RF Band/Frequencies
VHF
UHF 380 – 430 MHz
UHF 380 – 430 MHz
UHF 450 – 470 MHz
700 MHz
800 MHz

Table 1: Duplexer Specifications for PDR8000 Suitcase

Note that the following diagrams illustrate the adaptability of PDR8000 suitcase by use of its
internal and external connection points. These diagrams do not represent a detailed view of the
circuitry within each of the elements.
2.1.1 I D
NTERNAL
2.1.2 S
IMPLEX
2021-11-15
Tx to Rx Separation
5 MHz
10 MHz
5 MHz
5 MHz
30 MHz
45 MHz
UPLEXER

Figure 4: Internal Duplexer Hardware Topology

Figure 5: Simplex Hardware Topology

PDR8000® Portable Digital Repeater Product Planner
Bandpass Width
500 KHz
100 KHz
500 KHz
500 KHz
6 MHz
10 MHz
