Vehicle connections

The connection information listed below is specific to the 2019 Nissan Qashqai (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan HS CAN Low 1
H1/3 Tan/Black HS CAN High 1
H1/4 Tan/Black (Data) HS CAN High
H1/5 Orange/Brown No Connection
H1/6 Orange/Brown HS CAN Low 2
H1/7 Orange/Green HS CAN High 2
H1/8 Orange/Green No Connection
H1/9 Lt. Green No Connection
H1/10 Lt. Green No Connection
H1/11 Violet/Brown No Connection
H1/12 Violet/Brown No Connection
H1/13 Orange/Black (-) Arm Output
H1/14 Orange/Black No Connection
H1/15 Yellow/Black No Connection
H1/16 Yellow/Black (-) Lock Output
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) PTS Output
H2/2 Lt. Green/Black (-) Factory Alarm Arm (FAA) Output
H2/3 Blue/White (-) Ground When Running (Status) Output
H2/4 Blue/White (-) Accessory 2 Output
H2/5 Dk. Green/Black (-) Lock Output
H2/6 Dk. Green/Black (-) Lock Output
H2/7 Red/White (-) Trunk Output
H2/8 Red/White (-) Trunk Release Output
H2/9 Brown/Black (-) Accessory Output
H2/10 Brown/Black (-) Horn Output
8 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
BCM under driver dash, green 40 pin plug, pin 40
BCM under driver dash, green 40 pin plug, pin 40
Not Applicable
BCM under driver dash, green 40 pin plug, pin 40
BCM under driver dash, green 40 pin plug, pin 20
BCM under driver dash, green 40 pin plug, pin 20
BCM under driver dash, green 40 pin plug, pin 20
Not Applicable
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
BCM under driver dash, black 40 pin plug, pin 12
No Connection
No Connection
BCM under driver dash, gray 40 pin plug, pin 10
Connects To
Wire Location
BCM under driver dash, black 40 pin plug, pin 9
No Connection
No Connection
BCM under driver dash, gray 40 pin plug, pin 25
No Connection
No Connection
No Connection
No Connection
BCM under driver dash, gray 40 pin plug, pin 28
No Connection
(+/-) Wire Color Connection
Data Lavender/Pink Mandatory
Data Lavender/Pink
Data Lavender/Pink Mandatory
Data Lavender/Blue Mandatory
Data Lavender/Blue Mandatory
Data Lavender/Blue
- Brown (key lock) Mandatory
- Gray Mandatory
(+/-) Wire Color Connection
- Red Remote Start
Only
- Lavender/Pink Remote Start
Only
- Lavender/Blue Remote Start
Only
