GB
Figure 2 alphaBELT Lanyard
1 Carabiner in D-RIng
2 Length adjustment buckle 5 Label with markings
3 Main strap
2.2
Connecting Points for Breathing Apparatus
The back-plate of the breathing apparatus must only be connected to the belt system at the two points provided for that
purpose and only with the connecting buckles delivered with the belts. Only the following self-contained breathing
apparatus may be attached:
• AirMaXX
• AirGo
• M1
For correct use observe the operating manual of the respective breathing apparatus. Any configuration of above
breathing apparatus can be used if there is no other fall arrest harness connected to the back plate in parallel.
4 Middle loop for rescue loop seat (EN 1498 class B) (with red stitching)
6 End loop
2 Description
8
