Directed DS3+ Installation Manual page 10

Module
Conn./Pin Color Description
H2/44 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. No Connection
H3/2 Blue/White Relay 1 N.C. – No Connection
H3/3 Blue/Red Relay 1 N.O. – No Connection
H3/4 Blue/Red Relay N.O. No Connection
H3/5 Blue Relay COM No Connection
H3/6 Blue Relay 1 COM – No Connection
H3/7 White/Brown Relay 3 N.C. – No Connection
H3/8 White/Brown Relay N.C. No Connection
H3/9 White Relay COM. (-) Hazards Output
H3/10 White Relay 3 COM – No Connection
H3/11 Red (+) 12 Volt (Battery)
H3/12 Red (+) 12 Volt Input
H3/13 Lt. Green/Red Relay N.O. No Connection
H3/14 Lt. Green/Red Relay 2 N.O. – No Connection
H3/15 Lt. Green Relay 2 COM – No Connection
H3/16 Lt. Green Relay COM No Connection
H3/17 Lt. Green/White Relay N.C. No Connection
H3/18 Lt. Green/White Relay 2 N.C. – No Connection
H3/19 Black (-) Ground
H3/20 Black (-) Ground
H3/21 White Relay COM. (-) Hazards Output
H3/22 White Relay 3 COM – No Connection
H3/23 Red (+) 12 Volt (Battery)
H3/24 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 N/A No Connection
10 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
BCM under driver dash, gray 40 pin plug, pin 11
No Connection
Dash Fuse Box, rear, white 1 pin plug, pin 1
Dash Fuse Box, rear, white 1 pin plug, pin 1
Dash Fuse Box, rear, white 1 pin plug, pin 1
Not Applicable
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Not Applicable
BCM under driver dash, gray 40 pin plug, pin 11
No Connection
Dash Fuse Box, rear, white 1 pin plug, pin 1
Dash Fuse Box, rear, white 1 pin plug, pin 1
Dash Fuse Box, rear, white 1 pin plug, pin 1
Not Applicable
Connects To
Wire Location
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
- Lavender/Yellow Mandatory
+ Blue (30A) Mandatory
+ Blue (30A) Mandatory
+ Blue (30A)
(chassis ground) Mandatory
(chassis ground) Mandatory
(chassis ground)
- Lavender/Yellow Mandatory
+ Blue (30A) Mandatory
+ Blue (30A) Mandatory
+ Blue (30A)
(+/-) Wire Color Connection
