E T C I n s t a l l a t i o n G u i d e
Aero Relay Controller
P o w e r U p a n d Te s t
For detailed programming and configuration information, please reference the
Unison Aero 902 MHz User Programming Guide. ETC documentation is
available for free download at www.etcconnect.com.
Step 1: Restore power to the circuit.
Step 2: Test the circuit by linking a Aero Switch Station.
a:
b:
c:
Step 3: Test the controller response.
a:
b:
N o t e :
Contains FCC ID: SZV-TCM320U
The enclosed device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(I.) this device may not cause harmful interference and
(ii.) this device must accept any interference received,
including interference that may cause undesired operation.
Contains IC: 5713A-TCM320U
Rel ay Co nt r ol le r I ns ta ll at i on Gu id e
Within radio range of the controller, press the toggle switch up (On) three
times consecutively.
Press the toggle switch down (Off) three times consecutively.
Press the toggle switch up again, three times consecutively.
Press the toggle switch "Off" once. The controlled lighting should respond
by turning off.
Press the toggle switch "On" once. The controlled lighting should respond
by turning on.
The linking method described in "Step 2" will learn the Aero
Switch to any controllers that are within radio range that do not
already have stations linked to them.
Pa ge 4 o f 4
