Directed DS3+ Installation Manual page 11

Module
Conn./Pin Color Description
H4/3 Red/Black (+) 12 Volt Input (Accessory/Starter)
H4/4 Red/Black (+) 12 Volt Input
H4/5 Pink/Black Flex Relay (pin 87a)
H4/6 Pink/Black Relay N.C. – No Connection
H4/7 Pink/White Relay COM – Flex
H4/8 Pink/White (+) Flex Relay Output
H4/9 Red (+) 12 Volt Input
H4/10 Red (+) 12 Volt Input (Ignition)
H4/11 Green Relay COM – (+) Starter
H4/12 Green Starter Input (conn. side)
H4/13 Violet (+) Starter Output (vehicle side)
H4/14 Violet Relay N.C. – (+) Starter
H4/15 Orange Relay COM – (+) Accessory
H4/16 Orange (+) Accessory Output
H4/17 Red/White (+) 12 Volt Input
H4/18 Red/White (+) 12 Volt Input (Flex)
H4/19 Pink Relay COM – (+) Ignition
H4/20 Pink (+) Ignition Input/Output
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
H5/3
H5/4
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
H6/5
H6/6
H6/7
H6/8
11 933.NISS06 3.23.195.3 2019 Nissan Qashqai (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Color
N/A
N/A
N/A
N/A
Color
Blue
Blue
Black
Black
Green
Green
Red
Red
(+/-) Wire Color
Description
RF Loop
RF Loop
RF Loop
RF Loop
Description
(Data) TX
(Data) TX
(-) Ground
(-) Ground
(Data) RX
(Data) RX
(+) 12 Volt
(+) 12 Volt
Connection
