OWNER'S MANUAL

Operation

Maintenance

Specifications

All information in this Owner's Manual is current at the time

of publication. However, HYUNDAI reserves the right to make

changes at any time so that our policy of continual product

improvement may be carried out.

This manual applies to all HYUNDAI models and includes

descriptions and explanations of optional as well as standard

equipment. As a result, you may find material in this manual

that does not apply to your specific vehicle.

Table of Contents

Chapters

Table of Contents

Need help?

Do you have a question about the Palisade 2023 and is the answer not in the manual?

Questions and answers

АЛЕКСАНДР

April 7, 2025

Загаратся ошибка проверьте AWD 4WD и отключается полный привод

1 comments:

Mr. Anderson

April 9, 2025

The AWD (All Wheel Drive) error in a 2023 Hyundai Palisade is indicated by the AWD warning light staying on the instrument cluster. This may signal a malfunction in the AWD system. The exact cause is not specified, but it requires inspection by an authorized Hyundai dealer. Additionally, improper use on a dynamometer or damage from incorrect lifting of the vehicle may also harm the AWD system.

This answer is automatically generated

Krys

August 5, 2025

What does Hyundai call the small flap that is just forward of the rear tires? Is it also called a mud guard, mud flap, tire flap or like? Mine is cracked/torn on my 2023 Hyundai Palisade Caligraphy and I would like to replace it. I am looking for instructions on how to remove and replace the flap and a part number. Thank you. Krys

Юсифов Шакир

August 3, 2025

при посадке переднего пассажира у водителя пропадает управление функциями. не открывается окно не реагирует фары и много другое.

