Directed DS3+ Installation Manual page 9

Module
Conn./Pin Color Description
H2/11 Brown/White N/A
H2/12 Brown/White (-) Ignition Output
H2/13 White (+) AUX 1 Output
H2/14 White (+) AUX 1 Output
H2/15 Violet/Black (+) AUX 4 Output
H2/16 Violet/Black (+) Starter Disable Output [4]
H2/17 Dk. Blue/Black (-) Disarm Output
H2/18 Dk. Blue/Black (-) Unlock Output
H2/19 Lt. Blue/Black (-) Factory Alarm Disarm (FAD) Output
H2/20 Lt. Blue/Black (-) Starter Output
H2/21 Brown/Red (+) Siren Output [2]
H2/22 Brown/Red (+) Siren Output
H2/23 Pink (+) Ignition Sense Input
H2/24 Pink (+) Ignition Sense Input
H2/25 Violet (+) Door Trigger Input
H2/26 Violet (+) Door Input
H2/27 Brown (+) Brake Input
H2/28 Brown (+) Brake Input
H2/29 White/Blue (-) Activation Input
H2/30 White/Blue (-) Activation Input
H2/31 Red/Blue (-) Trigger Input
H2/32 Red/Blue No Connection
H2/33 Black/White (-) E-Brake Input
H2/34 Black/White (-) E-Brake Input (manual transmission)
H2/35 Orange/Black (+) Valet Switch Input
H2/36 Orange/Black (+) Instant Alarm Input
H2/37 Blue (-) Trunk Trigger Input
H2/38 Blue (-) Trunk Input
H2/39 Green (-) Door Input
H2/40 Green (-) Door Trigger Input
H2/41 Gray (-) Hood Switch Input [1]
H2/42 Gray (-) Hood Input
H2/43 Violet/White (AC) Tach Input
9 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
BCM under driver dash, gray 40 pin plug, pin 27
No Connection
No Connection
No Connection
Starter:
BCM under driver dash, black 24 pin plug, pin 19
Ignition:
BCM under driver dash, gray 40 pin plug, pin 27
Must use a relay.
Must use a 1N4002 diode or larger.
BCM under driver dash, black 40 pin plug, pin 13
No Connection
No Connection
BCM under driver dash, black 24 pin plug, pin 19
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
- Lavender/Lt. Green Remote Start
Only
- Blue Security Only
- Lavender/Lt. Green
Doubl Pink (key unlock) Mandatory
e -
- Blue Remote Start
Only
Security Only
Mandatory
Mandatory
