Adjusting the foot plate angle
See the section "Segmented leg supports".
Adjusting the posterior lower leg pad
1) Height adjustment: Loosen the Allen head screws on the clamp brackets (see fig. 40, item 1). Slide the pos
terior lower leg pad to the desired height and firmly re-tighten the Allen head screws.
2) Depth adjustment: Loosen and remove the Allen head screw on the posterior lower leg pad (see fig. 41,
item 1). Move the posterior lower leg pad to one of the four possible positions (see fig. 41, item 2) and firmly
re-tighten the Allen head screw.
3) Angle adjustment: Loosen the Allen head screw on the posterior lower leg pad (see fig. 42, item 1). Set the
desired angle and firmly re-tighten the Allen head screw.
4) Width adjustment: Loosen the Allen head screws on the posterior lower leg pad (see fig. 43, item 1). Slide
the posterior lower leg pad to the desired position (see fig. 43, item 2) and firmly re-tighten the Allen head
screws.
39
41
43
Start M2S, Start M2
40
42
Settings
21