Richard

July 26, 2025

Where are the drain holes for the sunroof located on a 2023 Palisade

tom

June 21, 2025

where controls to activate side mirrors to turn in the car to protect them

Kara

June 12, 2025

The parking camera

Summary of Contents for Hyundai Palisade 2023

Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all HYUNDAI models and includes descriptions and explanations of optional as well as standard equipment.
Page 2 Introduction CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S.
Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Page 4 Introduction HYUNDAI VEHICLE OWNER PRIVACY POLICY Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information.
Page 5: Table Of Contents
Table of Contents Introduction Vehicle Information, Consumer Information and Reporting Safety Defects Seats & Safety System Instrument Cluster Convenience Features Driving Your Vehicle Driver Assistance System Emergency Situations Maintenance Index...
Page 6: Introduction
1. Introduction Introduction......................1-2 Hyundai Motor America ..................1-2 Guide to Hyundai Genuine Parts ..............1-3 How to Use this Manual ..................1-4 Safety Messages ....................1-4 Fuel Requirements ..................... 1-5 Gasoline containing alcohol or methanol ..............1-5 Using Fuel Additives (except Detergent Fuel Additives) ......... 1-6 Gasoline containing MMT ..................
Page 7: Introduction
Your Owner’s Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle.
Page 8: Guide To Hyundai Genuine Parts
In addition, any damage to or failure of HYUNDAI Genuine Parts caused by the installation or failure of an imitation, counterfeit or used salvage part is not covered by any HYUNDAI Warranty. 3. How can you tell if you are purchasing HYUNDAI Genuine Parts? Look for the HYUNDAI Genuine Parts Logo on the package (see below).
Page 9: How To Use This Manual
Introduction HOW TO USE THIS MANUAL We want to help you get the greatest possible driving pleasure from your vehicle. Your Owner’s Manual can assist you in many ways. To gain an overview of the contents of your Owner’s Manual, use the Table of Contents in the front of the manual. The first page of each Chapter includes a detailed Table of Contents of the topics in that Chapter.
Page 10: Fuel Requirements
Flexible Fuel Vehicles. “E85” is not compatible with your vehicle. Use of “E85” may result in poor engine performance and damage to your vehicle’s engine and fuel system. HYUNDAI recommends that customers do not use fuel with an ethanol content exceeding 15 percent.
Page 11: Using Fuel Additives (Except Detergent Fuel Additives)
The malfunction indicator lamp on the cluster may come on. Detergent Fuel Additives HYUNDAI recommends that you use good quality gasolines treated with detergent additives such as TOP TIER Detergent Gasoline, which help prevent deposit formation in the engine. These gasolines will help the engine run cleaner and enhance performance of the Emission Control System.
Page 12: Vehicle Modifications
Some warning sounds (including welcome/good-bye sound, etc.) are generated from the interior speakers or amplifiers. If necessary, we recommend you to purchase HYUNDAI Part to replace an interior speaker or amplifier. Any unauthorized product may cause a malfunction of the interior speakers or amplifiers.
Page 13: Vehicle Data Collection And Event Data Recorders
Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 14: Vehicle Information, Consumer Information And Reporting Safety Defects
2. Vehicle Information, Consumer Information and Reporting Safety Defects Exterior Overview (I) ..................2-2 Exterior Overview (II) ..................2-3 Interior Overview ....................2-4 Instrument Panel Overview (I) ................. 2-5 Instrument Panel Overview (II) ................ 2-6 Engine Compartment ..................2-7 Dimensions ......................2-8 Engine ........................ 2-8 Bulb Wattage .....................
Page 15 Vehicle Information, Consumer Information and Reporting Safety Defects Front view The actual shape may differ from the illustration. A0001EU02 1. Hood ............5-82 6. Sunroof .......... 5-71, 5-75 2. Headlight ..........9-57 7. Front windshield wiper blades ... 5-110, 9-25 3.
Page 16 Rear view The actual shape may differ from the illustration. A0002EU02 1. Door ............5-29 6. High mounted stop lamp .....9-60 2. Fuel filler door ........5-29 7. Rear window wiper blades ....5-113 3. Rear combination lamp......5-29 8. Antenna ..........5-170 4.
Page 17: Interior Overview
Vehicle Information, Consumer Information and Reporting Safety Defects INTERIOR OVERVIEW The actual shape may differ from the illustration. A0003EU01 1. Inside door handle .........5-32 8. ESC (Electronic Stability Control) OFF button ............ 6-38 2. Side view mirror control switch ... 5-58 9.
Page 18 The actual shape may differ from the illustration. A0004KO01 1. Instrument cluster ........4-4 14. Ventilate seat button ......3-34 15. Warmer seat button ......3-32 2. Horn ............5-46 3. Ignition switch, Engine Start/ 16. Steering wheel heater button ....5-46 Stop button ........
Page 19 Vehicle Information, Consumer Information and Reporting Safety Defects The actual shape may differ from the illustration. A0005KO01 1. Audio remote control buttons .... 5-170 6. Wiper and washer control lever..5-110 2. Bluetooth® hands-free phone button . 5-171 7. LCD display controls......4-28 3.
Page 20: Engine Compartment
ENGINE COMPARTMENT The actual engine compartment in the vehicle may differ from the illustration. A0419KO02 1. Engine coolant reservoir ......9-3 6. Engine oil dipstick ......... 9-15 2. Radiator cap ...........9-18 7. Windshield washer fluid reservoir ..9-22 3. Brake fluid reservoir ......9-21 8.
Page 21: Dimensions
Vehicle Information, Consumer Information and Reporting Safety Defects DIMENSIONS Items in (mm) Overall length 196.65 (4,995) Overall width 77.75 (1,975) Overall height 68.89 (1,750) 245/60 R18 67.24 (1,708) Front tread 245/50 R20 67.24 (1,708) 245/60 R18 67.56 (1,716) Rear tread 245/50 R20 67.56 (1,716) Wheelbase...
Page 22: Bulb Wattage
BULB WATTAGE Light bulb Bulb type Wattage Headlight High, Low beam assist Daytime running light/Position lamp Front Turn signal lamp Side repeater lamp Side marker lamp Type A P28/8W 28/8 Tail lamp Type B Tail/Stop lamp Type A P28/8W 28/8 Stop lamp Type B Type A...
Page 23: Tires And Wheels
Vehicle Information, Consumer Information and Reporting Safety Defects TIRES AND WHEELS Inflation pressure kPa (psi) Wheel nut Maximum Items Tire size Wheel size Normal load torque Kgf·ft load (lbf·ft, N ·m) Front Rear Front Rear 245/60 R18 7.5J X 18 Full size tire 240 (35) 240 (35)
Page 24: Air Conditioning System
Classification Refrigerant 29.98 (850) ± 0.88 (25) R1234yf oz. (g) Compressor lubricant 6.35 (180) oz. (cc) Contact an authorized HYUNDAI dealer for more details. VEHICLE WEIGHT AND LUGGAGE VOLUME 3.8 GDI Item 7 Seater 5,732 (2,570) 5,871 (2,660) lbs. (kg)
Page 25: Recommended Lubricants And Capacities
To maintain the best braking performance and ABS/ESC performance, we recommend *4 : that you use genuine brake fluid that conform to specifications. If the rear differential is submerged, have you visit an authorized retailer of HYUNDAI *5 : genuine products to replace the differential oil.
Page 26: Recommended Sae Viscosity Number
Recommended SAE Viscosity Number CAUTION Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.
Page 27: Vehicle Identification Number (Vin)
Vehicle Information, Consumer Information and Reporting Safety Defects VEHICLE IDENTIFICATION VEHICLE CERTIFICATION LABEL Frame number (if equipped) B0015KO01 B0016KO01 The vehicle identification number (VIN) The vehicle certification label attached is the number used in registering your on the driver’s (or front passenger’s) vehicle and in all legal matters pertaining side center pillar gives the vehicle to its ownership, etc.
Page 28: Engine Number
ENGINE NUMBER AIR CONDITIONER COMPRESSOR LABEL B0017KO01 The engine number is stamped on the B0501EU01 engine block as shown in the drawing. A compressor label informs you the type of compressor your vehicle is equipped with such as model, supplier part number, production number, refrigerant and refrigerant oil 2-15...
Page 29: Consumer Information
This consumer information has been prepared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S. Department of Transportation.Your HYUNDAI dealer will help answer any questions you may have as you read this information. HYUNDAI motor vehicles are designed and manufactured to meet or exceed all applicable safety standards.
Page 30: Reporting Safety Defects
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or HYUNDAI MOTOR AMERICA. 2-17...
Page 31 3. Seats & Safety System Important Safety Precautions ................3-2 Always Wear Your Seat Belt ..................3-2 Restrain All Children ..................... 3-2 Air Bag Hazards ......................3-2 Driver Distraction ......................3-2 Control Your Speed ...................... 3-2 Keep Your Vehicle in Safe Condition ................3-2 Seats ........................
Page 32: Seats & Safety System
Seats & Safety System IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Drivers can become distracted when and recommendations throughout this they take their eyes and attention off section, and throughout this manual. the road or their hands off the wheel to The safety precautions in this section are focus on activities other than driving.
Page 33: Seats
SEATS A0051EU01 Front seat Air ventilation seat Seat sliding forward or rearward / Seat cushion tilt / Seat warmer Seat cushion height Walk-in seat switch Seatback angle Head restraint Leg support (if equipped) Rear air ventilation seat Lumbar support Rear seat warner Seatback bolster (if equipped) Comfortable stretch (if equipped)
Page 34 Seats & Safety System A0053EU01 Rear seat Seat sliding forward or rearward Walk-in strap (for emergency, row seat) row seat) Seatback angel/Seat folding Headrest restraint (3 row seat) row seat) Seat folding switch (2 row seat) Walk-in switch (2 row seat) (if equipped) Headrest restraint (2 row seat)
Page 35 B0051EE03 B0051EE04 Seat Setting screen, you may use various convenience functions. Seat position change alert : Seat change information is displayed. Ergo-motion seat alert: Ergo-Motion seat is operated, information is displayed with the seat image. Warmer/Ventilation Features - Auto. Controls That Use Climate Control Settings (for driver’s seat) : The seat temperature is automatically controlled.
Page 36: Safety Precautions
Seats & Safety System WARNING Information The information provided may differ To reduce the risk of serious injury or death from an inflating air bag, take the depending on which functions are applicable to your vehicle. following precautions: Adjust the driver’s seat as far to the Safety Precautions rear as possible while maintaining the ability to control the vehicle.
Page 37: Front Seats
Front Seats CAUTION To prevent injury: WARNING Do not adjust your seat while wearing your seat belt. Moving the Take the following precautions when seat cushion forward may cause adjusting your seat: strong pressure on your abdomen. NEVER attempt to adjust the seat Do not allow your hands or fingers to while the vehicle is moving.
Page 38 Seats & Safety System Manual adjustment (if equipped) The front seat can be adjusted by using the levers located on the outside of the seat cushion. Before driving, adjust the seat to the proper position so that you can easily control the steering wheel, foot pedals and controls on the instrument panel.
Page 39 Seat belts must be snug against your Power adjustment (if equipped) hips and chest to work properly. When The front seat can be adjusted by using the seatback is reclined, the shoulder the control switches located on the belt cannot do its job because it will not outside of the seat cushion.
Page 40 Seats & Safety System B0052EU06 B0052EU05 Seat cushion tilt Forward and rearward adjustment To change the angle of the front part of To move the seat forward or rearward: the seat cushion: 1. Push the control switch forward or Push the front portion of the control rearward.
Page 41 Seat belts must be snug against your hips and chest to work properly. When the seatback is reclined, the shoulder belt cannot do its job because it will not be snug against your chest. Instead, it will be in front of you. During an accident, you could be thrown into the seat belt, causing neck or other injuries.
Page 42 Seats & Safety System B0052EU08 B0052EU09 Lumbar support (2way) (if equipped) Seat bolster adjustment (for driver's seat) (if equipped) To adjust the lumbar support: To adjust seat bolster: Press the front portion of the switch to increase support or the rear portion of 1.
Page 43 Leg support adjustment (if Ergo-motion seat (if equipped) equipped) Place your leg on the leg support and adjust its angle to relax. B0052EE29 Motion Seat’ from the infotainment system’s Settings menu to select and set B0052EU10 up supplemental functions for the driver. Control switch Slide the leg support switch diagonally WARNING...
Page 44 Seats & Safety System Comfortable stretch Posture assist Comfortable stretch is a function that After driving for an hour, Posture Assist helps relieve fatigue of the driver’s pelvis automatically adjusts the pelvis and back and lower back due to driving. portion of the driver's seat to assist the driver’s posture.
Page 45 Walk-in switch Seatback pocket B0052EU12 B0052KO21 The rear seat passenger may use the The seatback pocket is provided on the switches to control the front passenger back of the front seatbacks. seat. Sliding forward or rearward: CAUTION Press the switch to move Do not put heavy or sharp objects in the the front passenger seat forward or...
Page 46: Rear Seats
Seats & Safety System Rear Seats Loading cargo - Make sure the engine is off, the gear shifted to P (Park), and the WARNING parking brake is securely applied whenever loading or unloading Take the following precautions: cargo. Failure to take these steps Adjusting the seats may allow the vehicle to move - NEVER attempt to adjust the seat...
Page 47 Manual adjustment (second row) WARNING B0053EU02 B0053EU01 Be careful when closing the liftgate with passenger’s seated on the third row seat. If the passenger’s head is not properly against an adjusted head restraint or a tall person is seated, the liftgate may hit the passenger’s head, which could cause injury.
Page 48 Seats & Safety System B0053EU03 B0053EU04 Seatback folding / Walk-in function The seatback will fold and the seat will slightly move forward, if the switch is pressed. The function operates when the gear is in P (Park) with the door open. While the seatback folding or walk-in function is operating, if the switch is pressed, the seat will stop moving.
Page 49 Manual adjustment (third row) Power adjustment (third row) B0053EU05 B0053EU06 Seatback angle Seatback angle To recline the seatback: Press the switch ( ) or ( ) to adjust the seatback angle. 1. Pull the seatback recline strap. When the seatback is folded, press 2.
Page 50 Seats & Safety System Walk-in seat (2 row seat) After getting in or out, slide the 2 seat to the farthest rearward position and pull the seatback firmly backward until it clicks into place. Make sure that the seat is locked in place. WARNING Never attempt to adjust while the vehicle is moving or the 2...
Page 51 Folding the rear seats WARNING The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. Before folding the rear seats, lower the head restraint to the lowest positon and store the seat belt buckles in the holders and webbing in the guide.
Page 52 Seats & Safety System Rear seatback manual folding To fold down the rear seatback: 1. Set the front seatback to the upright position and if necessary, slide the front seat forward. 2. Lower the rear head restraints to the lowest position. B0053EU07 B0053KO11 3.
Page 53 WARNING When returning the rear seatback from a folded to an upright position, hold the seatback and return it slowly. Ensure that the seatback is completely locked into its upright position by pushing on the top of the seatback. In an accident or sudden stop, the unlocked seatback could allow cargo to move forward with great force and enter the passenger...
Page 54 Seats & Safety System Seatback remote folding/unfolding The function operates when the gear is in P (Park) with the door open. (luggage compartment) While the seatback is folding or unfolding, if the switch is pressed, the seat will stop moving. If the switch is pressed again, the seat will continue the adjustment.
Page 55 CAUTION WARNING Without starting the engine, the 3 Do not place any part of your body seat can be folded or unfolded. When or anything in the operating area to this is attempted more than 10 times, intentionally check the detection of any the battery may discharge prematurely.
Page 56: Head Restraint
Seats & Safety System Armrest (Second row seat) Head Restraint The vehicle’s front and rear seats have adjustable head restraints. The head restraints provide comfort for passengers, but more importantly they are designed to help protect passengers from whiplash and other neck and spinal injuries during an accident, especially in a rear impact collision.
Page 57 Front seat head restraints WARNING B0701EU02 B0053KO24 The driver’s and front passenger’s seats When sitting on the rear seat, do not are equipped with adjustable head adjust the height of the head restraint restraints for the passengers safety and to the lowest position. comfort.
Page 58 Seats & Safety System NOTICE B0052KO15 B0052KO14 If you recline the seatback towards the front with the head restraint and seat cushion raised, the head restraint may come in contact with the sunvisor or other parts of the vehicle. B0052KO16 A : Manual seat B : Power seat Removal/Reinstall...
Page 59 Rear seat head restraints B0052KO18 B0701EU03 *: If equipped The rear seats are equipped with head restraints in all the seating positions for the passenger’s safety and comfort. B0052KO19 A : Manual seat B : Power seat To reinstall the head restraint : 1.
Page 60 Seats & Safety System Folding 3 row headrest (except for center) B0701EU05 Removal/Reinstallation B0705EU01 To remove the head restraint: The headrest will fold down 1. Raise the head restraint as far as it can automatically when folding the seatback. To fold the headrest manually: 2.
Page 61: Seat Warmers
Wing-out headrest adjustment (if Seat Warmers equipped) Seat warmers are provided to warm the seats during cold weather. During mild weather or under conditions where the operation of the seat warmer is not needed, keep the seat warmers OFF. WARNING The seat warmers can cause a SERIOUS BURN, even at low temperatures and B0706EU01...
Page 62 Seats & Safety System WARNING NEVER place anything on the seat that insulates against heat when the seat warmer is in operation, such as a blanket or seat cushion. This may cause the seat warmer to overheat, causing a burn or damage to the seat. NOTICE B0056KO01 To prevent damage to the seat warmers...
Page 63 Manual temperature control Each When When pressing the switch for time you push the switch, the more than 1.5 seconds with the seat temperature setting of the seat is warmer operating, the seat warmer changed as follow : will turn off. - Front seat The seat warmer defaults to the OFF position whenever the ignition switch...
Page 64: Air Ventilation Seats
