2
PANEL DESCRIPTION
D D KEYPAD
KEY
• Inputs digit '1' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "1."
• Inputs digit '2' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "2."
• Inputs digit '3' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "3."
• Inputs digit '4' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "4."
• Inputs digit '5' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "5."
• Inputs digit '6' for frequency input, memory channel selection,
etc.
• While pushing [PTT], this key sends the DTMF code "6."
4
Pushed momentarily Pushed and held for 1 sec.
• Displays the simple band scope for a single sweep. (p. 23)
• Starts a scan. (p. 75)
• Toggles the transmit output power between high and low. (p. 24)
- "LOW" appears when low power is selected.
- While pushing and holding this key, with [DIAL] rotation selects
the output power.
• Activates the following duplex functions in order.
- Minus duplex operation— "–DUP" appears.
- Plus duplex operation— "+DUP" appears.
- Simplex operation— no duplex indicator appears.
- While pushing and holding this key, with [DIAL] rotation selects
the duplex function.
• Turn the frequency skip function ON and OFF in VFO mode, or
set the memory channel as the following skip channel in memory
mode in order (p. 79).
- Skip channel— "SKIP" appears.
- Frequency skip channel— "PSKIP" appears.
- Non-skip channel— no skip indicator appears.
• Turn the memory name or bank name indication ON and OFF.
(p. 70)
