Dual Monitor Desk Stand with Riser
Instruction Manual
SKU: STAND-V102SF
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v102sf
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V102SF
Summary of Contents for Vivo STAND-V102SF
- Page 1 Dual Monitor Desk Stand with Riser Instruction Manual SKU: STAND-V102SF Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v102sf GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 15.4lbs Failure to do so may result in serious injury. (6.99kg) PER SCREEN Phillips Screwdriver ASSEMBLY STEPS STEP 1 Install legs (F) to underside of platform (E) using M6x14 bolts (N). STEP 2 Slide base cover (H) up onto pole (A). - Page 4 STEP 3 Attach pole assembly to platform assembly using M8x45 bolt (I) and support plate (J), and tighten with 6mm Allen key (P) while making sure base is straight on platform. The cell phone support lip on the base cover should be facing towards the front. STEP 4 Slide arm (B) down onto pole to desired height and tighten with 6mm Allen key (N).
- Page 5 STEP 5 Remove screw from end of each arm. Slide VESA brackets (D) onto arms, then reinstall screws. STEP 6 OPTION A: Flat Back Monitor Attach VESA plates (B) to the monitors using bolts (M-A, M-C) with D5 washers (M-E). M- E M- A M- C...
- Page 6 STEP 7 Slide VESA plates with monitors onto heads of VESA brackets. Secure using the knobs (K) with M3x8 bolts (L). Slide monitors together to eliminate center gap and tighten VESA brackets to arms using 4mm Allen key (O). Note : When attaching the NOTE: When attaching the monitor monito r screens , pleas e hol d screens, please hold the other end...
- Page 7 STEP 9 Use cable clip on pole to organize cables. Store Allen keys in cable clip when not in use. STEP 10 Adjust monitor to desired viewing angle. Turn knobs (K) using 6mm Allen wrench (P) to adjust monitor level if needed. Smartphone may be placed in holder on base cover. ±20°...
