02 - PB Sport - Power & LEDs
Connecting Power
The PB Sport can be powered from two different types of power source, via the 2way PWR input socket.
1. Vehicle power outlet socket (via a supplied cigar lighter power cable RLCAB060)
2. Battery power, (Racelogic 2Ah Battery pack RLACS110)
You must connect the GPS antenna before connecting power to the VBOX Micro. This is necessary because on
power-up the VBOX Micro will look for a connected GPS antenna and automatically adjust its gain for optimum
performance.
See
technical specification
LED Indicators
There are three LED indicators on the top panel of the PB Sport: SATS, COMS and LOG.
https://en.racelogic.support//Product_Info/Legacy_Products/PerformanceBox_Sport/PB_Sport_-_User_manual/02_-_PB_Sport_-
page for voltage input range.
_Power_%26_LEDs
4
