GB
Figure 11 Rescue seat/rescue loop class B
(3) Connect a second carabiner according to EN 362:2004 (for example of a rescue system according to EN
341:2011 class D) to the webbing loop in the front pouch of the belt.
(4) Connect the end loop of the lanyard to one D-ring like described in part "Preparing the alpha- BELT System for
Use".
– Lead the lanyard behind the legs to connect the carabiner with the opposite D-ring.
(5) Grab the middle loop of the lanyard between the legs from the front side and pull the lanyard upwards to the front
pouch area.
Figure 12 Connecting the red color stitched loop
(6) Connect the red color stitched loop with the second carabiner which is also connected with the front webbing loop
to form the rescue loop.
– To avoid injuries do not twist the lanyard.
3 Use
18
