QuickTouch Preset
Add Preset Content
Note:
Because trims represent a universal way to update a motor position, this allows updates
throughout all references to be simultaneous. If a desired position changes (for example,
due to soft goods stretching), trim-based references can be updated by altering a single
referenced trim position.
1. From the Presets screen, select the preset to which you want to add content.
2. Select a channel that you want to be in the preset. A position dialog box appears.
3. Enter the desired preset position for the motor for this preset.
Reference a trim position by selecting from the four available trims or pressing Trims to see
•
other recorded trims.
Press Current to store the current position of the channel.
•
Enter a specified position by selecting the position field.
•
4. Press Ok to close the motor position dialog.
5. Repeat these steps for any other channels you want to be included in the preset.
Note:
has been created, nor after content has been updated.

Play a Preset

To play a preset, simply select the preset from the list and press the Load button. This takes you
directly to the Manual tab where you can press the [GO] button to run the preset.

Edit Presets

To edit a preset, select the preset you want to edit and perform the following actions:
Add a channel: Select the channel to add and set the desired preset motor position.
•
Remove a channel: Select the channel to open the position dialog and then press Remove.
•
Edit motor position: Select the channel to open the position dialog and then change the
•
desired motor position.
QuickTouch Preset
It is recommended that you use trims when building groups, presets, and cues.
Preset content is stored automatically. You do not need to save a preset once it
