Single Monitor and Tablet Desk Mount
Instruction Manual
SKU: STAND-V102M
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v102m
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-V102M
Summary of Contents for Vivo STAND-V102M
- Page 1 Single Monitor and Tablet Desk Mount Instruction Manual SKU: STAND-V102M Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v102m GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Loosen the knob on Clamp (B). STEP 2 OPTION A: Clamp Installation OPTION B: Grommet Base Installation Assemble Clamp (B) to Pole (A) using M6x16mm Remove the screw from Clamp (B) using a Phillips Screws (S-D) and 3mm Allen Wrench (T-A). screwdriver, and set aside Clamp Bolt (B2). - Page 4 STEP 3 Slide the first Arm (C) onto Pole (A) and tighten the screw on the back using 6mm Allen Wrench (T-C). STEP 4 Slide the second Arm (C) onto Pole (A) and tighten the screw on the back using 6mm Allen Wrench (T-C).
- Page 5 STEP 6 Attach VESA Plate (D) to the back of the monitor using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B) and Spacers (M-C). STEP 7 With the adjustment screw holes on top, assemble Tablet Mount (E) to VESA Plate (D) using M4x16mm Thumbscrews (S-A) and M4 Washers (S-B).
- Page 6 STEP 8 To adjust Tablet Mount (E) to fit the device, push device down onto springloaded tabs and position device against the face of the adapter. With the adjustment screws still loose, center the device on the adapter. Then tighten the adustment screws. Adjustment Device Screws...
- Page 7 STEP 11 Adjust the tilt using 5mm Allen Wrench (T-B).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