If the air vents do not operate, restart the vehicle. If there is no change, have your vehicle inspected by an authorized HYUNDAI dealer. row seat If the air ventilation seat is positioned at HIGH, the airflow speed will increase according to vehicle speed.
Page 65 If there is no change, If the outside temperature is under have the vehicle inspected by an approximately 33°F (2°C), the air authorized HYUNDAI dealer. ventilation seat may not operate. Use the air ventilation seat when the climate control system is on. Using...
Page 66: Seat Belts
Seats & Safety System SEAT BELTS This section describes how to use the NEVER wear a seat belt over fragile seat belts properly. It also describes objects. If there is a sudden stop or some of the things not to do when using impact, the seat belt can damage it.
Page 67: Seat Belt Warning Light
Seat Belt Warning Light Rear passenger's seat belt warning Front seat belt warning Instrument cluster B0059KO04 A : 7-seater vehicle, B : 8-seater vehicle B0059KO02 As a reminder to the driver, the seat With the ignition switch ON, if the second row center seat passenger’s seat belt warning light will illuminate for approximately 6 seconds each time...
Page 68: Seat Belt Restraint System
Seats & Safety System Seat Belt Restraint System WARNING Riding in an improper position WARNING adversely affects the front passenger’s seat belt warning system. It is important Improperly positioned seat belts may for the driver to instruct the passenger increase the risk of serious injury to properly be seated as instructed in in an accident.
Page 69 Front Seat Belt – Driver’s 3point system with emergency locking retractor B0059KO06 You should place the lap belt portion across your hips and the shoulder belt portion across your chest. B0059KO05 The seat belt automatically adjusts to the To fasten your seat belt: proper length after the lap belt portion Pull the seat belt out of the retractor and is adjusted manually so that it fits snugly...
Page 70 Seats & Safety System Height adjustment You can adjust the height of the shoulder belt anchor to one of the four different positions for maximum comfort and safety. The shoulder portion should be adjusted so it lies across your chest and midway over your shoulder nearest the door, not over your neck.
Page 71 Rear Seat Belt – Passenger’s 3point system with convertible locking retractor This type of seat belt combines the features of both an emergency locking retractor seat belt and an automatic locking retractor seat belt. Convertible retractor type seat belts are installed in the rear seat positions to help accommodate the installation of child restraint systems.
Page 72 Seats & Safety System Second row center seatbelt Rear center seatbelt (3 row) (3-point rear center seat belt) B0059KO08 B0059KO12 To fasten your seatbelt: 1. Take out the buckle , which is stored 1. Extract the tongue plate from the between the seat/seatback cushions.
Page 73 B0059KO10 B0059KO13 3. Pull out the tongue plate from the To release your seatbelt: pocket. Pull the tongue plate 1. Press the release button on the buckle insert it into the buckle until an and remove the tongue plate audible "click" is heard, indicating the latch is locked.
Page 74 Seats & Safety System Stowing the rear seat belt B0059KO17 Routing the seat belt webbing through B0059KO15 the rear seat belt guides will help keep the belts from being trapped behind or under the seats. After inserting the seat belt, tighten the belt webbing by pulling it up.
Page 75 This must be done by an the frontal or side collision(s) is severe authorized HYUNDAI dealer. enough, together with the air bags. Do not hit the seat belt assemblies. When the vehicle stops suddenly, or if...
Page 76 B0702EU01 body. SRS air bag warning light In this case, consult an authorized Retractor pre-tensioner HYUNDAI dealer. The air bag SRS control module warning light illuminates, if there is a malfunction with the pre-tensioner seat NOTICE belt system.
Page 77: Additional Seat Belt Safety Precautions
Additional Seat Belt Safety Seat belt use and children Precautions Infant and small children Seat belt use during pregnancy All 50 states have Child Restraint System laws which require children to travel The seat belt should always be used in approved Child Restraint System during pregnancy.
Page 78 Always have the LATCH system Do not lie down inspected by your authorized HYUNDAI Sitting in a reclined position when the dealer after an accident. An accident can vehicle is in motion can be dangerous.
Page 79: Care Of Seat Belts
The entire seat belt assembly or assemblies should be replaced if the vehicle has been involved in an accident. This should be done even if no damage is visible. Additional questions concerning seat belt operation should be directed to an authorized HYUNDAI dealer. 3-49...
Page 80: Child Restraint System (Crs)
You must use a commercially available adequate protection in an accident. Child Restraint System that meets the After an accident, have a HYUNDAI requirements of the Federal Motor dealer check the child restraint Vehicle Safety Standards (FMVSS 213).
Page 81: Selecting A Child Restraint System (Crs)
Selecting a Child Restraint The harness system holds the child in place, and in an accident, acts to keep System (CRS) the child positioned in the Child Restraint When selecting a Child Restraint System Systems and reduce the stress to the for your child, always: fragile neck and spinal cord.
Page 82: Installing A Child Restraint System (Crs)
Seats & Safety System Installing a Child Restraint System (CRS) WARNING Before installing your Child Restraint System always: Read and follow the instructions provided by the manufacturer of the Child Restraint System. B0065KO02 Read and follow the instructions Forward-facing Child Restraint System regarding child restraint systems in A forward-facing Child Restraint System this manual.
Page 83 Make sure the Child Restraint System Lower Anchors and Tether for is firmly secured. After installing a Children (LATCH System) Child Restraint System to the vehicle, The LATCH system holds a Child push and pull the seat forward and Restraint System during driving and in from side-to-side to verify that it is an accident.
Page 84 (e.g. toy, pen, wire) around the lower anchor area. Those objects may damage either the seat belt system or the Child Restraint System during the installment procedure. If necessary, have the vehicle inspected by an authorized HYUNDAI dealer. 3-54...
Page 85 Always have the LATCH system inspected by your authorized HYUNDAI dealer after an accident. An accident can damage the LATCH system and may not properly secure the child restraint.
Page 86 Seats & Safety System WARNING Take the following precautions when installing the tether strap: Read and follow all installation instructions provided with your Child Restraint System. NEVER attach more than one Child Restraint System to a single tether anchor. This could cause the anchor or attachment to come loose or B0065KO08 break.
Page 87 Securing a Child Restraint System with a lap/shoulder belt When not using the LATCH system, all Child Restraint Systems must be secured to a rear seat with the lap part of a lap/ shoulder belt. WARNING ALWAYS place a rearward-facing Child B0065KO08 Restraint System in the rear seat of the Automatic locking mode...
Page 88 Seats & Safety System B0065KO03 B0065KO05 2. Fasten the lap/shoulder belt latch 4. Slowly allow the shoulder portion of into the buckle. Listen for the distinct the seat belt to retract and listen for “click” sound. an audible "clicking" or "ratcheting" sound.
Page 89 Information When the seat belt is allowed to retract to its fully stowed position, the retractor will automatically switch from the “Automatic Locking” mode to the emergency lock mode for normal adult usage. WARNING If the retractor is not in the “Automatic B0065KO06 Locking”...
Page 90 Seats & Safety System The actual air bags in the vehicle may differ from the illustration. A0066EU01 1. Driver’s front air bag 4. Curtain air bag 2. Passenger’s front air bag 5. Driver’s knee air bag 3. Side air bag 3-60...
Page 91 The vehicles are equipped with an Advanced Supplemental Air Bag System for the driver’s seat and front passenger’s seats. The front air bags are designed to supplement the three-point seat belts. For these air bags to provide protection, the seat belts must be worn at all times when driving. You can be severely injured or killed in an accident if you are not wearing a seat belt.
Page 92: Where Are The Air Bags
Seats & Safety System Where Are the Air Bags? The SRS consists of air bags which are located in the center of the steering Driver’s and passenger’s front air wheel, in the driver’s side lower crash bags pad below the steering wheel, and the passenger’s side front panel pad above the glove box.
Page 93 Side air bags WARNING To reduce the risk of serious injury or death from inflating front air bags, take the following precautions: Seat belts must be worn at all times to help keep occupants positioned properly. Move your seat as far back as possible from front air bags, while still maintaining control of the vehicle.
Page 94 If the seat or seat cover is damaged, to help keep occupants positioned have the vehicle checked and properly. repaired by an authorized HYUNDAI dealer. Do not allow passengers to lean their heads or bodies onto doors, put their arms on the doors, stretch their arms out of the window, or place objects between the doors and seats.
Page 95 Curtain air bags The side and/or curtain air bags and pre- tensioners on both sides of the vehicle may deploy if a rollover or possible rollover is detected. The curtain air bags are not designed to deploy in all side impact or rollover situations.
Page 96: How Does The Air Bags System Operate
Seats & Safety System How Does the Air Bags System The SRSCM (Supplemental Restraint System Control Module) continually Operate? monitors all SRS components while the ignition switch is ON to determine if a crash impact is severe enough to require air bag deployment or pre-tensioner seat belt deployment.
Page 97 Air bags inflate in the event of certain Have an authorized HYUNDAI dealer frontal or side collisions to help inspect the SRS as soon as possible if protect the occupants from serious any of these conditions occur.
Page 98 Seats & Safety System In addition to inflating in serious side WARNING collisions, vehicles equipped with a To reduce the risk of serious injury or rollover sensor, side and curtain air death from an inflating air bag, take the bags will inflate if the sensing system following precautions: detects a rollover.
Page 99 B0074EE06 B0074EE04 A : Driver’s front air bag (1) When the SRSCM detects a sufficiently severe impact to the front of the vehicle, it will automatically deploy the front air bags. B0074EE07 C : Driver’s front air bag (3) D : Passenger’s front air bag After complete inflation, the air bag immediately starts deflating, enabling the driver to maintain forward visibility...
Page 100: What To Expect After An Air Bag Inflates
Always wash exposed skin areas thoroughly with cold water and mild soap. Always have an authorized HYUNDAI dealer replace the air bag immediately after deployment. Air bags are designed to be used only once. B0073EU01 Your vehicle is equipped with an Occupant Classification System (OCS) in the front passenger’s seat.
Page 101 Main components of the Occupant You will find the “PASSENGER AIR BAG OFF” indicator on the overhead console Classification System panel. This system detects the conditions A detection device located within the 1-4 in the following table and activates or front passenger seat cushion.
Page 102 Seats & Safety System Condition and operation in the front passenger Occupant Classification System Indicator/Warning light Devices Condition detected by the “PASSENGER SRS warning Front passenger occupant classification system AIR BAG OFF” light air bag indicator light 1. Adult Activated 2.
Page 103 WARNING Riding in an improper position or placing weight on the front passenger’s seat when it is unoccupied by a passenger adversely affects the OCS. To reduce the risk of serious injury or death: NEVER put a heavy load in the front seat or seatback pocket, or hang any items on the front passenger seat.
Page 104 Do not place any items under the front passenger seat. When changing or replacing the seat or seat cover, use original items only. The OCS has been developed based on using original HYUNDAI car seats only. Altering or changing the authentic parts may result in system malfunction and increase risk of injury when in collision.
Page 105 WARNING NEVER allow an adult passenger to ride in the front passenger seat when the “PASSENGER AIR BAG OFF” indicator is illuminated. During a collision, the air bag will not inflate if the indicator is illuminated. Have your passenger reposition themselves in the seat. If the “PASSENGER AIR BAG OFF”...
Page 106: Why Didn't My Air Bag Go Off In A Collision
Do not install bumper guards or Always properly restrain children in replace the bumper with a non- an appropriate child restraint in the genuine HYUNDAI parts. This may rear seat of the vehicle. adversely affect the collision and air bag deployment performance.
Page 107 A0076EU02 SRS control module / Rollover sensor Side impact sensor (Acceleration) Front impact sensor Side impact sensor (Acceleration) Side impact sensor (Pressure) 3-77...
Page 108 Seats & Safety System Air bag inflation conditions B0076EU03 B0076EU02 Front air bags Front air bags are designed to inflate in a frontal collision depending on the severity of impact of the front collision. B0076EU04 Side and curtain air bags Side and curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the...
Page 109 Air bag non-inflation conditions B0076EU06 Front air bags may not inflate in side B0076EU02 impact collisions, because occupants In certain low-speed collisions the air move in the direction of the collision, bags may not deploy. The air bags are and thus in side impacts, front air bag designed not to deploy in such cases deployment would not provide additional because they may not provide benefits...
Page 110 Seats & Safety System B0076KO08 B0076KO10 In an angled collision, the force of impact Front air bags may not inflate in may direct the occupants in a direction rollover accidents because front air bag where the air bags would not be able to deployment would not provide additional provide any additional benefit, and thus occupant protection.
Page 111: Srs Care
Clean the air bag pad covers with HYUNDAI dealer. Improper handling of a soft cloth moistened with plain the SRS system may result in serious water. Solvents or cleaners could personal injury.
Page 112: Additional Safety Precautions
Modifications to accommodate disabilities. If you require modification to your vehicle to accommodate a disability, contact the HYUNDAI Customer Connect Center at 800-633- 5151. Adding equipment to or modifying your air bag equipped vehicle If you modify your vehicle by changing your vehicle’s frame, bumper system,...
Page 113: Instrument Cluster
4. Instrument Cluster Instrument cluster .................... 4-4 Instrument Cluster Control ..................4-5 Instrument panel illumination ...................4-5 Gauges and Meters ..................... 4-6 Speedometer ......................4-6 Tachometer ....................... 4-6 Engine coolant temperature gauge ................4-7 Fuel gauge ........................4-7 Outside temperature gauge ..................4-8 Odometer ........................
Page 114 Downhill Brake Control (DBC) indicator light ............4-20 AUTO STOP indicator light ..................4-21 Turn signal indicator light ..................4-21 High beam indicator light ..................4-21 Low beam indicator light ..................4-21 Light ON indicator light ....................4-21 High Beam Assist indicator light ................4-22 AUTO HOLD indicator light ..................4-22 LCD Display Messages ....................4-22 Vehicle is on ......................4-22 Shift to P ........................4-22...
Page 115 4. Instrument Cluster LCD Display ..................... 4-28 LCD Display Control ....................4-28 View Modes ........................4-29 Trip computer mode ....................4-30 Turn By Turn (TBT) mode ..................4-30 Driving Assist mode ....................4-31 Trip Computer (Type A) ....................4-32 Trip modes ........................4-32 Trip Computer (Type B) ....................4-34 Trip modes ........................4-34 Vehicle Settings (infotainment system) ............
Page 116: Instrument Cluster
Instrument Cluster INSTRUMENT CLUSTER The actual cluster in the vehicle may differ from the illustration. For more information, refer to “Gauges and meters” section in this chapter. A0084EU01/ A0084EU03 1. Tachometer 4. Fuel gauge 2. Speedometer 5. Warning and indicator lights 3.
Page 117: Instrument Cluster Control
Instrument Cluster Control WARNING Instrument panel illumination Never adjust the instrument cluster while driving. This could result in loss of control and lead to an accident that may cause death, serious injury, or vehicle damage. Information For safety reasons, the brightness of the instrument cluster lighting cannot not be adjusted below a certain level.
Page 118: Gauges And Meters
Instrument Cluster Gauges and Meters Tachometer Speedometer B0086EU03 B0086EU01 B0086EU05 The tachometer indicates the B0086EU02 approximate number of engine The speedometer indicates the speed of revolutions per minute (RPM). the vehicle and is calibrated in miles per hour (MPH) and/or kilometers per hour Use the tachometer to select the correct (km/h).
Page 119: Engine Coolant Temperature Gauge
Engine coolant temperature gauge Fuel gauge B0086EU07 B0086EU09 B0086EU08 B0086EU10 This gauge indicates the temperature This gauge indicates the approximate of the engine coolant when the ignition amount of fuel remaining in the fuel tank. switch is in the ON position. Information NOTICE The fuel tank capacity is given in...
Page 120: Outside Temperature Gauge
Instrument Cluster Outside temperature gauge WARNING Running out of fuel can expose vehicle occupants to danger. You must stop and obtain additional fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the “E (Empty)”...
Page 121: Odometer
Odometer Distance to empty B0086EU20 B0086EU15 B0086EU19 B0086EU21 The odometer indicates the total The distance to empty is the distance that the vehicle has been estimated distance the vehicle can be driven and should be used to determine driven with the remaining fuel. when periodic maintenance should be If the estimated distance is below performed.
Page 122: Transmission Shift Indicator
Instrument Cluster Fuel economy (for type B cluster) Transmission Shift Indicator Automatic transmission shift indicator B0086EU22 The average fuel economy and instant fuel economy is displayed at the B0086EU13 bottom of the cluster. Automatic reset To automatically reset the average fuel economy, select between "After Ignition"...
Page 123: Warning And Indicator Lights
Have the vehicle If this occurs, have the vehicle inspected by an authorized HYUNDAI inspected by an authorized HYUNDAI dealer. dealer. 4-11...
Page 124: Anti-Lock Brake System (Abs) Warning Light
These two warning lights illuminate at the same time while driving: In this case, have the vehicle inspected by an authorized HYUNDAI dealer. When the ABS and regular brake system may not work normally. In this case, have the vehicle inspected by an authorized HYUNDAI dealer.
