Pneumatic Arm Dual Monitor Desk Mount with
Docking Station
Instruction Manual
SKU: STAND-V102G2D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v102G2D
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V102G2D
Summary of Contents for Vivo STAND-V102G2D
- Page 1 Pneumatic Arm Dual Monitor Desk Mount with Docking Station Instruction Manual SKU: STAND-V102G2D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v102G2D GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 2.2-33lbs Failure to do so may result in serious injury. (1-15kg) PER ARM Phillips Screwdriver ASSEMBLY STEPS STEP 1 (Option A) Clamp Installation Attach Clamp Brace (I) to Base (A) using M6x12mm Screws (S-A) and tighten with 4mm Allen Wrench (T-B).
- Page 4 STEP 1 (Option B) Grommet Base Installation Attach Grommet Plate (F) to Base (A) using M6x12mm Screws (S-A) and tighten with 4mm Allen Wrench (T-B). Apply Soft Pad (G) to underside of of the base assembly. Use Clamp Plate (E) to mark drilling locations and drill 3/8” (10mm) holes through the desk for installation.
- Page 5 STEP 2 Loosen the set screws on the bottom of Lower Arms (B) using 3mm Allen Wrench (T-A). Attach Lower Arms (B) to Base (A). For 180° rotation, retighten both set screws. For 360° rotation, retighten the bottom set screw only. STEP 3 Loosen the set screw on the top of Lower Arm (B) using 3mm Allen Wrench (T-A).
- Page 6 STEP 4 Assemble VESA Plates (D) to the back of the monitors using Screws (M-A, M-B) and M5 Washers (M-C). Tighten with a Phillips screwdriver. STEP 5 Pull back and hold the release levers on Gas Spring Arms (C), then slide the monitors with VESA Plates (D) onto the arms.
- Page 7 STEP 7 Remove the cable covers on Gas Spring Arms (C) using a Phillips screwdriver. Slide the cable covers on Lower Arms (B) forward to remove. Route cables through the arms and Cover (H), then reattach the cable covers. STEP 8 Adjust the tilt using 6mm Allen Wrench (T-C).
- Page 8 AVG. RESPONSE TIME help@vivo-us.com (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
