6.10.1 F
P
RONT
BLUETOOTH
LOCAL RPT
DC/BATTERY
The front panel status LEDs fall into two categories:
Dedicated Status LEDs These LEDs have permanent labels beside them indicating
the represented PDR8000 functionality:
o BLUETOOTH: For future use
o WLAN: For future use
o LINK TX: Indicates status and activity on the Transmit Wireline (Ethernet or V.24)
Interface
o LINK RX: Indicates status and activity on the Receive Wireline (Ethernet or V.24)
Interface
o LOCAL RPT: Indicates whether PDR8000 is currently repeating due to initial
configuration or received wireline command
o DC/BATTERY: Indicates whether DC Power is normal, above/below operational
threshold, or approaching lower threshold (configurable indication thresholds)
o LINK QUALITY: Indicates the quality of the network (Ethernet or V.24 interface)
o LAN STATUS: For future use
o RF TX: Indicates Transmitter activity
o RF RX: Indicates Receiver activity
o PDR STATUS: Indicates whether PDR is operating normally, or whether a pending
Warning or Error exists. Warnings and Errors are clearly captured in the Tech Log,
accessible via the service software (Futurecom Repeater Configurator (FRC)).
o POWER: Indicates whether PDR is powered on
2021-11-15
I
ANEL
NDICATORS
RESET
WLAN
LINK TX
LINK RX

Figure 25: Front Panel LEDs and Switches

PDR8000® Portable Digital Repeater Product Planner
PDR PTT
General Status LEDs
LINK QUALITY
LAN STATUS
RF TX
Dedicated Status LEDs
RF RX
PDR STATUS
POWER
Document 8K088X02 R5.0
Page 44 of 64
