Chapter 9 — Advanced Features

9.1 Specifying Complex Bar Codes

Complex two-dimensional bar codes or dot codes, for example PDF417,
MaxiCode, or LEB, require many specifying parameters. Therefore, there
is a complex instruction that allows all bar code parameters to be speci-
fi ed within a single instruction. This instruction can also be used for
one-dimensional bar codes, see Chapter 4.4.
BARSET[#<start parameter>,]["<bar code name>"[,<ratio wide bars> [,<ratio narrow
bars>[,<magnifi cation>[,<height>[,<security level> [,<aspect ratio height>[,<aspect
ratio width>[,<no. of rows>[,<no. of columns> [,<truncate fl ag>]]]]]]]]]]]
<start parameter>
<bar code name>
<ratio wide bars>
<ratio narrow bars>
<magnifi cation>
<height>
<security level>
<aspect ratio height>
<aspect ratio width>
<no. of rows>
<no. of columns>
<truncate fl ag>
88 Intermec Direct Protocol v7.80 Programmer's Reference Manual
limits size of syntax by specifying the fi rst parameter
(default 1)
specifi es the type of bar code
(default "INT2OF5")
specifi es ratio wide/narrow bars
(default 3)
specifi es ratio wide/narrow bars
(default 1)
specifi es magnifi cation
(default 2)
specifi es height of bars in dots
(default 100)
is only used in some complex codes
(default 2)
is only used in some complex codes
(default 1)
is only used in some complex codes
(default 2)
is only used in some complex codes
(default 0)
is only used in some complex codes
(default 0)
is only used in some complex codes
(default 0)
