STEP 9
32 Orient the Right pedal (33) as
14
shown, and attach it to the right
76
pedal arm (15) with two bolts
33
(M10*45) (76), two washers (M10)
76
(72), and two Locknuts (M10) (83);
start both bolts and then tighten the
15
locknuts.
72
Attach the Left pedal (30) to the Left
pedal arm (14) in the same way.
83
72
83
STEP 10
Tip: Avoid pinching the wire. Attach
the Handlebar (6) to the Upright (2)
with two screws (M8*16) (74), two
Split washers (M8) (90), and two
Curved washer (M8) (65), start both
screws, and then tighten them.
STEP 11
While a second person holds the
console (5) near the Upright (2),
connect the wire (C) on the Console
to the Upright wire (49). Insert the
excess wire into the Upright.
Tip: Avoid pinching the wire. Attach
the console (5) to the Upright (2)
with two screws (M5*12) (80), start
both screws and then tighten them.
Then plug the Pulse wire (81) into
the receptacle on the back of the
Console (5).
