M to the bar on the Part G by 4pcs of P4 screws. ② Screw 2pcs of eye hook P8 on the front door of pen. (The are pre-drilled holes to screw in) Then hang with the front ramp.{Use only when needed} Screw the roof hinge to the back by 3pcs of P4 screws on each side.
- Page 12 PRODUCT ASSEMBLY Screw the roof hinge P7, one side to the roof by P4x2 the other side to the right panel by P4x2. ① Attach the pen roof Part K by 4pcs of P2 screws. ② Stick PVC curtain "P" to the hutch door.
- Page 13 PRODUCT ASSEMBLY Screw two casters without brake Part Q to the front of hutch legs by P3x8. Screw two brake casters Part R to the back of hutch legs by P3x8. LOCKED OPEN...
-
Page 14: Help Center
Once the items are received, opened, and deemed to be faulty or other problems. Pls contact us at service@aivituvin.com for the solution. We will feedback to you within 24 hours. If you are happy with the shopping ,welcome to share photos and thoughts with others . - Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