Page 125: Motor Sriven Power Steering (Mdps) Warning Light
If this occurs, have the vehicle Have the vehicle inspected by an inspected by an authorized HYUNDAI authorized HYUNDAI dealer as soon as dealer. possible. Charging system warning Information - Electronic Brake light...
Page 126: Engine Oil Pressure Warning Light
HYUNDAI dealer as soon as possible. Continued driving with the warning Low fuel level warning light light on may cause engine failure.
Page 127: Malfunction Indicator Lamp (Mil)
- Blind-spot Collision Warning the engine or the vehicle powertrain. malfunction (if equipped) If this occurs, have the vehicle - Blind-spot Collision Warning radar inspected by an authorized HYUNDAI blocked (if equipped) dealer. - LED headlight malfunction (if equipped) NOTICE...
Page 128: Electronic Parking Brake (Epb) Warning Light
When there is a malfunction with the not indicate malfunction of EPB. TPMS. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. For more details, refer to “Tire Pressure Monitoring System (TPMS)” section in chapter 8.
Page 129: Forward Safety Warning Light
Assist is operating operating If this occurs, have the vehicle inspected If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer as by an authorized HYUNDAI dealer as soon as possible. soon as possible. For more details, refer to “Forward For more details, refer to “Forward...
Page 130: Lane Safety Indicator Light
All Wheel Drive (AWD) LED headlight related part. warning light (if equipped) If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer as This warning light illuminates: soon as possible. Whenever there is a malfunction with the AWD system.
Page 131: Icy Road Warning Light
ESC system. You can activate or deactivate the Icy If this occurs, have the vehicle Road Warning function from the Settings inspected by an authorized HYUNDAI menu in the instrument cluster or dealer as soon as possible. infotainment system. Select:...
Page 132: Immobilizer Indicator Light
This indicator light illuminates for 2 If this occurs, have the vehicle inspected seconds and goes off: by an authorized HYUNDAI dealer as If the smart key is in the vehicle and the soon as possible. ignition switch is ON, but the vehicle For more details, refer to "Downhill Brake...
Page 133: Auto Stop Indicator Light
ISG function. - The turn signal indicator light If this occurs, have the vehicle inspected illuminates but does not blink by an authorized HYUNDAI dealer as - The turn signal indicator light blinks soon as possible. rapidly For more details, refer to "ISG (Idle Stop...
Page 134: High Beam Assist Indicator Light
Low key battery (for smart key If this occurs, have the vehicle system) inspected by an authorized HYUNDAI dealer as soon as possible. This message is displayed if the battery of the smart key is discharged while For more details, refer to “Electronic changing the ignition switch to the OFF Parking Brake (EPB)”...
Page 135: Press Brake Pedal To Start Engine
Engine Start/Stop button was pressed. If this occurs, attempt to start the engine by pressing the Engine Start/Stop button again. If the warning message appears each time you press the Engine Start/Stop button, have your vehicle inspected by an authorized HYUNDAI dealer. 4-23...
Page 136: Battery Discharging Due To External Electrical Devices
HYUNDAI dealer. Engine Start/Stop button. To start the vehicle, place a registered digital key on Press START button with key...
Page 137: Door, Hood, Liftgate Open Indicator
Door, Hood, Liftgate open indicator Sunroof open indicator (if equipped) B0088KO01 B0088KO02 This warning is displayed if any door or This warning is displayed if you turn off hood or liftgate is left open. The warning the engine when the sunroof is open. will indicate which door is open in the Close the sunroof securely before leaving display.
Page 138: Lights
Instrument Cluster Lights Wiper B0088EU04 B0088EU05 This indicator displays which exterior light is selected using the lighting control. You can activate or deactivate Wiper/ Lights display function from the Settings menu in the infotainment system. Select: Information B0088EU06 A : Front, B : Rear The infotainment system may change after software updates.
Page 139: Low Washer Fluid
31~62 miles (50~100 km) the vehicle inspected by an authorized after the engine warms up, the warning HYUNDAI dealer. message should disappear. If the warning message remains on, have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. 4-27...
Page 140: Instrument Cluster
Instrument Cluster LCD DISPLAY LCD Display Control B0090KO01 The LCD display modes can be changed by using the control buttons. Switch Function MODE button for changing modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item Information If equipped with an infotainment system, only the Settings menu in the infotainment system is supported and not the instrument cluster.
Page 141: View Modes
View Modes View modes Symbol Explanation This mode displays the state of : - Lane Keeping Assist - Smart Cruise Control Driving Assist - Highway Driving Assist For more information, refer to "Lane Keeping Assist (LKA)", "Smart Cruise Control (SCC)", "Highway Driving Assist (HDA)"...
Page 142 Instrument Cluster Trip computer mode Turn By Turn (TBT) mode B0091EU04 B0091KO03 Turn-by-turn navigation, distance/time to destination information is displayed when Turn by Turn view is selected. B0091EU05 The trip computer mode displays information related to vehicle driving parameters including fuel economy, tripmeter information and vehicle speed.
Page 143 Driving Assist mode B0091EU12 Tire Pressure B0091KO02 This mode displays information related to LKA/SCC/HDA Tire Pressure. This mode displays the state of Lane For more details, refer to "Tire Pressure Keeping Assist, Smart Cruise Control, Monitoring System (TPMS)" in chapter 8. and Highway Driving Assist.
Page 144: Trip Modes
Instrument Cluster Trip Computer (Type A) The trip computer is a microcomputer- controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example, Average Vehicle Speed) resets if the battery is B0090KO01 disconnected.
Page 145 B0802EU01 B0802EU03 Drive info Accumulated info Trip distance , total driving time Accumulated trip distance , total average fuel economy are displayed. driving time and average fuel economy are displayed. The information is combined for each ignition cycle. However, when the engine The information is accumulated starting has been OFF for 3 minutes or longer the from the last reset.
Page 146: Trip Computer (Type B)
Instrument Cluster Trip Computer (Type B) The trip computer is a microcomputer- controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example, Average Vehicle Speed) resets if the battery is B0090KO01 disconnected.
Page 147 B0803EU01 B0803EU03 Drive info Accumulated info Trip distance , total driving time Accumulated trip distance , total average fuel economy are displayed. driving time and average fuel economy are displayed. The information is combined for each ignition cycle. However, when the engine The information is accumulated starting has been OFF for 3 minutes or longer the from the last reset.
Page 148 Instrument Cluster B0802EU05 Digital speedometer Digital speedometer display shows the speed of the vehicle. 4-36...
Page 149: Setting Your Vehicle
Setting Your Vehicle B0094EU01 Vehicle Settings in the infotainment B0095KO01 system provides user options for a 1. Press the SETUP button on the head variety of settings including door lock/ unit of the infotainment system. unlock features, convenience features, driver assistance settings, etc. Vehicle Settings menu - Driver Assistance - Drive Mode...
Page 150: Convenience Features
Accessing Your Vehicle ..................5-5 Using Remote Key ......................5-5 Using Smart Key ......................5-8 Immobilizer System ....................5-17 Hyundai Digital Key ..................5-18 Digital key (smartphone) ................... 5-18 Digital key (Card key) ....................5-23 Used Vehicle/Digital Key Maintenance ..............5-28 Limitations of the System ..................5-28 Door Locks .......................
Page 151 Windows ......................5-66 Power Windows ......................5-67 Panoramic Sunroof ..................5-71 Power Sunshade ......................5-71 Tilt Open/Close......................5-72 Slide Open/Close ....................... 5-72 Automatic Reversal ....................5-73 Resetting the Sunroof ....................5-74 Sunroof Open Warning ....................5-75 Dual Sunroof ....................5-76 Hood ........................ 5-82 Opening the Hood ......................5-82 Closing the Hood ......................5-82 Liftgate......................
Page 152 5. Convenient Features Exterior Lights ....................5-98 Lighting Control......................5-98 High Beam Operation ....................5-99 Turn Signals and Lane Change Signals ..............5-100 Battery Saver Function .....................5-101 Headlight Delay Function ..................5-101 High Beam Assist (HBA) ................5-102 High Beam Assist Settings ..................5-102 High Beam Assist Operation ..................
Page 153 Climate Control Additional Features ............5-150 Auto Defogging System ................... 5-150 Auto Dehumidify ....................... 5-151 Recirculating Air When Washer Fluid Is Used ............5-151 Sunroof Inside Air Recirculation ................5-152 Scheduled Ventilation Control .................5-152 Storage Compartment ................... 5-153 Center Console Storage ....................5-153 Glove Box ........................5-153 Interior Features .....................5-154 Cup Holder ........................
Page 154: Accessing Your Vehicle
The priority for unlocking the driver door B0921EU02 only, or unlocking all the doors with Your HYUNDAI uses a remote key, which one press may be adjusted in the User you can use to lock or unlock the driver Settings mode in the cluster LCD display.
Page 155 Convenience Features The Two Press Unlock feature can also be Start-up enabled or disabled by pressing the door For detailed information refer to “Ignition lock and unlock buttons simultaneously switch” in chapter 6. on the Key: Press and hold both the Door Lock NOTICE button and the Door Unlock button To prevent damaging the remote key:...
Page 156 If you have a problem with the remote key, it is recommended that you contact an authorized HYUNDAI dealer. If the remote key is in close proximity to your mobile phone, the signal could be blocked by your mobile phone’s normal operational signals.
Page 157: Using Smart Key
HYUNDAI dealer. B0096EU02 Your HYUNDAI maybe equipped with a smart key, which you can use to lock or WARNING unlock the doors and liftgate, and start...
Page 158 Locking your vehicle (Button type) Locking your vehicle (Touch sensor type) B0097KO01 To lock your vehicle using the door B0097EU02 handle button or the Smart Key: 1. Make sure that all doors are closed. 1. Make sure all doors, the hood and the 2.
Page 159 Convenience Features Note that if you press the outside door Unlocking your vehicle (Button type) handle to lock the doors using the touch sensor, the doors will not lock under the following circumstances: The Smart Key is in the vehicle The Engine Start/Stop button is in the ACC or ON position Any of the doors are open (except for...
Page 160 Unlocking your vehicle (Touch To prevent unintentional door lock or unlock: sensor type) Press the lock button on the smart key and immediately press the unlock button along with the lock button for more than 4 seconds. The hazard warning lights will blink four times.
Page 161 Convenience Features Opening the liftgate Remotely starting vehicle (if equipped) Non-power liftgate You can start the vehicle using the To unlock and open the liftgate: Remote Start button on the smart key. 1. Make sure you have the smart key in To start the vehicle remotely: your possession.
Page 162 Remote Smart Parking Assist Information Feature (if equipped) Laws in your country may restrict the Some models are equipped with Remote use of remote start. You should check Smart Parking Assist Feature. With the country regulations before using this Smart Key, the vehicle can be moved remote starting system.
Page 163 Convenience Features Start-up (if equipped) Information Some models are equipped with a push If the smart key is not moved for some button start instead of a key cylinder. time, the detection function for smart key You can leave your Smart Key in your operation will pause.
Page 164 To remove the mechanical key from the HYUNDAI dealer or tow the vehicle, if smart key: necessary. Smart key precautions The smart key may not work if any of the...
Page 165 Operation is subject to the following three it is recommended that you contact an conditions: authorized HYUNDAI dealer. 1. This device may not cause harmful interference. WARNING 2. This device must accept any...
Page 166: Immobilizer System
If the system repeatedly does not recognize the coding of the key, it is recommended that you contact your HYUNDAI dealer. Do not attempt to alter this system or add other devices to it. Electrical problems could result that may make your vehicle inoperable.
Page 167: Digital Key (Smartphone)
Smartphone Key’. Depending on the availability of service on the vehicle, some functions may not Digital Key’ from the My Hyundai App operated. in the smart phone, register the digital key according to the guidance in the Setting your smart phone smart phone screen.
Page 168 Information If you want to register a digital key (smart phone) again, refer to ‘How to Delete Digital Key (Smart Phone)’ and delete the digital key (smart phone) before re-registering. During the digital key saving process, the process will cancel when: - The smart phone is removed from the vehicle authentication pad (wireless B0901KO07...
Page 169 Convenience Features Using the digital key (smart phone) The driver can lock or unlock the door by placing the smart phone on the outside door handle, and the vehicle can be started by placing the smart phone on the vehicle authentication pad (wireless charging pad).
Page 170 Locking/Unlocking the doors Starting the vehicle - If the driver places the digital key After placing your registered digital (smart phone) NFC antenna to the key (smart phone) on the vehicle driver’s or passenger’s door handle authentication pad (wireless charging authentication pad for more than 2 pad), depress the brake pedal and press...
Page 171 Convenience Features Deleting your digital key (smart phone) Turn on the vehicle with a smart key. Have your smart key with you in the vehicle. B0901EU05 Deleting my registered digital key (smart phone) To delete only my registered digital key (smart phone), from the Settings menu B0901EU05 Delete’...
Page 172: Digital Key (Card Key)
Digital key (Card key) How to register Digital Key (Card Key) To use the card key as a digital key, follow the following procedure. 1. Have both of your smart keys with you in the vehicle. B0901KO02 Vehicle authentication pad (Wireless charging pad) 3.
Page 173 Convenience Features Using the digital key (card key) Information The driver can lock or unlock the door by You cannot lock your vehicle using placing the card key on the outside door the digital key (Card key) if any of the handle, and the vehicle can be started following occurs: by placing the card key on the vehicle...
Page 174 NOTICE Deleting your digital key (card key) 1. Turn on the vehicle with a smart key. The digital key (card key) may not Have your smart key with you in the work under the following conditions: vehicle. - The digital key (card key) is not placed on the door handle authentication pad or vehicle authentication pad (wireless...
Page 175 Convenience Features Linking/Unlinking profile Vehicle personalization operation How to link user profile The personalization function linked with digital key works when the profile linked smart phone is placed on the outside door handle authentication (Smartphone)’ from the Settings menu pad to lock or unlock the doors. in the infotainment system.
Page 176 Vehicle personalization with digital key The available personalization function in the vehicle is as follows: System Personalization Item Lamp Blink number of one-touch signal lamps Information display on the cluster, Voice volume, Cluster Welcome sound Seat position, Side view mirror position, Easy Access Infotainment system vehicle Seat/Mirror...
Page 177: Used Vehicle/Digital Key Maintenance
Convenience Features Used Vehicle/Digital Key Limitations of the System Maintenance Hyundai digital key may not operate if Purchasing used vehicle any of the following occurs: - The smart phone battery or the If any of the digital key devices (smart...
Page 178: Door Locks
DOOR LOCKS After removing the cover, turn the key toward the front of the vehicle to unlock Outside the Vehicle and toward the rear of the vehicle to Mechanical key lock. If you lock the driver’s door with a mechanical key, the driver’s door will lock.
Page 179 Convenience Features Remote key Smart key Button type B0115EU06 To lock the doors, press the Door Lock B0097KO01 button on the remote key. To lock the doors, press the button on Press the Door Unlock button on the the outside door handle while carrying remote key, the driver's door will unlock.
Page 180 Touch type Information During a car wash or rain, in order to minimize unintentional operation of the touch sensor, the touch sensor may become insensitive. This is not a malfunction. In cold and wet climates, door lock and door mechanisms may not work properly due to freezing conditions.
Page 181 Convenience Features Information Inside the Vehicle If a power door lock ever fails to function With the door handle while you are in the vehicle try one or more of the following techniques to exit: Operate the door unlock feature repeatedly (both electronic and manual) while simultaneously pulling on the door handle.
Page 182 With the central door lock switch In case of an emergency B0111KO03 B0115EU03 In case of emergency such as when the battery is discharged, the only way to lock the door(s) is with the mechanical key from the outside key hole. Doors without an outside key hole can be locked as follows: 1.
Page 183 Convenience Features Automatic Door Lock and Unlock WARNING Do not leave children or animals Your vehicle is equipped with features unattended in your vehicle. An enclosed that will automatically lock or unlock vehicle can become extremely hot, your vehicle based on settings you select causing death or serious injury to in the infotainment system.
Page 184: Child-Protector Rear Door Locks
Auto UNLOCK On key out (if Child-Protector Rear Door Locks equipped with remote key) (if equipped) When this feature is set, all the doors will be unlocked automatically when the ignition key is removed from the key ignition switch. Auto UNLOCK Vehicle off (if equipped with smart key) When this feature is set, all the doors will be unlocked automatically when the...
Page 185: Electronic Child Safety Lock
Convenience Features Electronic Child Safety Lock (if If 3 minutes passes after the ignition switch or Engine Start/Stop button is equipped) pressed to the LOCK/OFF or ACC, the indicator on the button turns off, and the driver cannot turn off electronic child safety lock by pressing the button.
Page 186 If the Electronic child safety lock system is not operated when pushing the Electronic child safety lock switch, the message is displayed and the alarm will sound. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. 5-37...
