Label
USB
6.15 E
XTERNAL
The Booster Pack also connects to its external environment via several connection ports.
These are located on the side of the case. The external connection points on the Booster Pack
are illustrated below.
Note that an LED "Power" indicator is included to indicate whether the Booster Pack is powered
on. This indicator can be disabled via the adjacent switch, as some users may want to operate
in "dark mode" with no visible power/activity indicators.
2021-11-15
Front Panel (lid open)
Type
USB Type B

Table 6: PDR8000 External Ports

P - B
ORTS OOSTER

Figure 31: Booster Pack External Ports

PDR8000® Portable Digital Repeater Product Planner
Open/Close Mechanism
Screw/Unscrew Dust Cap
P
ACK
Document 8K088X02 R5.0
