E T C I n s t a l l a t i o n G u i d e
Aero Relay Controller
It is recommended that stations and sensors be placed with in 50 feet (15m) of
the UAR controller for optimal performance.
Material
Line of sight
Line of sight
Plasterboard
Brick
Concrete
FerroConcrete
Ceiling
Material
Wood/Plaster/Glass
Brick/MDF
Metal
I n s t a l l a t i o n
The UAR is mounted directly to an electrical junction box or panel at the
electrical lighting load or before the load in the circuit.
N o t e :
W A R N I N G :
W A R N I N G :
Step 1: Locate the circuit breaker panel and turn off the power to the circuit.
Rel ay Co nt r ol le r I ns ta ll at i on Gu id e

Typical Radio Range

Range - typical
100 feet (30m) corridors
330 feet (100m) open halls
100 feet (30m) through 5 walls
65 feet (20m) through 3 walls
65 feet (20m) through 3 walls
33 feet (10m)
1 ceiling

Signal Loss

Attenuation
0-10%
5-35%
90-100%
If the circuit will have an additional hard wired switch, wire the
UAR in series before the switch.
Risk of electric shock! The UAR utilizes high voltage and
should only be installed by a qualified installer or
electrician. Follow all local codes for installation. Before
terminating the AC power wiring verify the main breaker
is in the off position and follow the proper lockout/tag out
procedures per NFPA Standard 70E.
For indoor use only! Must install in an electrical junction
box or wire way.