Page 187 Convenience Features This system helps to protect your vehicle Information and valuables. The horn will sound and Do not lock the doors until all the hazard warning lights will blink passengers have left the vehicle. If the continuously if any of the following remaining passenger leaves the vehicle occur: when the system is armed, the alarm...
Page 188: System Setting
Rear Occupant Alert is provided to help System Operation prevent the driver from leaving the First alert vehicle with the rear passenger left in the When you open the front door after vehicle. opening and closing the rear door and turning off the engine, the ‘Check rear System Setting seats’...
Page 189: System Precautions
Convenience Features System Precautions WARNING Make sure that all the windows are Even if your vehicle is equipped with closed. If the window is open, the Rear Occupant Alert, always make sure alert may operate by the sensor to check the rear seat before you leave detecting an unintended movement the vehicle.
Page 190: Storing Memory Positions
If the battery is disconnected, the memory settings will be erased. If the Integrated Memory System does not operate normally, have the system inspected by an authorized HYUNDAI dealer. Storing Memory Positions B0122KO01 1. Shift to P (Park) while the Ignition The IMS, or Integrated Memory System, switch is in the ON position.
Page 191: Recalling Memory Positions
Convenience Features Recalling Memory Positions Resetting the System 1. Shift to P (Park) while the Ignition Follow the below procedures to reset the switch is in the ON position. Integrated Memory System (IMS) if it is not operating properly: 2. Press the desired memory button (1 or 2).
Page 192: Seat Easy Access
NOTICE Entering the vehicle: The driver’s seat, steering wheel and While integrated memory system seat bolster will move as follows when is being reset, if the resetting the ignition switch is placed to the and notification sound stops ACC, ON or START position or while incompletely, restart the resetting carrying the smart key, the driver’s procedure again.
Page 193: Steering Wheel
LOCK/OFF position. require increased steering efforts. Take Motor noise may be heard when the your vehicle to an authorized HYUNDAI vehicle is at a stop or at a low driving dealer or to a service station and have speed.
Page 194: Tilt/Telescopic Steering
Tilt/Telescopic Steering Manual adjustment When adjusting the steering wheel to a comfortable position, adjust the steering wheel so that it points toward your chest, not toward your face. Make sure you can see the instrument cluster warning lights and gauges. After adjusting, push the steering wheel both up and down to be certain it is locked in position.
Page 195: Horn
Convenience Features Horn Heated Steering Wheel (if equipped) B0133KO00 To sound the horn, press the area B0132KO01 indicated by the horn symbol on your When the Ignition switch or Engine steering wheel (see illustration). The Start/Stop button is in the ON position horn will operate only when this area is or when the engine is running, press the pressed.
Page 196: Mirrors
MIRRORS Inside Rearview Mirror Day/night rearview mirror (if equipped) Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING Make sure your line of sight is not obstructed.
Page 197 Convenience Features Electrochromic Mirror Electrochromic mirror (ECM) with (if equipped) HomeLink® system (if equipped) Your vehicle may be equipped with a Gentex Automatic-Dimming Mirror with an Integrated HomeLink® Wireless Control System. During nighttime driving, this feature will automatically detect and reduce rearview mirror glare.
Page 198 Automatic-Dimming Night Vision Safety™ WARNING (NVS ) Mirror (if equipped) ® The NVS® Mirror automatically helps garage door opener or gate operator, reduce glare by monitoring light levels in make sure people and objects are out the front and the rear of the vehicle. Any of the way of the device to prevent object that obstructs either light sensor potential harm or damage.
Page 199 Convenience Features Visit the HomeLink website at: www. 2. It is recommended that a new battery homelink.com. Then at the top of the be placed in the handheld transmitter page, choose your vehicle make. Then of the device being programmed to watch the You Tube video, and/or HomeLink for quicker training and access additional website information.
Page 200 3. While the HomeLink indicator light is flashing orange, press and hold the hand-held remote button. Continue pressing the handheld remote button until the HomeLink indicator light light changes from orange to green. You may now release the handheld remote button. 4.
Page 201 Convenience Features 3) Two-Way Communication 2. On your garage door opener in your Programming (For select garage door garage, locate the “Learn” button openers) (usually near where the hanging antenna wire is attached to the garage If your garage door opener has the door opener).
Page 202 4) Canadian Programming Information Canadian radio-frequency laws require The HomeLink indicator should transmitter remote signals to “time- light green, solid or flashing, and your out” (or quit) after a couple seconds of programmed device should operate. transmission, which may not be long If your device does not operate, the enough for HomeLink to pick up the signal HomeLink programming was not...
Page 203 Convenience Features If the indicator flashes in Orange, 3. Erasing HomeLink® Buttons it indicates that the garage door is 1) Erasing and Reprogramming a Single “Closing”. HomeLink® Button: The indicator turns solid green once 1. Press and hold the desired HomeLink the garage door has closed.
Page 204 FCC (Htats-Unis) et ISED (Canada) Information Cet appareil est conforme aux HomeLink and the HomeLink House ® ® règlements de la FCC, section 15, et logo are registered trademarks of Gentex au CNR-210 d’Innovation, Sciences et Corporation. Dhveloppement économique Canada. Le The myQ logo is a registered trademark of fonctionnement est assujetti aux deux The Chamberlain Group, Inc.
Page 205 Convenience Features HomeLink 5 Programing Flow Chart OOS040475N 5-56...
Page 206: Side View Mirrors
Side View Mirrors WARNING Do not adjust or fold the side view mirrors while driving. This may cause loss of vehicle control resulting in an accident. NOTICE Do not scrape ice off the mirror face; this may damage the surface of the glass.
Page 207 Convenience Features Adjusting the side view mirrors Folding the side view mirrors B0136EU01 B0136EU05 Adjusting the side view mirrors To fold the side view mirror, grasp the housing of the mirror and then fold it 1. Move the lever either to the L (left toward the rear of the vehicle.
Page 208: Reverse Parking Aid
Reverse Parking Aid (if equipped) Reverse parking aid user settings mode You may change the angle of the side view mirror if it is difficult to see the rear view with the basic downward mirror angle provided when reversing. When the vehicle is first delivered, the set downward angle of the left and right side view mirror are different to ensure driver visibility.
Page 209 Digital Center Mirror, stop using the system immediately. Have you see an authorized HYUNDAI dealer for servicing. B0362KO01 If the camera lens is dirty, the displayed image may not be clear.
Page 210: System Component
System component How to change the mode ONE1052295N ONE1052296 1. Icon display area The mode can be switched when the switch is in the ON position. Displays icons, adjusting Brightness & Tilt 1. Pull the mode select lever to all the way switch to the Digital Center Mirror 2.
Page 211 Convenience Features Adjusting the mirror height Display settings (Digital mirror mode) B0913EU03 The height of the rearview mirror can be B0913EU01 adjusted to suit your driving posture. 1. Press the menu button . The icons will be displayed. Change to optical mirror mode, adjusting the rearview mirror angle by moving it up Icons Settings...
Page 212 When using the Digital Center Mirror in digital mirror mode When the liftgate is open, the Digital Center Mirror image may not display properly. Before driving, make sure the liftgate is closed. If the display is difficult to see due to reflected light, close the sunshade for the sunroof (if equipped).
Page 213 If this happens, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. Operating the system at the ON position while the engine is not running would cause discharging of the battery.
Page 214 If the icon does not disappear even to increase, the Digital though the mirror is cool, have the Center Mirror will turn off.) vehicle inspected by an authorized HYUNDAI dealer. If the display icon Change to optical mirror mode and have been switched...
Page 215: Windows
Convenience Features WINDOWS A0141EU01 Driver’s door power window switch Rear door (right) power window switch Front passenger’s door power window Window opening and closing switch Automatic power window Rear door (left) power window switch Power window lock switch/ Electronic child safety lock 5-66...
Page 216: Power Windows
Power Windows Window opening and closing The ignition switch or Engine Start/Stop button must be in the ON position to be able to raise or lower the windows. Each door has a Power Window switch to control that door’s window. The driver has a Power Window Lock button which can block the operation of rear passenger windows.
Page 217 If the power windows do not operate properly after resetting, have the system be inspected by an authorized HYUNDAI dealer. WARNING The automatic reverse feature doesn’t activate while resetting the power window system.
Page 218 Power window lock button Information The automatic reverse feature is only active when the “Auto Up” feature is used by fully pulling up the switch to the second detent. WARNING Make sure body parts or other objects are safely out of the way before closing the windows to avoid injuries or vehicle damage.
Page 219 Convenience Features Remote window opening function (if WARNING equipped) If you stay on the function after operating the Remote window opening function, it is likely to cause a theft. In addition, please use caution there might be a malfunction due to the inflow of water while raining.
Page 220: Power Sunshade
If your vehicle is equipped with a Power Sunshade sunroof, you can slide or tilt your sunroof with the sunroof switch located on the overhead console. B0904KO01 Use the sunshade to block direct sunlight coming through the sunroof glass. B0903EU01 Open or close the sunshade by hand.
Page 221: Tilt Open/Close
Convenience Features Tilt Open/Close Slide Open/Close B9022EU02 B9022EU03 Push the sunroof switch upward, the Push the sunroof switch rearward, sunroof glass tilts open. the sunshade and sunroof glass slide open. Push the sunroof switch forward when the sunroof glass is tilt opened, the Push the sunroof switch forward, only sunroof glass closes.
Page 222: Automatic Reversal
NOTICE Automatic Reversal Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor could occur. Continuous operations such as slide open/close, tilt open/close, etc. may cause the motor or sunroof system to malfunction.
Page 223: Resetting The Sunroof
Convenience Features Resetting the Sunroof 5. Once again push and hold the sunroof switch forward until the power sunshade and sunroof glass slide open and close. Do not release the switch until the operation is completed. If you release the switch during operation, start the procedure again from step 2.
Page 224: Sunroof Open Warning
Sunroof Open Warning CAUTION Make sure the sunroof is closed fully when leaving your vehicle. If the sunroof is left open, rain or snow may wet the interior of the vehicle. Also, leaving the sunroof open when the vehicle is unattended may invite theft. B0088KO02 If the driver turns off the engine when the sunroof is not fully closed, the...
Page 225 Convenience Features If your vehicle is equipped with a WARNING sunroof, you can slide or tilt your sunroof Adjust the sunroof or sunshade when with the sunroof switch located on the your vehicle stops. This could result overhead console. in loss of control and an accident that may cause injury, or property damage.
Page 226 Sunshade (Front)/Power sunshade (Rear) Use the sunshade to block direct sunlight coming through the sunroof glass. B0904KO03 Rear Push the power sunshade open switch , the power sunshade automatically slides open. B0904KO01 Push the power sunshade close switch Front , the power sunshade automatically closes.
Page 227 Convenience Features Tilt open/close (Front) Slide open/close (Front/Rear) B0905EU01 B0906EU01 Push the sunroof switch rearward, : Tilt open the sunshade and sunroof glass slide : Tilt close open. Push the sunroof switch upward, the Push the sunroof switch forward, only sunroof glass tilts open.
Page 228 NOTICE Automatic reversal Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor could occur. Continuous operations such as slide open/close, tilt open/close, etc. may cause the motor or sunroof system to malfunction.
Page 229 Convenience Features Resetting the sunroof Sunroof resetting procedure: 1. It is recommended to perform the reset procedure with the vehicle engine running. Start the vehicle in P (Park). 2. Make sure the sunroof glass is in the fully closed position. If the sunroof glass is open, push the switch forward until the sunroof glass is fully closed.
Page 230 Sunroof open warning B0088KO02 If the driver turns off the engine when the sunroof is not fully closed, the warning chime will sound for several seconds and the sunroof open warning will appear on the cluster LCD display. Close the sunroof securely when leaving your vehicle.
Page 231: Hood
Convenience Features HOOD Opening the Hood Closing the Hood 1. Before closing the hood, check in and around the engine compartment to ensure the following: - Any tools or other loose objects are removed from the engine room area or hood opening area - All gloves, rags, or other combustible material is removed from the engine compartment...
Page 232: Liftgate
Opening the Liftgate Closing the Liftgate B0909KO01 B0910KO01 Make sure the vehicle is in P (Park) and Lower the liftgate lid and press down set the parking brake. until it locks. To be sure the liftgate lid is securely fastened, always check by trying Then do one of the following: to pull it up again without pressing the 1.
Page 233: Emergency Liftgate Safety Release
Convenience Features Emergency Liftgate Safety WARNING Release B0911KO02 B0914KO01 Do not grab or hold on to the liftgate Your vehicle is equipped with the support struts at any time. Damage to emergency liftgate safety release lever the liftgate support struts could result. located on the bottom of the liftgate.
Page 234: Power Liftgate Operating Conditions
NOTICE Power Liftgate Operating Conditions Do not close or open the liftgate manually. This may cause damage to The power liftgate operates when the power liftgate. If it is necessary the gear is in P (Park) with the engine to close or open the liftgate manually running.
Page 235 If the liftgate is not fully closed and This must be done by an authorized vehicle speed is at or above 3 km/h (1.8 HYUNDAI dealer. mph), a warning will sound 10 times. Do not operate the power liftgate Immediately park the vehicle at a safe under the following conditions.
Page 236: Operating The Power Liftgate
Operating the Power Liftgate Power liftgate open/close button (Outside the power liftgate) Power liftgate open/close button (Smart key, Instrument panel) B0909KO01 When the liftgate is closed, press the B0912KO01 power liftgate open/close button to open the liftgate. If the vehicle is locked, press the power liftgate open/close button with the smart key in your possession.
Page 237: Setting The Power Liftgate
Convenience Features Automatic reverse Setting the Power Liftgate During power liftgate operation if the To use each feature, you must select the power liftgate senses any obstacle, opening speed or opening height from the liftgate will stop or will fully open. the settings menu.
Page 238: Resetting The Power Liftgate
If the liftgate stops before it is fully open, resetting cannot be completed. Information If the power liftgate does not operate properly after the above procedure, have the system inspected by an authorized HYUNDAI dealer. 5-89...
Page 239: Emergency Liftgate Safety Release
Convenience Features Emergency Liftgate Safety Release B0915KO01 On a vehicle equipped with a smart key, B0914KO01 the liftgate can be opened with hands- To unlock and open the liftgate manually free activation using the smart liftgate from inside the luggage compartment, system.
Page 240: Using Smart Liftgate
Using Smart Liftgate 1. Settings To use smart liftgate, it must be The hands-free smart liftgate system enabled from the Settings menu in can be opened automatically when the the instrument cluster or infotainment following conditions are met: system. Select: The Smart Liftgate option is enabled in the instrument cluster or Liftgate (for cluster type)
Page 241: Deactivating Smart Liftgate
Convenience Features Deactivating Smart Liftgate Detecting Area B0916KO01 B0917KO01 Door lock The smart liftgate detecting area extends approximately 20-40 in. (50- Door unlock 100 cm) behind the vehicle. If you are Liftgate open/close positioned in the detecting area and Panic are carrying the smart key, the hazard warning lights will blink and the chime will sound for about 3 seconds to alert...
Page 242 1. To install the fuel tank cap, turn it clockwise until it “clicks” one time. 2. Close the fuel filler door until it is latched securely. Information The fuel filler door will not close if the driver’s door is locked. If you lock the driver’s door while fueling, unlock it before closing the fuel filler door.
Page 243 If the fuel filler cap requires gear to the P (Park) position, set the replacement, use only a genuine parking brake, and place the ignition HYUNDAI cap or the equivalent specified for your vehicle. An Sparks produced by electrical incorrect fuel filler cap can result...
Page 244 Head-Up Display Settings B0167EU03 The Head-Up Display is an optional feature that allows the driver to view Head-up display can be enabled from information projected onto a transparent in the infotainment system. Select: screen while still keeping your eyes on the road ahead while driving.
Page 245: Head-Up Display (Hud)
Convenience Features Head-Up Display Information Precautions While Using the Head-Up Display It may sometimes be difficult to read information on the Head-Up Display in the following situations. - The driver is improperly positioned in the driver’s seat - The driver wears polarizing-filter sunglasses - An object is located above the Head-Up Display cover...
Page 246 WARNING The warning information of Blind-Spot Safety on the Head-Up Display are supplemental. Do not solely depend on them to change lanes. Always take a look around before changing lanes. Information Head-up Display includes GPL, LGPL, MPL and other open source license softwares.
Page 247: Exterior Lights
Convenience Features EXTERIOR LIGHTS Lighting Control AUTO headlight To operate the lights, turn the knob at the end of the control lever to one of the following positions: B0177KO02 The position lamp and headlight will be turned ON or OFF automatically depending on the amount of daylight as B0177KO01 measured by the ambient light sensor...
Page 248: High Beam Operation
