Doc. nr.
Rev.
9129358
0
WARNING
Self-contained units: Risk of Fire or explosion. Flammable refrigerant used.
WARNING
The maximum load on top of the unit may never exceed 22 Lbs.
MINIMUM ROOM FLOOR
Self-contained units: Refer to the data label on the unit for the required floor area.
WARNING
See installation instructions for grounding requirements.
WARNING
Always use the brakes on both front wheels when applicable:
WARNING
Remote R744 refrigerant is environmentally friendly but under high pressure. It is non-toxic
with zero Ozone Depletion Potential (ODP) and very low Global Warming Potential (GWP).
Read this manual carefully and follow all precautions described herein.
SAFETY
Wear eye protection when working on the refrigeration system.
WARNING
Remote R744 filled under high pressure.(max. 60 bar/ 870 PSI)
•
Do not tamper with the system.
The system must be installed and maintained by qualified persons only.
•
Fixate the unit to the floor.
•
The ventilation openings of the cladding of the unit (including accessories) must not be blocked or covered.
•
Ensure that the air circulation remain unobstructed.
Registration form.
MCC
Drop in installation instruction US
Safety instructions
AREA
Cold units with remote CO2 (R744) refrigerant
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fri-Jado MCC
Summary of Contents for Fri-Jado MCC
- Page 1 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Safety instructions WARNING Self-contained units: Risk of Fire or explosion. Flammable refrigerant used. WARNING The maximum load on top of the unit may never exceed 22 Lbs. MINIMUM ROOM FLOOR AREA Self-contained units: Refer to the data label on the unit for the required floor area.
- Page 2 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Installation must comply with: • No spark-forming components or components with a high surface temperature may be present in the substructure / counter where the furniture is placed. • The refrigeration components must not be directly accessible by unauthorized Personnel.
- Page 3 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Unpack instruction The MCC Drop in will be delivered, packed in a crate Start unpacking by removing top cover Remove short sides first (Left and Right), by unscrewing them.
- Page 4 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Remove foam which holds the electrical box Remove documents and glass shelfs from unit. Step 1. Position the cabinet above the cut-out in the counter top with a forklift and support it using the wooden beams supplied with the unit Step 2.
- Page 5 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Step 6. Install a partition panel to prevent recirculation of hot condenser air. (Not applicable for remote units) Step 7. Install all remaining trim panels. Make sure ventilation openings have the correct size and the cabinet remains accessible for service and maintenance.
- Page 6 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 CONNECTING REFRIGERATION PIPES FOR REMOTE SYSTEM MCC...
- Page 7 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Make sure, after build in, the condensing unit is still accessible. Keep in mind the complete condensing unit is extendable on self-contained units, at the back side of the unit for maintenance and service purposes. For remote units, please keep latch for service.
- Page 8 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Connections; Drain, Refrigiration pipework, Power Supply Electrical specifications...
- Page 9 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358...
- Page 10 Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Distance between units when using coupling kit...
-
Page 11: Self-Contained
Doc. nr. Rev. Registration form. Drop in installation instruction US 9129358 Self-Contained: Do not block the internal airflow with products!
