7.4 E
XTERNAL
General Specifications
(50:50 Tx-Rx Duty Ratio, with new battery pack)
Backup time for Booster Pack
(50:50 Tx-Rx Duty Ratio, with new battery pack)
Dimensions: Height / Width / Depth
Weight
Voltage
Temperature
Charger DC Output Fuse
(Reverse DC Polarity Protection)
Connectors
Compliance
The External Battery Pack is provided with an external Battery Charger. This charger is a
separate physical unit that resides outside of the Battery Pack enclosure case.
2021-11-15
B
P
ATTERY
ACK
Backup time for PDR8000
Charging Time
Float Charge
Battery Pack
Battery Charger
Battery Pack
Battery Charger
Battery Charger Input
Battery Pack Output
Charging
Operating
Storage
Battery Pack DC Output
Charger AC Input
Charger DC Output
Charger
Charger DC Plug
PDR8000® Portable Digital Repeater Product Planner
S
PECIFICATION
5 hrs
4.5 hrs
10 hrs approx.
Required
245mm (9.65") x 280mm (11.0") x 175mm (6.9")
51mm (2.0") x 127mm (5.0") x 124.5mm (4.9")
13.0kg (28.5lb)
1.8kg (4.0lb)
100-132V AC, 50-60 Hz
200 - 240V AC, 50-60 Hz with Step Down Transformer
10.9V DC – 13.8V DC
+20°C to +25°C (+68°F to +77°F)
-15°C to +50°C (+5°F to +122°F)
+25°C (+77°F)
7.5A, Automotive Blade Type, Fast Blow
CA3102E16-11SB, "MIL-C-5015" Bayonet
NEMA 5-15P Three Prong AC Plug
CA3106E16-11PB, "MIL-C-5015" Bayonet
CSA C22.2, UL 1236
MIL-C-5015
Document 8K088X02 R5.0
S
UMMARY
Page 62 of 64