Position lamp ( ( High Beam Operation B0177KO03 B0178EU02 The position lamp, license plate lamp To turn on the high beam headlight, push and instrument panel lamp are turned the lever away from you. The lever will return to its original paosition. The high beam indicator will light when Headlight ( ( the headlight high beams are switched...
Page 249: Turn Signals And Lane Change Signals
Convenience Features Turn Signals and Lane Change One touch turn signal Signals To use One Touch Turn Signal push the turn signal lever up or down to position B and then release it. The lane change signals will blink 3, 5 or 7 times.
Page 250 The purpose of this feature is to If the ignition switch is in the ACC help prevent the battery from being position or the LOCK/OFF position with discharged. The system automatically the headlights ON, the headlights (and/ turns off the position lamp when the or position lamps) remain on for about driver turns the vehicle off and opens the 5 minutes.
Page 251: High Beam Assist Settings
Convenience Features NOTICE Always keep the front view camera in good condition to maintain optimal performance of High Beam Assist. of the front view camera, refer to High Beam Assist Settings B0179KO01 Hight Beam Assist will automatically switch between high beam and low beam depending on the detected brightness from the lamps of oncoming vehicles or vehicles in front.
Page 252: High Beam Assist Operation
High Beam Assist Operation When High Beam Assist is operating, high beam switches to low beam if Display and control any of the following conditions occur: After selecting ‘High Beam Assist’ - When the headlight of an oncoming in the Settings menu, High Beam vehicle is detected.
Page 253: High Beam Assist Malfunction And Limitations
Information illuminate on the cluster. Have the function be inspected by an authorized For more details on the limitations of the HYUNDAI dealer. Front View Camera, refer to “Forward Collision-Avoidance Assist (FCA)” section Limitations of High Beam Assist in chapter 7.
Page 254: Interior Lights
INTERIOR LIGHTS WARNING Do not use the interior lights when driving in the dark. The interior lights may obscure your view and cause an accident. NOTICE Do not use the interior lights for extended periods when the vehicle is turned off or the battery will discharge. B0903EU03 Interior Lamp AUTO Off Front map lamp (...
Page 255: Rear Lamps
Convenience Features Rear Lamps Vanity Mirror Lamp B0192KO01 B0194KO04 Opening the lid of the vanity mirror will automatically turn on the mirror lamp. Touch the icon to turn either lamp on or off. Glove Box Lamp B0195KO01 The glove box lamp turns on when the glove box is opened.
Page 256: Door Courtesy Lamp
Door Courtesy Lamp (if Puddle Lamp equipped) Welcome light B0918KO01 B0198KO01 The lamp turns on when a door is open When all doors (and liftgate) are closed and turns off when the door is closed. and locked, the puddle lamp will turn on for 15 seconds if the door is unlocked by Luggage Compartment Lamp the smart key or when you put your hand...
Page 257: Welcome System
Convenience Features Welcome System Puddle lamp and door handle lamp When all the doors (and liftgate) are closed and locked, the puddle lamp and door handle lamp will turn on for approximately 15 seconds if: When all the doors (and liftgate) are closed and locked, the puddle light and door handle light turn on for about 15 seconds if:...
Page 258 Headlight and position lamp Information When the light switch is ON, and all The infotainment system may change after the doors (and liftgate) are closed and software updates. For more information, locked, the headlight and position lamp refer to the user's manual provided in will turn on for approximately 15 seconds the infotainment system and the quick if the door unlock button is pressed...
Page 259: Wipers And Washers
Convenience Features WIPERS AND WASHERS AUTO wiper control (if equipped) B0200KO01 B0200KO02 The rain sensor located on the upper Operates as follows when the ignition end of the windshield glass senses switch or Engine Start/Stop button is in the amount of rainfall and controls the the ON position.
Page 260 WARNING To avoid personal injury from the windshield wipers, when the engine is running and the windshield wiper switch is placed in the AUTO mode: Do not touch the upper end of the windshield glass facing the rain sensor. Do not wipe the upper end of the windshield glass with a damp or wet cloth.
Page 261 Convenience Features Recirculating air when washer WARNING fluidis used When the outside temperature is below When washer fluid is used, in order freezing, ALWAYS warm the windshield to reduce any objectionable scent using the defroster to help prevent of the washer fluid from entering the washer fluid from freezing on the the cabin,recirculation mode and air windshield and obscuring your vision...
Page 262: Rear Window Wiper And Washer
Rear Window Wiper and Washer B0201KO02 Push the lever away from you to spray B0200KO03 rear washer fluid and to run the rear The rear window wiper and washer wipers 1~3 cycles. The spray and wiper switch is located at the end of the wiper operation will continue until you release and washer switch lever.
Page 263 Convenience Features A0922EU01 Front windshield defroster button Fan speed control knob Rear window defroster button Temperature control knob Rear fan speed control button Air conditioning button Rear climate control button Mode selection button Air intake control button 5-114...
Page 264: Heating And Air Conditioning
Heating and Air Conditioning 6. If air conditioning is desired, turn the air conditioning system on. 1. Start the engine. When starting the vehicle in cold 2. Set the mode to the desired position. weather a more efficient way to heat To improve the effectiveness of the passenger compartment is to do the heating and cooling, select the mode...
Page 265 Convenience Features B9024EU01 B9024EU08 Face-Level ( B , D ) Defrost-Level ( A , D ) Air flow is directed toward the upper Most of the air flow is directed to body and face. Additionally, each outlet thewindshield with a small amount of air can be controlled to direct the air directed to the side window defrosters.
Page 266 Instrument panel vents Temperature control B0204KO04 B9024EU03 The instrument panel vent air flow can be The temperature will increase by turning the knob to the right. directed up/down or left/right using the vent adjustment lever. The temperature will decrease by turning The outlet vents can be opened or closed the knob tao the left.
Page 267 Convenience Features Recirculation mode WARNING When Recirculation mode Continued use of the climate control is selected, air from the system operation in Recirculation passenger compartment will mode for a prolonged period of be recirculated through the time may cause drowsiness to the system and heated or cooled occupants in the cabin.
Page 268 Fan speed control Rear climate control button B9024EU04 B9024EU06 Turn the knob to the right to increase If you press the rear climate control the fan speed and airflow. Turn the knob button, rear passengers can control the to the left to decrease fan speed and rear climate system.
Page 269: Rear Climate Control
Convenience Features Rear climate control 2nd row air conditioning control A0923EU01/A0923EU01/A0923EU03 OFF button Temperature control button Mode selection button Fan speed control button If you press the rear climate control button of the front climate control system, rear passengers can control the rear climate system by using the rear climate control system.
Page 270 Fan speed control Temperature control 1. Press the rear climate control button of the front climate control system. B9024EU06 1. Press the rear climate control button of the front climate control system. B9025EU02 2. The temperature of delivered aircan be set to the desired temperature by pushing the temperaturecontrol button.
Page 271 Convenience Features OFF mode Mode selection B9025EU03 B9025EU05 You can select the direction of the air flow through the ventilation system. You can adjust the front climate control system for heating or cooling to passengers on 2nd row seats. The air flow is directed from the floor.
Page 272 Rear vents on the headliner The rear passengers can adjust the direction of air flow from the rear vents on the headliner. If you operate the rear climate control with rear vents closed, a noise may sound. When operating the rear climate control, open two or more rear vents.
Page 273: System Operation
Convenience Features System Operation Operation Tips Cooling / Ventilation To keep dust or unpleasant fumes from entering the vehicle through the 1. Select the Face Level mode. ventilation system, temporarily set 2. Set the air intake control to fresh the air intake control to recirculation mode.
Page 274 Air conditioning Air conditioning system operation tips If the vehicle has been parked in Your HYUNDAI vehicle air conditioning direct sunlight during hot weather, system is filled with R-1234yf refrigerant. open the windows for a short time 1. Start the engine.
Page 275: System Maintenance
Have the cabin air filter replaced by an NOTICE authorized HYUNDAI dealer according to the maintenance schedule. If the vehicle The refrigerant system should only is being driven in severe conditions be serviced by trained and certified...
Page 276 WARNING Vehicles equipped with R-1234yf Since the refrigerant is operated at very high pressure, the air conditioning system should only be serviced by trained and certified technicians. It is important that the correct type and amount of oil and refrigerant are used. B0206KO02 Each symbol and specification on the All refrigerants should be reclaimed...
Page 277: Automatic Climate Control System
Convenience Features AUTOMATIC CLIMATE CONTROL SYSTEM A0202EU01/A0202EU02 Fan speed control button Driver’s temperature control knob Mode selection button Passenger’s temperature control knob Rear climate control button AUTO (automatic control) button Air intake control button SYNC button Rear window defroster button Front windshield defroster button Climate control information screen Air conditioning button...
Page 278: Automatic Temperature Control Mode
Automatic Temperature Control To turn the automatic operation off, select any button of the following: Mode - Mode selection button The Automatic Climate Control System - Front windshield defroster button is controlled by setting the desired (Press the button one more time temperature.
Page 279: Manual Temperature Control Mode
Convenience Features Manual Temperature Control 6. If air conditioning is desired, turn the air conditioning system on. Mode 7. Press the AUTO button to convert to The heating and cooling system can be full automatic control of the system. controlled manually by pushing buttons When starting the vehicle in cold other than the AUTO button.
Page 280 Mode selection A0204KO02 The mode selection button or icon controls the direction of the air flow through the ventilation system. 5-131...
Page 281 Convenience Features Floor-Level ( A , C , D , E ) Most of the air flow is directed to the floor, with a small amount of the air being directed to the windshield and side window defrosters. B0204EC01 B0204EC03 Defrost-Level ( A , D ) B0204KO02 Most of the air flow is directed to the...
Page 282 Temperature control Adjusting the driver and passenger side temperature individually Press the “SYNC” button again to operate the driver and passenger side temperature individually. The button indica-tor will turn off. Temperature conversion If the battery has been discharged or disconnected, the temperature mode display will reset to Fahrenheit.
Page 283 Convenience Features Air intake control WARNING The air intake control button is used to Continued use of the climate control select either Fresh mode (outside air) or system operation in Recirculation Recirculation mode (cabin air). mode for a prolonged period of time may cause drowsiness to the Recirculation mode occupants in the cabin.
Page 284 Fan speed control Air conditioning B9029EC01 B9029EU03 B9029EU02 B9029EU04 The fan speed can be set as desired by Push the A/C button or icon to manually pressing the fan speed control button or turn the system on (indicator light will icon.
Page 285 Convenience Features OFF mode Rear climate control button B9029EU05 B9029EU07 B9029EU06 B9029EU08 Press the OFF button to turn the climate If you press the rear climate control control system off. You can still operate button, rear passengers can control the the mode and air intake buttons as rear climate system.
Page 286: Rear Climate Control
Rear climate control 2nd row air conditioning control A0202KO02 AUTO button Fan speed control button Temperature control button OFF button Mode selection button Climate control information screen If you press the rear climate control button of the front climate control system, rear passengers can control the rear climate system by using the rear climate control system.
Page 287 Convenience Features Fan speed control Temperature control B9029EU07 B9029EU07 B9029EU08 B9029EU08 1. Press the rear climate control button 1. Press the rear climate control button or icon of the front climate control of the front climate control system. system. B0204KO15 B9030EU01 2.
Page 288 AUTO mode Mode selection B9025EU05 B9030EU02 The rear automatic climate control system is controlled by setting the desired temperature. 1. Press the AUTO button. The modes, fan speeds, air intake and air- conditioning will be controlled automatically by the temperature setting you select.
Page 289 Convenience Features Rear vents on the headliner The rear passengers can adjust the direction of air flow from the rear vents on the headliner. If you operate the rear climate control with rear vents closed, a noise may sound. When operating the rear climate control, open two or more rear vents.
Page 290: System Operation
System Operation Air conditioning Cooling/Ventilation Your HYUNDAI vehicle air conditioning system is filled with R-1234yf refrigerant. 1. Select the Face Level mode. 1. Start the engine. 2. Set the air intake control to fresh mode. 2. Press the air conditioning button.
Page 291: System Maintenance
Have the cabin air filter replaced by an that of the windshield could cause authorized HYUNDAI dealer according to the outer surface of the windshield the maintenance schedule. If the vehicle to fog up, causing loss of visibility. In...
Page 292 Therefore, if abnormal operation is It is important that the correct type and found, have the system inspected by an amount of oil and refrigerant are used. authorized HYUNDAI dealer. All refrigerants should be reclaimed with proper equipment. NOTICE Venting refrigerants directly to the...
Page 293 Convenience Features B0206KO01 B0206KO02 Air Conditioning refrigerant label Each symbol and specification on the air conditioning refrigerant label is You can find out which air conditioning represented as below: refrigerant is applied to your vehicle on the label located in front of engine Classification of refrigerant compartment.
Page 294 Manual Climate Control System WARNING Windshield heating Do not use the position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface of the windshield to fog up, causing loss of visibility could cause an accident resulting in serious injury or death.
Page 295 Convenience Features Automatic Temperature Control System (if equipped) B9031EU02 To defrost outside windshield 1. Set the fan speed to the highest B0208KO01 setting (knob rotated all the way to To defog inside windshield the right). 1. Select the desired fan speed. 2.
Page 296 Defogging logic To reduce the probability of fogging up the inside of the windshield, the air intake or air conditioning are controlled automatically according to certain conditions such as positions. To cancel or reset the defogging logic, do the following. Manual climate control system B0209KO01 1.
Page 297 Convenience Features When the Auto Defogging To cancel or reset the Auto Defogging System operates, the indicator System will illuminate. Press the front windshield defroster button for 3 seconds when the ignition If a high amount of humidity is detected switch is in the ON position.
Page 298: Rear Window Defroster
Rear Window Defroster Side view mirror defroster If your vehicle is equipped with the side view mirror defrosters, they will operate NOTICE at the same time you turn on the rear To prevent damage to the rear window window defroster. defroster conducting elements bonded to the inside surface of the rear window, never use sharp instruments or window...
Page 299: Auto Defogging System
Convenience Features Auto Defogging System Turning the Auto Defogging System On or off Infotainment system Auto Defogging System can be turned Defog’ from the infotainment system screen. Information To maintain the effectiveness and B0200KO02 efficiency of the Auto Defogging Auto defogging helps reduce the System, do not select Recirculation possibility of fogging up the inside of the mode while the system is operating.
Page 300: Auto Dehumidify
Auto Dehumidify (if equipped) Recirculating Air When Washer To increase cabin air quality and reduce windshield misting, recirculation mode Recirculation mode automatically switches off automatically after about 5 activates to reduce any objectionable to 30 minutes, depending on the outside scent of the washer fluid from entering temperature, and the air intake will the cabin when the windshield washer is...
Page 301: Sunroof Inside Air Recirculation
Convenience Features Sunroof Inside Air Recirculation Scheduled Ventilation Control (if equipped) The Scheduled Ventilation Control releases hot air in the vehicle to lower When the sunroof is opened, fresh cabin temperature before getting in the mode will be automatically selected. vehicle.
Page 302: Storage Compartment
STORAGE COMPARTMENT Center Console Storage WARNING Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for extended periods. WARNING ALWAYS keep the storage compartment covers closed securely while driving.
Page 303: Cup Holder
Convenience Features Cup Holder Rear (2 row, 3 row) B0225KO03 B0225KO02 A : Driver and passenger seat Cups or small beverages cups may be placed in the cup holders. Push the button and the cover opens. Push the buttons and the cup supporter protrudes from the front console.
Page 304 WARNING WARNING Avoid abrupt starting and braking Keep cans or bottles out of direct sun when the cup holder is in use to light and do not put them in a hot prevent spilling your drink. If hot vehicle. It may explode. liquid spills, you could be burned.
Page 305: Conversation Mirror
Convenience Features Conversation mirror Sunvisor B9023EU01 B0226KO01 You can see widely the rear view through To use the sunvisor, pull it downward. the conversation mirror. To use the sunvisor to block the sun from To open: the side window, pull it rearward, release it from the bracket and swing it to the Press the cover and the holder will slowly...
Page 306: Power Outlet
Power Outlet WARNING Avoid electrical shocks. Do not place your fingers or foreign objects (pin, etc.) into a power outlet or touch the power outlet with a wet hand. NOTICE To prevent damage to the power outlets: Use the power outlet only when the engine is running and remove the B0228KO01 accessory plug after use.
Page 307: Usb Charger
Convenience Features USB Charger B0229KO03 B0229KO01 B0229KO04 B0229KO02 A : Front, B : Rear (2nd row) B0920EU01 C : Rear (3rd row, left side), D : Rear (3rd row, right side), E : Center console storage (if equipped) The USB charger is designed to recharge batteries of small size electrical devices using a USB cable.
Page 308: Ac Inverter
