7 PDR8000 SPECIFICATION

7.1 PDR8000 S
General Specifications
Dimensions: Width / Height / Depth
Weight (without duplexer)
DC Current Drain
Operating Temperature, Full Power setting;
At 50% Transmit Duty Cycle with case closed
At 100% Transmit Duty Cycle with case open
External Connectors
Internal Connector
IEC IP Rating During Operation and Storage
Military Standards Compliance
Safety
Equipment Type Acceptance
Transmitter Specification
3
Connector was EGG.1K.306.CLL prior to PDR8000 Release 4
2021-11-15
S
UITCASE
PECIFICATION SUMMARY
488 mm (19.2") x 386 mm (15.2") x 185 mm (7.3")
27.8 lbs. / 12.6kg
AC Supply Voltage
100V AC to 240V AC, 47Hz to 63Hz
AC Current at 120V AC
2.9A
AC Supply Approvals
UL60950-1 and IEC60950-1
DC Supply Voltage
13.8V DC -15%/+20%
Standby/Receive
0.9A
Transmit
7.0A
-30°C to 55°C
-30°C to 60°C
Antenna Impedance
50 Ohms
Antenna
N female, with Dustcap
RF Input
N female, with Dustcap
RF Output
N female, with Dustcap
AC Input
powerCON TRUE1, NAC3MPX, with Sealing Cover
DC Input
LEMO push pull, EGL.2K.302.CLA, with Dustcap
AUX
LEMO push pull, EGG.1K.308.CLL
V.24
RJ-45 Type, 17-111574, with Dustcap
LAN
RJ-45 Type, 17-111574, with Dustcap
Ground
Stainless steel stud, 0.5" long with 10-32 thread
Computer Interface
USB (type B)
Channel Spacing
Digital: 12.5kHz programmable
Analog: 12.5 kHz or 25 kHz programmable
Number of Channels
64
IP65
(Closed Case)
MIL-STD-810G
High Temperature
501.6
Low Temperature
502.6
Temperature Shock
503.6
Rain
506.6
Humidity
507.6
Salt Fog
509.5
Vibration
514.7
Shock
516.7
EN 62368-1
FCC
LO6-DVRSVHF
Industry Canada
2098B-DVRSVHF
Frequency Bands
136-174 MHz
PDR8000® Portable Digital Repeater Product Planner
VHF
UHF
LO6-DVRSUHF
2098B-DVRSUHF
VHF
UHF
380-430 MHz
Document 8K088X02 R5.0
3
with Dustcap
700 MHz
800 MHz
LO6-DVRS700
LO6-DVRS800
2098B-DVRS700
2098B-DVRS800
700 MHz
800 MHz
764-776 MHz
851-869 MHz
