Dual Monitor Desk Stand
Instruction Manual
SKU: STAND-V102Z
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v102z
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V102Z
Summary of Contents for Vivo STAND-V102Z
- Page 1 Dual Monitor Desk Stand Instruction Manual SKU: STAND-V102Z Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v102z GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6lbs Failure to do so may result in serious injury. (8 kg) PER MONITOR Phillips Screwdriver ASSEMBLY STEPS STEP 1 Press the base cover (B) onto the base (A). Assemble the pole (D) to the base using M6x14 bolts (E) and tighten with the 4mm Allen wrench (F). - Page 4 STEP 2 Slide the monitor arm (C) onto the pole to the desired height, and tighten the center bracket to the pole using the 6mm Allen wrench (G). STEP 3 Attach two bolts (M-A or M-B) and washers (M-C) to the top mounting holes of each monitor, making sure to leave 3mm of thread exposed.
- Page 5 STEP 4 Align bolts (M-A, M-B) in VESA plates. Secure using two more bolts (M-A or M-B) and washers (M-C) in the bottom two holes of each monitor. Tighten all bolts using a Phillips screwdriver.
- Page 6 STEP 5 Tighten or loosen the tilt joints using the 6mm Allen wrench (G). Store tools in the cable clip. STEP 6 CAUTION: To prevent tipping, please be careful not to extend the arms too far forward or backward.
- Page 7 Adjust as Desired Adjust monitor position and rotation as desired. Manage cables using the clips on the arms and pole.