A smart phone or a tablet PC may AC Inverter (if equipped) get warmer during the re-charging process. It does not indicate any malfunction with the charging system. A smart phone or a tablet PC, which adopts a different re-charging method, may not be properly re- charged.
Page 309 Convenience Features NOTICE Information To prevent the battery from being discharged, do not use the AC inverter while the engine is not running. When not using the AC inverter, make sure to close the AC inverter cover. After using an electric accessory or equipment, pull the plug out.
Page 310: Wireless Smart Phone Charging System
Wireless Smart Phone Charging 2. Turn on the wireless charging function from the Settings menu in the System infotainment system. Select: Wireless Charging System 3. Place the smart phone in the center of the wireless charging pad. The indicator light is orange when the smart phone is charging and turns blue when phone charging is complete.
Page 311 Convenience Features NOTICE If the smart phone has a thick cover, the wireless charging may not be The wireless smart phone charging possible. system may not support certain If the smart phone is not completely smart phones, which are not verified contacting the charging pad, ( ).
Page 312: Clock
NOTICE Clock Some magnetic items like credit cards, The clock can be set from the phone cards or rail tickets may be infotainment system. damaged if left with the smart phone during the charging process. WARNING Do not attempt to adjust the clock Information while driving.
Page 313: Coat Hook
Convenience Features Coat Hook ALWAYS use the Floor Mat Anchors to attach the front floor mats to the vehicle. The anchors on the front floor carpet keep the floor mats from sliding forward. WARNING Do not overlay additional mats or liners over the floor mats.
Page 314: Floor Mat Anchors
If you pull the rear side window with pedal operation, HYUNDAI sunshade or apply force to return recommends that the HYUNDAI floor the sunshade to its original position mat designed for use in your vehicle be after use, you may find the sunshade installed.
Page 315: Cargo Net Holder
Using the cargo security screen attached to the holders in the luggage board. If necessary, contact your authorized HYUNDAI dealer to obtain a luggage net. WARNING Avoid eye injury. DO NOT overstretch the cargo net. ALWAYS keep your face and body out of the cargo net’s recoil path.
Page 316 Removing the cargo security screen When the cargo security screen is not in use: 1. Push one side of the cargo screen 1. Pull the cargo security screen inward to compress the spring and rearward and up to release it from the release the screen from the vehicle.
Page 317 Convenience Features NOTICE Removing the cargo security screen from the luggage tray Since the cargo security screen may be damaged or malformed, do not put luggage on it when it is used. B9027EU03 1. Pull up the screen board. B9027EU04 2.
Page 318: Roof Side Rails
The roof side rails crossbars are an the roof side rails. Avoid sudden accessory and are available at your local starts, braking, sharp turns, abrupt HYUNDAI dealer. maneuvers or high speeds that may result in loss of vehicle control or NOTICE rollover resulting in an accident.
Page 319: Usb Port
Convenience Features NOTICE Antenna If you install an aftermarket HID head lamp, your vehicle’s audio and electronic devices may not function properly. Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.
Page 320: Infotainment System
1 VOLUME (VOL + / VOL -) Infotainment System Push the lever up or down to adjust the volume. 2 SEEK/PRESET ( If the SEEK/PRESET switch is pressed up or down and held for 0.8 second or more, it will function in the following modes: RADIO mode It will function as the AUTO SEEK select button.
Page 321 Convenience Features B0242KO01 B0242EU02 Call/Answer/Call end button Microphone For more information, refer to the user's manual provided in the infotainment system and the quick reference guide. CAUTION To avoid driver distractions, do not excessively operate the device while driving the vehicle which may lead to an accident.
Page 322: Driving Your Vehicle
6. Driving Your Vehicle Before Driving ....................6-4 Before Entering the Vehicle ..................6-4 Before Starting ......................6-4 Ignition Switch ....................6-5 Key Ignition Switch .......................6-5 Engine Start/Stop Button ................... 6-8 Vehicle Auto-Shut Off ..................6-13 Operating Conditions ....................6-13 Deactivating Conditions ................... 6-13 System Operation .......................
Page 323 Drive Mode Integrated Control System ............6-57 Selecting Drive Mode ....................6-57 Changing Drive Mode ....................6-57 CUSTOM Mode Features ..................6-58 Multi Terrain Mode (AWD) ..................6-59 TOW Mode ......................... 6-60 Special Driving Conditions ................6-61 Hazardous Driving Conditions .................. 6-61 Rocking the Vehicle ....................6-61 Smooth Cornering .....................
Page 324 If you hear a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the vehicle, have the exhaust system checked as soon as possible by an authorized HYUNDAI dealer. Do not run the engine in an enclosed area.
Page 325: Before Driving
Driving Your Vehicle BEFORE DRIVING Before Entering the Vehicle WARNING Be sure all windows, side view To reduce the risk of SERIOUS INJURY or mirror(s), and outside lights are clean DEATH, take the following precautions: and unobstructed. ALWAYS wear your seat belt. All Remove frost, snow, or ice.
Page 326: Ignition Switch
IGNITION SWITCH WARNING WARNING To reduce the risk of SERIOUS INJURY or NEVER turn the ignition switch to DEATH, take the following precautions: the LOCK or ACC position while the vehicle is in motion except in an NEVER allow children or any person emergency.
Page 327 Driving Your Vehicle Key Ignition Switch Positions Switch Action Notes Position To turn the ignition switch to the LOCK position, push the key in at the ACC position and turn the key towards the LOCK position. LOCK The ignition key can be removed in the LOCK position.
Page 328 Starting the Engine Information Do not wait for the engine to warm up WARNING while the vehicle remains stationary. Start driving at moderate engine Always wear appropriate shoes when speeds. (Steep accelerating and operating your vehicle. Unsuitable decelerating should be avoided.) shoes, such as high heels, ski boots, sandals, flip-flops, etc., may interfere Always start the vehicle with your foot...
Page 329: Engine Start/Stop Button
Driving Your Vehicle Engine Start/Stop Button (if WARNING equipped) NEVER press the Engine Start/Stop button while the vehicle is in motion except in an emergency. This will result in the vehicle turning off and loss of power assist for the steering and brake systems.
Page 330 Engine Stop/Start Button Positions Button Position Action Notes To turn off the engine, press the Engine Start/Stop button with the vehicle shifted to P (Park). Note if the Engine Start/Stop button is pressed with the vehicle shifted to D (Drive) or R (Reverse), the gear will automatically shift to P (Park).
Page 331 Driving Your Vehicle Starting the Engine 1. Always carry the smart key with you. 2. Make sure the parking brake is applied. WARNING 3. Make sure the gear is shifted to P Always wear appropriate shoes when (Park) by pressing the P button. operating your vehicle.
Page 332 NOTICE Emergency Starting To prevent damage to the vehicle: If the engine stalls while you are in motion, do not attempt to shift the gear to the P (Park) position. If traffic and road conditions permit, you may put the gear in N (Neutral) while the vehicle is still moving and press the Engine Start/Stop button in an attempt to restart the engine.
Page 333 Driving Your Vehicle Remote Start (if equipped) To start the vehicle remotely: 1. Press the door lock button within 32 ft. (10 m) from the vehicle. 2. Press the remote start ( ) button for over 2 seconds within 4 seconds after locking the doors.
Page 334: Vehicle Auto-Shut Off
If your vehicle is parked and the engine System Operation is left on for a long period of time, the engine will turn off automatically to help reduce fuel consumption and prevent accidents caused by carbon dioxide poisoning. Operating Conditions Vehicle Auto-Shut Off timer operates when all the following conditions are satisfied:...
Page 335: Automatic Transmission
Driving Your Vehicle AUTOMATIC TRANSMISSION Depress the brake pedal whenever pressing the shift button to change gear or shifting P. A0251KO01 Automatic Transmission Operation The automatic transmission has eight forward speeds and one reverse speed. The individual speeds are selected automatically in the D (Drive) position. WARNING The automatic transmission shift button or interior parts might get hot when a vehicle is parked out-side during hot weather.
Page 336 Transmission ranges WARNING P (Park) To reduce the risk of serious injury or Always come to a complete stop before death: shifting into P (Park). ALWAYS check the surrounding areas near your vehicle for people, especially children, before shifting a vehicle into D (Drive) or R (Reverse).
Page 337 Driving Your Vehicle Automatic gear shift to P (Park) R (Reverse) The gear is shifted to P (Park) Use this position to drive the vehicle automatically for safety reasons under rearward. the following conditions: - When the engine is turned off with the gear in R (Reverse), D (Drive) or N (Neutral).
Page 338 To stay in N (Neutral) when vehicle is N (Neutral) The wheels and transmission are not engaged. B0252EU03 B0252EU05 To shift the gear to N (Neutral), press the N button from R (Reverse) or D (Drive) while depressing the brake pedal. Always depress the brake pedal when you are shifting from N (Neutral) to another gear.
Page 339 Driving Your Vehicle D (Drive) 4. Press and hold the OK button A on the steering wheel for more than 1 This is the normal driving position. second. The transmission will automatically shift 5. When the message ‘Vehicle will stay through an 8-gear sequence, providing in (N).
Page 340 When the battery is discharged Shift-lock system You cannot shift gears, when the battery For your safety, the automatic is discharged. transmission has a shift-lock system which prevents shifting the transmission In emergencies, do the following to shift from P (Park) into R (Reverse) or D (Drive) the gear to N (Neutral) on a level ground.
Page 341: Lcd Display Messages (Cluster)
Driving Your Vehicle Parking LCD Display Messages (Cluster) Press brake pedal to change gear Always come to a complete stop and continue to depress the brake pedal. Shift the gear to P (Park), apply the parking brake, and place the ignition switch or press the Engine Start/Stop button to the OFF position.
Page 342 RPM is too high, or when driving speed is a malfunction with the shift button. too fast to shift the gear. Immediately have the vehicle inspected Decrease vehicle speed or slow down by an authorized HYUNDAI dealer. before shifting the gear. Shifter system malfunction Check P button B0253EU10...
Page 343 B0253EU04 with the Parking brake. Immediately have This message is displayed when the P the vehicle inspected by an authorized (PARK) position is engaged. HYUNDAI dealer. Make sure that the vehicle is completely stopped before shifting to P (Park). 6-22...
Page 344 ‘Press and hold the Immediately have the vehicle inspected OK button on the steering wheel to stay by an authorized HYUNDAI dealer. in Neutral’ appears on the cluster LCD display. The gear stays in N(Neutral) position after turning off the engine.
Page 345 If the above message is continuously displayed, we recommend that you contact an authorized authorized HYUNDAI dealer. B0253EU17 Trans cooled. Resume driving This message is displayed when the vehicle is safe to drive. 6-24...
Page 346: Paddle Shifter (Manual Shift Mode)
Paddle Shifter (Manual Shift Good Driving Practices Mode) Never shift the gear from P (Park) or N (Neutral) to any other position with the accelerator pedal depressed. Never shift the gear into P (Park) when the vehicle is in motion. Be sure the vehicle is completely stopped before you attempt to shift into R (Reverse) or D (Drive).
Page 347 In the event your vehicle leaves the roadway, do not steer sharply. Instead, slow down before pulling back into the travel lanes. HYUNDAI recommends you follow all posted speed limits. 6-26...
Page 348: Braking System
BRAKING SYSTEM Power-Assist Brakes Wet brakes may impair the vehicle's ability to safely slow down; the Your vehicle has power-assisted brakes vehicle may also pull to one side that adjust automatically through normal when the brakes are applied. usage. Applying the brakes lightly will If the engine is not running or is turned indicate whether they have been off while driving, the power assist for...
Page 349: Electronic Parking Brake (Epb)
EPB is used for Make sure the Parking Brake warning emergency braking, have the system light comes on. checked by an authorized HYUNDAI dealer. EPB (Electronic Parking Brake) may be automatically applied when: Requested by other systems The driver turns the vehicle off while Auto Hold is operating.
Page 350 P (Park) to released, have the system checked R (Reverse) or D (Drive). by an authorized HYUNDAI dealer. Gear in N (Neutral) Do not drive your vehicle with EPB With the engine running depress applied.
Page 351 Driving Your Vehicle Warning messages WARNING Whenever leaving the vehicle or parking, always come to a complete stop and continue to depress the brake pedal. Shift the gear into P (Park), pull the EPB switch, and place the ignition switch or press the Engine Start/ Stop button to the OFF position.
Page 352 NOTICE Do not apply the accelerator pedal while the parking brake is engaged. If you depress the accelerator pedal with EPB engaged, a warning will sound and a message will appear. Damage to the parking brake may occur. Driving with the parking brake on can overheat the braking system and B0261EU05 cause premature wear or damage...
Page 353 If the Parking Brake warning light If this occurs, have the system checked remains on after the parking brake is by an authorized HYUNDAI dealer. released while the engine is running, The EPB warning light may illuminate there may be a malfunction in the when the ESC indicator comes on to brake system.
Page 354: Auto Hold
Auto Hold Auto Hold helps maintain the vehicle in a standstill even though the brake pedal is not depressed after the driver brings the vehicle to a complete stop by depressing the brake pedal. Information The Auto Hold On or Off setting is B0261KO02 maintained when the vehicle is turned off.
Page 355 Auto Hold before you: - Drive downhill. NOTICE - Drive the vehicle in R (Reverse). If the AUTO HOLD indicator changes - Park the vehicle. to yellow, Auto Hold is not working properly. Contact an authorized HYUNDAI dealer. 6-34...
Page 356 Auto Hold may not pedal work properly. When the conversion from Auto Hold to Contact an authorized HYUNDAI dealer. EPB is not working properly a warning will sound and a message will appear. Warning messages When this message is displayed, Auto Hold and EPB may not operate.
Page 357: Anti-Lock Brake System (Abs)
Driving Your Vehicle Anti-Lock Brake System (ABS) WARNING Anti-Lock Braking System (ABS) or Electronic Stability Control (ESC) system will not prevent accidents due to improper or dangerous driving maneuvers. Even though vehicle control is improved during emergency braking, always maintain a safe B0261EU07 distance between you and objects AUTO HOLD conditions not met.
Page 358 To reduce the risk of serious brakes. Depress your brake pedal as hard injury or death, contact your authorized as possible. HYUNDAI dealer as soon as possible. When you apply your brakes under conditions which may lock the wheels, NOTICE...
Page 359: Electronic Stability Control (Esc)
Driving Your Vehicle Electronic Stability Control (ESC) WARNING Never drive too fast for the road conditions when cornering. ESC will not prevent accidents. Excessive speed in turns, abrupt maneuvers, and hydroplaning on wet surfaces can result in severe accidents. ESC operation ESC ON condition When the ignition switch or Engine B0263EU01...
Page 360 ESC system. When this warning light management) and the brake control illuminates, have the vehicle checked by function of ESC (braking management) an authorized HYUNDAI dealer as soon are disabled. as possible. If the ignition switch or Engine Start/...
Page 361: Vehicle Stability Management (Vsm)
Driving Your Vehicle ESC OFF usage Vehicle Stability Management (VSM) When Driving Vehicle Stability Management is a The ESC OFF mode should only be used function of the Electronic Stability briefly to help free the vehicle if stuck in Control (ESC) system. It helps the vehicle snow or mud, by temporarily stopping stay stable when accelerating or braking operation of ESC, to maintain wheel...
Page 362 When the warning light illuminates Driving in reverse. have the vehicle checked by an The ESC OFF indicator light is on. authorized HYUNDAI dealer as soon as possible. The MDPS (Motor Driven Power Steering) warning light ( ) is on or NOTICE blinks.
Page 363: Hill-Start Assist Control (Hac)
Driving Your Vehicle Hill-Start Assist Control (HAC) Trailer Stability Assist (TSA) Hill-Start Assist Control helps prevent Trailer stability assist is operated as a the vehicle from rolling backwards vehicle stability control system. The when starting a vehicle from a stop Trailer stability assist system stabilizes on a hill.
Page 364: Downhill Brake Control (Dbc)
Brake Assistant System (BAS) Downhill Brake Control (DBC) The Brake Assistant System provides additional pressure when the brake pedal is momentarily and strongly depressed in a situation sudden braking is required while driving. The Brake Assistant System reduces the time for ABS (Anti-Lock Brake System) control to enter and consequently reduces the braking distance, by providing additional pressure up to the...
Page 365 The yellow warning light illuminates when the system may have malfunctioned or may not work properly System during activation. If this occurs, Downhill Brake Control malfunction is deactivated. Have the system be inspected by an authorized HYUNDAI dealer as soon as possible. Yellow light on 6-44...
Page 366 Information Downhill Brake Control may not deactivate on steep inclines even though the brake pedal or accelerator pedal is depressed. Downhill Brake Control may not always maintain vehicle speed at a certain speed. Downhill Brake Control does not operate when: B1000EU03 Downhill Brake Control disabled.
Page 367: Good Braking Practices
HYUNDAI the Engine Start/Stop button to the dealer for assistance.
Page 368: All Wheel Drive (Awd)
All Wheel Drive (AWD) delivers engine Shorten your scheduled power to front and rear wheels for maintenance interval if you drive in maximum traction. AWD is useful when off-road conditions such as sand, extra traction is required, such as when mud or water (see "Maintenance driving on, muddy, wet, or snow-covered Under Severe Usage Conditions"...
Page 369: Awd Operation
Driving Your Vehicle AWD Operation All Wheel Drive (AWD) mode selection Transfer mode Selection mode Description In the AWD AUTO mode, under normal operating conditions, the vehicle operates similar to conventional 2WD vehicles. If the system determines there is a need for four wheel drive, the engine's AWD AUTO driving power is distributed to all four wheels (Normal diving)
