MSA alphaBELT Pro Operating Manual page 15

GB 3 Use
Mounting Additional Tools on the Belt
WARNING!
The small connector strap loop must only be used with objects that are tested for SCBA usage, which are not heavier
than 1 kg and will not influence the ergonomic attributes of the harness. We are warningly emphasizing to follow the
restriction of the EN 137:2006 (for example no aluminum parts). Thus means also the overall weight of the SCBA
needs to be chosen according to the EN 137:2006.
Failure to follow this warning can result in serious personal injury or death.
Figure 7 Additional tools on the belts
(1) Install the small connector strap loop on the main strap of the belts around or beside the D-ring.
– Both ends of the small connector strap must be on top and the loop of the small connector strap must hang
behind the D-Ring.
Figure 8 Using the lanyard
Restraint lanyard to EN 358:2018 Positioning lanyard to EN 358:2018 Restraint lanyard to EN 358:2018
Anchorage connector to EN 795:2012 type B
(1) Prepare the belt like described in point manual in the point "Preparing the Belt System for Use".
(2) Pull the lanyard completely out of the back pouch of the belt.
(3) Close the loop with the carabiner to use the lanyard as a supporting rope.
(4) Connect the carabiner with one of the D-rings on the belt after pulling the lanyard around a chosen attachment
point.
(5) Adapt the length by using the length adjustment buckle to assure safe working.
(6) Chose the working position accurately to avoid any risks to fall.
15
