Connector
Label
1
V.24
2**
LAN
3
13V/7A DC
4
100-240V/4A AC
5
AUX
6
ANTENNA
7
RF OUT
8
RF IN
9
10
2
Connector was EGG.1K.306.CLL on releases prior to PDR8000 Release 4
2021-11-15

Figure 30: PDR8000 External Ports

Side Panel
Type
RJ-45
RJ-45
DC Power
Input
AC Power
Input
Circular
Receptacle
N Female
N Female
N Female
Ground Lug
10-32x12.7mm
(0.5")
Green LED
Indicator
PDR8000® Portable Digital Repeater Product Planner
Manufacturer
Model Ref*
CONEC
17-111574
CONEC
17-111574
LEMO
EGL.2K.302.
CLA
NEUTRIK
NAC3MPX
LEMO
EGG.1K.308.
2
CLL
N/A
N/A
N/A
N/A
N/A
N/A
NA
N/A
N/A
N/A
Document 8K088X02 R5.0
Open/Close
Mechanism
Screw/Unscrew
Dust Cap
Screw / Unscrew
Dust Cap
Push Pull Dust Cap
Push Pull Sealing
Cover
Push Pull Dust Cap
Screw/Unscrew
Dust Cap
Screw/Unscrew
Dust Cap
Screw/Unscrew
Dust Cap
N/A
N/A
Page 50 of 64
