Part nr Qty Unit Description
9192331 12 Pcs Chicken rack 1,7 kg RVS
9191136 1 Pcs Pipe brush
9191146 1 Pcs Pipe brush little
9191150 1 Pcs Grease bag 10 Ltr (box of 100st)
9190073 Handle lock
9191244s Turbine puller
9191175 Grease bag 10 Ltr (box of 200st)
9191154 Cleaning fluid 5l (one can)
9191284 Cleaning fluid 5l (x4)
0194935 Tb Loctite 620, 50ml
0194938 Tb Loctite 648, 50ml
9191234 Pcs Sealant, 2 component
3500306 Ct Sealant silicon red 343°C / 650°F
4302335 Ct Sealant silicon, aluminum 230°C /
450°F
4302375 Ct Sealant silicon, black 200°C / 400°F
9061045 Al Silicon spray Eurogrill 0,4ltr
9191109 Ct Lubricant OKS 250Moly P1900 - 400 gr.
9191235 Rl Foam tape, thick 2mm, wide 9mm
9171128 Rl Velcro ( contra hook )
9171127 Rl Velcro ( hook )
9192071 2 Mtr Washer 10x14mm, copper
9110103 0,5 Pcs Isolation plate Conlit, 1800x900x15mm
9004718 2,8 Pcs Isolation plate type 520,
1000x600x22mm
9261022 1 Pcs Cable gland M25
9261023 1 Pcs Nut, cable gland M25
9194529 1 Pcs Lasercut Ampère Sign, Multisserie USA
9191255 1 Pcs Earth sign
9192269 1 Pcs Earth strip
9079137 Mtr Wire AWG 12, black
9079140 Mtr Wire AWG 12, green/yellow
9070654 Mtr Wire AWG14, black
0260155 Pcs Wire AWG18, black
2005933 Rl Ringterminal, M4 red
2005755 Pcs Ringterminal, M4 Blue
2006159 Pcs Ringterminal M4, uninsulated
2005941 Pcs Ringterminal, M5 Red
2005763 Pcs Ringterminal, M5 Blue
2006133 Pcs Receptacle, female Blue
2005836 Pcs Receptacle, female Red 2,8mm
2006183 Pcs Receptacle, female Red, full insulated
2006222 Pcs Receptacle, female Red piggyback
4310570 Rl Receptacle, uninsulated (6000)
Service Manual Deli Multisserie form 9123667 rev. 20220317
EXPLODED VIEWS AND PARTSLISTS

MISCELLANIOUS

Part nr
8031502
2005967
2005802
2006303
2005658
6511553
9191187
9191211
2008614
9190072
9194504
9193144
9193145
4288189
9008047
9193091
9191116
0147016
Qty Unit Description
Pcs Receptacle insulation boot, 6,3x0,9
Pcs Splice, Red
Pcs Splice, blue
Pcs Bootlace ferrule, Grey 0,75 qmm
Pcs Bootlace ferrule, Blue 9mm
0,2 Mtr Cable protection sleeve
Rl Spiral protecting conduit Ø6.4mm
Rl Spiral protecting conduit Ø8mm
15 Pcs Sokkel, cable tie
1 Pcs Crate set multisserie on underframe
2 Pcs U-profile (on pallet)
2 Pcs Support plank, underframe Front/Rear
2 Pcs Support plank, underframe L/R
4 Pcs Bolt M8x80, ZP
5 Pcs Nut M8, ZP self locking
3 Pcs Lock bushing for transport
2 Pcs Cap, 3/4" pvc
4 Pcs Screw 2,5x10 cheese head
