Summary of Contents for Fri-Jado Modular Table Top
- Page 1 ‒ USER MANUAL USA version Modular Table Top WARNING Read the instructions before using the machine. 9124856 / 2310...
- Page 2 KEEP THIS USER MANUAL FOR FUTURE USE! © 2023 Fri-Jado B.V., Oud Gastel, The Netherlands. We advise you to contact your supplier for the guarantee period and conditions. Further we refer to our General Terms and Conditions for Sales and Delivery that are available upon request.
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ......................4 General ..........................4 Identification of the unit ..................... 4 Pictograms and symbols ....................4 Safety instructions ......................5 1.4.1 General ........................5 1.4.2 Moving (when applicable) .................... 6 1.4.3 Outdoor use restrictions ....................6 Hygiene ..........................6 Service and technical support ................... -
Page 4: Introduction
INTRODUCTION General This manual is intended for the user of the MTT (Modular Table Top). The features and controls are being described, along with directions for the safest and most efficient use, in order to guarantee a long life of the unit. -
Page 5: Safety Instructions
Safety instructions WARNING The outside and shelves of the unit can be very hot. WARNING The maximum load on top of the unit may never exceed 22 lbs. WARNING See installation instructions for grounding requirements. 1.4.1 General The user of the unit will be fully responsible for abiding the locally prevailing safety- rules and regulations. -
Page 6: Moving (When Applicable)
1.4.2 Moving (when applicable) When moving the unit: • Before moving the unit, first switch off the mains voltage by pulling the plug from the wall socket. • Remove pans containing a liquid product from the unit. • Always keep the unit in upright position. To prevent damage from moving/lifting the unit, remove the front panel by pulling on one of the hinge pins. -
Page 7: Service And Technical Support
Service and technical support The electrical schematics of your unit is included. In case of malfunctions you can contact your dealer/service agent. Make sure you have the following data available: • Model. • Serial number. This data can be found on the identification plate. Storage If the unit will not be used temporarily, and will be stored, follow these instructions: •... -
Page 8: Description Of The Unit
DESCRIPTION OF THE UNIT Technical description The panels are made of galvanized steel plating, stainless steel or aluminium. Some of the visible internal and external parts have been provided with a powder coating. The glass used is tempered. The controls for operating the appliance have been mounted on the operator side of the unit. The product contact parts are made of stainless steel AISI 304 or AISI 430 and tempered glass. -
Page 9: Installation And First Use
INSTALLATION AND FIRST USE All packing materials used for this unit are suited for recycling. Before and during unpacking, check the state of the unit. In case of damage, store the packing material, and contact the transporter within fifteen working days after receiving the goods. Unpacking the unit 1. -
Page 10: Installation And Positioning
Installation and positioning WARNING Electric chock hazard. Grounding instructions: only connect the appliance to an alternating current provided by a grounded wall socket, with a mains voltage in accordance with the information indicated on the data plate of the appliance. It is the consumer's responsibility to make sure the electrical installation conforms with current national and local codes and wiring regulations. - Page 11 These 4 types of air blockers need to be installed according the next steps: 1. Mount the air blockers under the shelf at the 4 positions. 2. Mount air blocker 1 and 2 on the right hand side of the shelf and mount air blocker 3 and 4 on the left hand side of the shelf with 6 screws (hand tight).
-
Page 12: Installation Of Plinth Set
Installation of plinth set Install the plinth set as initiated on the installation instruction (9124862). If the power cord needs to go underneath the unit, the back plinth will have an opening which needs to be facing upwards. If the power cord goes around the unit, the opening of the back plinth must face downwards. -
Page 13: Operation And Use
OPERATION AND USE The display and/or set value is not the product/unit temperature. Control Panel On/Off Switch(es): The main switch is located left underneath the front of the unit. Controls: Note: The controls are located behind the front panel of the unit. To access the controls: 1. -
Page 14: Operating
If you need any assistance in determining the best setup for your hot food-to-go offering (such as temperature setpoint, packaging and accessories), please contact Fri-Jado. Temperature controller Power on/off button*... - Page 15 Loading the unit • Only place products that have a core temperature of at least 185ºF. • The hot products need to be packaged in bags or containers that are suitable for this purpose. • To ensure a good contact with the heated trays, only place a single layer of products. •...
-
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING Never use a water hose for cleaning. Water can seep into the unit through the ventilation holes of the unit. Appliances must be disconnected from their power supply during cleaning or maintenance and when replacing parts. Because of hygiene aspects and optimum condition of the unit it is of utmost... -
Page 17: Cleaning Glass Panes
Cleaning Glass Panes Cleaning the top air guide WARNING Do not use detergents and other cleaning products that may damage polycarbonate. Using inappropriate products to clean may tarnish, scratch or even crack any polycarbonate surfaces. The transparent air guide pane can be removed for cleaning. •... -
Page 18: Malfunctions And Service
MALFUNCTIONS AND SERVICE Before you consult your dealer or the service agency when there is a fault, you can check the following points yourself: • Is the power supply OK? Check the fuses and the earth leakage switch in the meter cupboard. •... -
Page 19: Technical Specifications
TECHNICAL SPECIFICATIONS WARNING Consult the identification plate to get the proper specifications of the unit. The electrical data may vary from country to country. Model MTT 24-2 MTT 36-2 Approved for USA / CAN USA / CAN Width 23 5/9 in 35 7/16 in Depth SB model 24 in... - Page 20 Fri-Jado B.V. Fri-Jado Inc. Blauwhekken 2 1401 Davey Road, Suite 100 4751 XD Oud Gastel Woodridge IL 60517 The Netherlands Tel: +31 (0) 76 50 85 400 Tel: +1-630-633-7950 www.frijado.com 20/20...
