Configure a VLAN and a Virtual Router to Use a Front
Panel Port for Local Management
What to Do Next
Configure the switch's IP address for the management virtual LAN (VLAN) by following the steps in

Configure a VLAN and a Virtual Router to Use a Front Panel Port for Local Management

Configure a VLAN and a Virtual Router to Use a Front Panel Port for Local
Management
About This Task
The 5320 Series does not have a dedicated Ethernet port for out-of-band (OOB) management. Instead,
you can create and configure a VLAN and a virtual router in order to use a front panel port for local
switch management.
Log in to the management console, connect to the device, and follow these steps.
Procedure
1. Create a user virtual router (VR) using the following command:
For models 5320-48T-8XE and 5320-48P-8XE, use the following command:
create vr vr-name
For all other models, use the following command:
create vr vr-name local-only
create vr VR-mymgmt
2. Create a VLAN and connect the virtual router using the following command:
create vlan vlan-name vr vr-name
create vlan myvlan vr VR-mymgmt
3. Remove the port to use as the management port from the default virtual router (vr-default) using
the following command:
configure vr vr-default delete port port-number
configure vr vr-default delete port 12
4. Add the port to use as the management port to the virtual router using the following command:
configure vr vr-name add port port-number
configure vr vr-mymgmt add port 12
5. Add the port to use as the management port to the VLAN using the following command:
configure vlan-name add port port-number
configure myvlan add port 12
6. Configure the IP address and subnet mask length using the following command: configure
vlan-name ipaddress ipaddress/subnet-mask
configure myvlan ipaddress 10.69.8.100/24
7. Configure the default gateway (you must specify VR-Mgmt for the management port and VLAN
mgmt) using the following command:
configure vlan-name iproute add default ipaddress vr vr-name
configure iproute add default 10.69.8.1 vr vr-mymgmt
8. Enter save to save your configuration changes so that they will be in effect after the next system
reboot
66 ExtremeSwitching 5320 Series Hardware Installation Guide
Activate and Verify the Switch
on page 66.
