- Page 1 INSTRUCTION MANUAL AIR 25 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M6.0x30mm BOLT M6.0x45mm BOLT 8PCS 4PCS M3.0x28mm SCREW M3.0x20mm SCREW 12PCS+1 spare 1PCS+1spare M3.0x14mm SCREW M3.0x10mm SCREW 4PCS+1 spare 4PCS+1spare Spanner... - Page 4 PARTS Front Panel of Small Top of Small House Back Panel of Small Side Panel of Small House House House 2PCS Left Panel Right Panel Back Panel Front Panel Tray Bottom Layer Caster Caster with brake 2PCS 2PCS...
- Page 5 PARTS Shelf PVC Layer Ramp Middle Layer Upper Layer Ramp PVC Layer Roof Support...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the small house,attach the Part A,B,C&D by 12XP3 screws. Attach the Part E,F,G,H by 8XP2 screws. - Page 7 PRODUCT ASSEMBLY ① Screw the caster 2x Part I on the front legs. ② Screw the caster with brake 2x Part J on the back legs. Put in the bottom layer Part K.
- Page 8 PRODUCT ASSEMBLY Put in the tray Part L above the bottom layer. Attach the Shelf Part M by 4XP1 screws.
- Page 9 PRODUCT ASSEMBLY Put in the middle layer Part N. ① Attach the ramp Part P to middle layer by 2XP6 screws. ② Put in the pvc layer Part O above the middle layer.
- Page 10 PRODUCT ASSEMBLY Put in the upper layer Part Q. Attach the ramp part S to the upper layer by 2XP6 screws. ① ② Put in the pvc layer Part R above the upper layer.
- Page 11 PRODUCT ASSEMBLY Screw the roof Part T by 4XP5 screws. Put in the small house inside the hutch anywhere you want. ① Screw the support part U to the left panel by 1XP4 screw. ② Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
