INSTALLATION
MODELS
Multi Deck 25 Hot
Multi Deck 40 Hot
Classic Deck Hot
Classic Deck Cold
WWW.FRIJADO.COM
MANUAL
MULTI DECK
CLASSIC DECK
Model Classic Deck Hot
This manual is prepared for the use of trained Service Technicians and
should not be used by those not properly qualified. If you have attended
a trianing for this product, you may be qualified to perform all the proce-
dures in this manual.
This manual is not intended to be all encompassing. If you have not
attended a training for this product, you should read, in its entirety, the
repair procedure you wish to performto determine if you have the neces-
sary tools, instruments and skills required to perform the procedure.
Procedures for which you do not have the necessary tools, instruments
and skills should be performed by a trained technician.
Reproduction or other use of this Manual, without the express written
consent of Fri-Jado, is prohibited.
Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006
- NOTICE -
Model Multi Deck 40 Hot
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fri-Jado Multi Deck 25 Hot
Summary of Contents for Fri-Jado Multi Deck 25 Hot
- Page 1 INSTALLATION MANUAL MULTI DECK CLASSIC DECK MODELS Multi Deck 25 Hot Multi Deck 40 Hot Classic Deck Hot Classic Deck Cold Model Classic Deck Hot Model Multi Deck 40 Hot - NOTICE - This manual is prepared for the use of trained Service Technicians and should not be used by those not properly qualified.
- Page 2 TABLE OF CONTENTS EMPTY PAGE Page 2 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006...
-
Page 3: Table Of Contents
Casters ............................9 Test run ............................9 Instructions for operators ........................9 Installation drawings ..................... 10 Multi Deck 25 hot ...........................10 Multi Deck 40 hot ...........................11 cLASSIC dECK hot ..........................12 Page 3 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006... -
Page 4: General Technical Data
This manual covers the Multi Deck 25 and 40 Hot and the Classic Deck Hot and Cold series merchan- diser cabinets. The cabinets come in two sizes, 25 and 40 inches. • Multi Deck 25 Hot - Merchandiser 25 Inches wide. • Multi Deck 40 Hot - Merchandiser 40 Inches wide. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS UNPACKING AND REMOVING THE UNIT FROM THE PALLET Immediately after unpacking the merchandiser, check for possible shipping damage. If the merchan- diser is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. - Page 6 1. Carefully tilt the unit slightly 2. Remove the board-and-beam assembly 3. Carefully lower the unit until it rests on the floor Unit after removal of the crate 1. Remove the screws from the connecting Remove the screws from the board on the front beam side of the pallet as shown above 2.
- Page 7 Carefully let the unit slide onto its wheels Remove top transport safety beam WARNING! Prevent the unit from rol- 1. Carefully tilt the shelf slightly ling away on the casters. 2. Remove the transport beam 3. Repeat for bottom shelf Page 7 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev.
-
Page 8: Location/Airgrid
Remove transport safety shelfs (3x) LOCATION/AIRGRID The merchandiser must be installed on a level surface. The installation location must allow adequate clearances for servicing and proper operation. Take care that a free airflow around the top is secured. This is to prevent the electronic ballast for overheating. -
Page 9: Electrical Supply
CASTERS Each merchandiser is furnished on 4 casters of 3 1/8”. The Multi Deck 25 hot and Classic Deck hot & cold have 2 rigid casters on the back side and 2 locking swivel casters on the customer side. The Multi Deck 40 hot is furnished with 2 swivel casters on the back side and 2 locking swivel casters on the cus- tomer side. -
Page 10: Installation Drawings
Power cable, length 80” * *) length is measured from the point where the cables coms out of the unit MULTI DECK 25 HOT Page 10 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006... -
Page 11: Multi Deck 40 Hot
MULTI DECK 40 HOT Page 11 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006... -
Page 12: Classic Deck Hot
CLASSIC DECK HOT Page 12 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006... - Page 13 Fri-Jado Inc. • 180 Kehoe Blvd. • Carol Stream, Ill. 60188 • USA • tel. 630-784-3469 • fax 630-784-1650 • toll free 877-FRI-JADO • us.info@frijado.com • www.frijado.com Page 13 Installation Manual Multi Deck 25/40 hot / Classic Deck 25 hot/cold form 9123655 rev. 03/2006...
