08 - PB Sport - Connecting an Input module
The PerformanceBox Sport can connect to any one of the following Racelogic input modules and then include the data
from each channel in the logged VBO file. The PerformanceBox Sport will automatically log all channels from a
connected Input Module providing that the module is connected before the power is switched on.
Description
8 Channel Thermocouple Interface
8 Channel (10bit) Analogue
Interface
8 Channel (16bit) Analogue
Interface
4 Channel Frequency and Pulse
Counter Input Module
Mini Input Module
Yaw Rate Sensor + 2-Axis G
Sensor
Inertial Measurement Unit
Configuring the Input Modules
To configure an input module you must connect the module directly to the computer via a serial cable, you cannot setup
the channels via the USB port on the PerformanceBox Sport. The software which is required is the Stand Alone Module
Setup software which is included in the PerformanceBox Sport installation. The module can take power from the
PerformanceBox Sport both during operation and during configuration.
Once the module is powered and connected to the computer, run the Stand Alone Module Setup software. Under
'Options' select the appropriate COM port, then click 'Read Module Setup'.
https://en.racelogic.support//Product_Info/Legacy_Products/PerformanceBox_Sport/PB_Sport_-_User_manual/08_-_PB_Sport_-
Part Number
RLVBTC8
RLVBADC02
RLVBADC03
RLVBFIM03
RLVBMIM01
RLVBYAW03
RLVBIMU04
Connection Cable
RLCAB063
RLCAB063
RLCAB063
RLCAB063
RLCAB063
RLCAB065
RLCAB065