Page 370 For safe AWD operation Driving in sand or mud Maintain slow and constant speed. Before driving Use tire chains driving in mud if Make sure all passengers are wearing necessary. seat belts. Keep sufficient distance between your Sit upright and closer to the steering vehicle and the vehicle in front of you.
Page 371: Emergency Precautions
Driving Your Vehicle WARNING WARNING Do not drive across the contour of steep Do not grab the inside of the steering hills. A slight change in the wheel angle wheel when you are driving off-road. can destabilize the vehicle, or a stable You may hurt your arm by a sudden vehicle may lose stability if the vehicle steering maneuver or from steering...
Page 372 If the AWD ( ) warning light stays on the instrument cluster, your vehicle may have a malfunction with the AWD system. When the AWD warning light ( ) illuminates, have the vehicle be checked by an authorized HYUNDAI dealer as soon as possible. 6-51...
Page 373: Isg System Operation
Driving Your Vehicle Idle Stop and Go helps reduce fuel The vehicle is sufficiently warmed up consumption by automatically shutting ISG related parts are working properly down the engine, when the vehicle is The incline is gradual at a standstill (for example, red stop The steering wheel is turned less than light, stop sign, and traffic jam) subject 180 degrees and then the vehicle...
Page 374 In the Auto Stop mode, if the engine LCD display messages hood is opened, ISG system will be The messages are displayed on the deactivated. instrument cluster to help use ISG When the system is deactivated, the ISG system. off button indicator will illuminate and a message ‘Auto Stop error.
Page 375: Isg System Off
Driving Your Vehicle ISG System Off B0802EU04 AUTO STOP elapsed time B0285KO01 AUTO STOP display shows the elapsed Press the ISG OFF button to turn off ISG time of engine stop by the Idle Stop and system. The ISG OFF button indicator will Go system.
Page 376: Forced To Restart Engine
The light on the ISG OFF button will The battery is weak illuminate. The cooling and heating performance Contact an authorized HYUNDAI dealer. of the climate control system is unsatisfactory Calibrating the Battery Sensor The vehicle is shifted to P (Park) or R...
Page 377 If this occurs, have the ISG system checked by an authorized HYUNDAI dealer. NOTICE Use only a genuine HYUNDAI ISG battery for replacement. If not, the ISG system may not properly operate. Do not recharge the ISG battery with a general battery charger.
Page 378: Drive Mode Integrated Control System
DRIVE MODE INTEGRATED CONTROL SYSTEM Selecting Drive Mode ECO mode (if equipped) ECO mode helps improve fuel Drive mode may be selected according efficiency for eco-friendly to the driver's preference or road driving. condition. Fuel efficiency varies according to the driver's driving habit and road condition.
Page 379: Custom Mode Features
Driving Your Vehicle SPORT mode CUSTOM Mode Features SMART mode SPORT mode provides sporty but firm riding. SMART mode selects the proper driving In SPORT mode, the fuel mode among SMART ECO, SMART efficiency may decrease. COMFORT and SMART SPORT by judging the driver's driving habits (for example, When SPORT mode is selected, the mild or dynamic) from the brake pedal...
Page 380: Multi Terrain Mode (Awd)
The driving mode automatically Multi Terrain Mode (AWD, if changes to SMART SPORT, when equipped) you abruptly accelerate the vehicle Multi terrain mode may be selected or repetitively operate the steering according to the driver's preference or wheel (Your driving is categorized road condition.
Page 381: Tow Mode
Driving Your Vehicle TOW Mode (if equipped) Setting features When towing a trailer, switching to TOW mode enables smooth driving by changing the shifting pattern to suit heavy loads. Operating button B1007EU02 When the gear is in P(Park), select 'Setup from the infotainment system to set the weight of trailer to be towed.
Page 382: Special Driving Conditions
SPECIAL DRIVING CONDITIONS Hazardous Driving Conditions Rocking the Vehicle When hazardous driving elements If it is necessary to rock the vehicle to are encountered such as water, snow, free it from snow, sand, or mud, first turn ice, mud and sand, take the following the steering wheel right and left to clear precautions: the area around your front wheels.
Page 383: Smooth Cornering
Driving Your Vehicle Smooth Cornering Information Avoid braking or gear changing in The ESC system must be turned OFF corners, especially when roads are wet. before rocking the vehicle. Ideally, corners should always be taken under gentle acceleration. NOTICE Driving at Night If you are still stuck after rocking the vehicle a few times, have the vehicle Night driving presents more hazards than...
Page 384: Driving In The Rain
Driving in the Rain Driving in Flooded Areas Rain and wet roads can make driving Avoid driving through flooded areas dangerous. Here are a few things to unless you are sure the water is no consider when driving in the rain or on higher than the bottom of the wheel hub.
Page 385: Reducing The Risk Of A Rollover
Driving Your Vehicle Reducing the Risk of a Rollover WARNING Your multi-purpose passenger vehicle is Utility vehicles have a significantly defined as a Sports Utility Vehicle (SUV). higher rollover rate than other types of SUV’s have higher ground clearance vehicles. To prevent rollovers or loss of and a narrower track to make them control: capable of performing in a wide variety...
Page 386: Winter Driving
WINTER DRIVING The severe weather conditions of winter Snow tires quickly wear out tires and cause other problems. To minimize winter driving WARNING problems, you should take the following suggestions: Snow tires should be equivalent in size and type to the vehicle’s standard tires. Snow or Icy Conditions Otherwise, the safety and handling of your vehicle may be adversely affected.
Page 387 If tire chains must same manufacturer for safe driving. be used, use genuine HYUNDAI Parts When driving with the M+S tires with and install the tire chain after reviewing...
Page 388 Chain Installation WARNING When installing tire chains, follow the The use of tire chains may adversely manufacturer’s instructions and mount affect vehicle handling: them as tightly possible. Drive slowly Drive less than 20 mph (30 km/h) (less than 20 mph (30 km/h)) with or the chain manufacturer’s chains installed.
Page 389: Winter Precautions
9. The To prevent the window washer from battery charging level can be checked being frozen, add authorized window by an authorized HYUNDAI dealer or in a washer anti-freeze solution, as specified service station. on the window washer container.
Page 390 Do not let your parking brake freeze Carry emergency equipment Under some conditions your parking In accordance with weather conditions, brake can freeze in the engaged position. you should carry appropriate emergency This is most likely to happen when there equipment, while driving.
Page 391: Trailer Towing
When towing a trailer, consult an properly. Damage to your vehicle caused authorized HYUNDAI dealer for by improper trailer towing is not covered further information on additional by your vehicle manufacturer’s warranty.
Page 392 Trailer weight Tongue load Tongue Load Total Trailer Weight Gross Axle Weight Gross Vehicle Weight OOSH069129L OOSH069130L What is the maximum safe weight of a The tongue load is an important weight trailer? It should never weigh more than to measure because it affects the total the maximum trailer weight with trailer Gross Vehicle Weight (GVW) of your brakes.
Page 393: Trailer Towing Equipment
Do not attach rental hitches or other bumper-type hitches to them. Use only a frame- mounted hitch that does not attach to the bumper. A HYUNDAI trailer hitch accessory is available at an authorized HYUNDAI dealer. 6-72...
Page 394: Driving With A Trailer
Safety chains Driving with a Trailer You should always attach chains between Towing a trailer requires a certain your vehicle and your trailer. amount of experience. Before setting out for the open road, you must get to Instructions about safety chains may know your trailer.
Page 395 You may system and/or personal injury. Consult proceed once the engine has cooled an authorized HYUNDAI dealer for sufficiently. assistance. When towing a trailer, your vehicle speed may be much slower than the general flow of traffic, especially when climbing an uphill grade.
Page 396 Parking on hills Driving the vehicle after it has been parked on a hill Generally, if you have a trailer attached to your vehicle, you should not park your 1. With the gear in P (Park), apply your vehicle on a hill. brakes and hold the brake pedal down while you: However, if you ever have to park your...
Page 397: Maintenance When Towing A Trailer
Driving Your Vehicle Maintenance When Towing a Trailer Your vehicle will need service more often when you regularly pull a trailer. Important items to pay particular attention to include engine oil, transmission fluid, axle lubricant and cooling system fluid. Brake condition is another important item to frequently check.
Page 398: Vehicle Load Limit
VEHICLE LOAD LIMIT Two labels on your driver’s door sill show GAWR (Gross Axle Weight Rating) how much weight your vehicle was This is the maximum allowable weight designed to carry: the Tire and Loading that can be carried by a single axle (front Information Label and the Certification or rear).
Page 399: The Loading Information Label
Driving Your Vehicle The Loading Information Label B1006EU03 B1006EU01 B1006EU02 B1006EU04 The label located on the driver’s door sill gives the original tire size, cold tire pressures recommended for your vehicle, the number of people that can be in your vehicle and vehicle capacity weight.
Page 400 Vehicle capacity weight Steps for determining correct load limit 1. 7 persons: 1173 lbs. (532 kg) 1. Locate the statement "The combined 1. 8 persons: 1323 lbs. (600 kg) weight of occupants and cargo should Vehicle capacity weight is the maximum never exceed XXX kg or XXX lbs."...
Page 401 Driving Your Vehicle Example 1 Maximum Load Passenger Weight Cargo Weight (1400 lbs.) (150 lbs. × 2 = 300 lbs.) (1100 lbs.) (635 kg) (68 kg × 2 = 136 kg) (499 kg) Example 2 Maximum Load Passenger Weight Cargo Weight (1400 lbs.) (150 lbs.
Page 402 Certification label WARNING Overloading Never exceed the GVWR for your vehicle, the GAWR for either the front or rear axle and vehicle capacity weight. Exceeding these ratings can affect your vehicle's handling and braking ability, and cause an accident. Do not overload your vehicle. Overloading your vehicle can cause heat buildup in your vehicle's tires OBH059070...
Page 403: Driver Assistance System
7. Driver Assistance System Driver Assistance system functions can be updated by infotainment software update. Descriptions for each function of the system may differ from the owners' manual once updated. Refer to the user's manual provided in the infotainment system and the quick reference guide. Driving Safety Forward Collision–Avoidance Assist (FCA) .............
Page 404: Forward Collision-Avoidance Assist (Fca)
Driver Assistance System Basic function Junction Turning function B0311KO01 B0311KO02 Forward Collision-Avoidance Assist is Junction Turning function helps avoid designed to help detect and monitor the a collision with an oncoming vehicle in vehicle ahead or help detect a pedestrian an adjacent lane when turning left at or cyclist in the roadway and warn the a crossroad with the turn signal on by...
Page 405 Lane-Change Oncoming function (if Lane-Change Side function (if equipped) equipped) B0311KO04 B0311KO05 A : Oncoming vehicle A : Front-side vehicle Lane-Change Oncoming function helps Lane-Change Side function helps avoid avoid a collision with an oncoming a collision with the vehicle ahead in vehicle when changing lanes by assisting the next lane when changing lanes by the driver’s steering.
Page 406 Driver Assistance System Evasive Steering Assist function (if Detecting sensor equipped) B0311KO07 B0311KO06 Driver steering assist Evasive Steering Assist function helps avoid a collision with a vehicle, pedestrian or cyclist ahead in the same lane. When a risk of collision is detected, Evasive Steering Assist function will warn the driver and if the driver steers to avoid collision it will...
Page 407 HYUNDAI dealer. any damage to it. Use only genuine HYUNDAI parts to If the detecting sensors have been repair or replace a damaged front replaced or repaired, have the radar cover.
Page 408 Driver Assistance System Forward Collision-Avoidance Forward Cross-Traffic Safety (if equipped) Assist Settings Forward Safety B0312EU02 With the engine on, select or deselect B0312EU01 With the engine on, select or deselect Forward Cross-Traffic Safety’ from the Settings menu to turn on Junction the Settings menu to set whether to use Crossing function and deselect to turn each function.
Page 409 Collision-Avoidance Assist is on, Have Safety Warning Timing’ from the Settings the vehicle inspected by an authorized menu to change the initial warning HYUNDAI dealer. activation time for Forward Collision- Avoidance Assist. The warning time can WARNING be set to either ‘Standard’ or ‘Late’.
Page 410 Driver Assistance System Forward Collision-Avoidance Assist Operation Basic function The basic function for Forward Collision- Avoidance Assist is to warn and help control the vehicle depending on the collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. B0312EU05 Warning Volume With the vehicle on, select ‘Driver...
Page 411 B0313EU02 B0313EU03 Emergency Braking Stopping vehicle and ending brake control To warn the driver that emergency When the vehicle is stopped due braking will be assisted, the ‘Emergency to emergency braking, the ‘Drive Braking’ warning message will appear on carefully’ warning message will the cluster, an audible warning will sound appear on the cluster.
Page 412 Driver Assistance System Junction Turning function Junction Turning function will warn and help control the vehicle depending on the collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’ B0313EU05 Emergency Braking To warn the driver that emergency braking will be assisted, the ‘Emergency Braking’...
Page 413 Junction Crossing function (if equipped) Junction Crossing function will warn and help control the vehicle depending on collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’ B0313EU03 Stopping vehicle and ending brake control When the vehicle is stopped due to emergency braking, the ‘Drive carefully’...
Page 414 Driver Assistance System B0313EU07 B0313EU03 Emergency Braking Stopping vehicle and ending brake control To warn the driver that emergency When the vehicle is stopped due braking will be assisted, the to emergency braking, the ‘Drive ‘Emergency Braking’ warning carefully’ warning message will message will appear on the cluster, appear on the cluster.
Page 415 Lane-Change Oncoming function (if equipped) Lane-Change Oncoming function will warn and help control the vehicle depending on collision risk level: ‘Collision Warning’ and ‘Emergency Steering’ B0313EU08 Emergency Steering To warn the driver that emergency steering will be assisted, the ‘Emergency Steering’ warning message will appear on the cluster, an audible warning will sound and the steering wheel will vibrate.
Page 416 Driver Assistance System Lane-Change Side function (if equipped) Lane-Change Side function will warn and help control the vehicle depending on collision risk level: ‘Collision Warning’ and ‘Emergency Steering’ B0313EU10 Emergency Steering To warn the driver that emergency steering will be assisted, the ‘Emergency Steering’...
Page 417 Evasive Steering Assist function (if CAUTION equipped) Lane-Change Side function does not Evasive Steering Assist function will warn operate if the vehicle speed of the and control the vehicle with ‘Emergency preceding vehicle from the front side steering’. is 0 mph (0 km/h). The detecting range of the front corner radar and the rear corner radar is determined by a standard...
Page 418 Driver Assistance System CAUTION The steering wheel may turn automatically when emergency steering is operating. Emergency steering will automatically cancel when risk factors disappear. If necessary, the driver must steer the vehicle. Emergency steering may not operate B0313EU11 or may cancel during operation if Emergency Steering (Evasive steering the steering wheel is held tight or assist)
Page 419 If any other system’s warning WARNING message is displayed or audible For your safety, change the Settings warning is generated, Forward after parking the vehicle at a safe Collision-Avoidance Assist warning location. message may not be displayed and audible warning may not be Forward Collision-Avoidance Assist generated.
Page 420 Oncoming, Lane-Change Side and cluster. Have the vehicle inspected by an Evasive Steering Assist functions will HYUNDAI dealer. only warn the driver (if equipped). Information In a situation where collision is imminent, braking may be assisted by...
Page 421 Driving in heavy rain or snow, or thick the vehicle inspected by an authorized HYUNDAI dealer. The field of view of the front view camera is obstructed by sun glare Street light or light from an oncoming...
Page 422 Driver Assistance System The surrounding is very bright Driving in vast areas where there are few vehicles or structures (for The surrounding is very dark, such as example, desert, meadow, suburb, in a tunnel, etc. etc.) The brightness changes suddenly, for Driving near areas containing metal example when entering or exiting a substances, such as a construction...
Page 423 You are continuously driving in a circle There is a group of pedestrians, cyclists or a large crowd in front The vehicle in front has an unusual shape The pedestrian or cyclist is wearing clothing that easily blends into the The vehicle in front is driving uphill or background, making it difficult to downhill...
Page 424 Driver Assistance System Junction Crossing, Lane-Change A vehicle such as a flat trailer is Oncoming, Lane-Change Side, Evasive detected Steering Assist function (if equipped) A big vehicle such as a bus or truck is The temperature around the front detected corner radar or rear corner radar is A small moving obstacle such as a high or low...
Page 425 WARNING Driving on a curved road B0349KO08 B0349KO07 B0314KO09 Forward Collision-Avoidance Assist may detect a vehicle, pedestrian or cyclist in the next lane or outside the B0314KO07 lane when driving on a curved road. Forward Collision-Avoidance Assist may not detect other vehicles, If this occurs, Forward Collision- pedestrians or cyclists in front of Avoidance Assist may unnecessarily...
Page 426 Driver Assistance System Driving on an inclined road Forward Collision-Avoidance Assist may not detect other vehicles, pedestrians or cyclists in front of you while driving uphill or downhill, adversely affecting the performance of the sensors. This may result in unnecessary warning, braking assist or steering assist or no warning, braking assist or steering assist (if equipped) when...
Page 427 Changing lanes B0314KO15 A : Your vehicle, B0314KO14 B : Lane changing vehicle, A : Your vehicle, C : Same lane vehicle B : Lane changing vehicle When a vehicle in front of you When a vehicle moves into your lane merges out of the lane, Forward from an adjacent lane, it cannot Collision-Avoidance Assist may not...
Page 428 Driver Assistance System Detecting vehicle Forward Collision-Avoidance Assist may not operate properly if interfered by strong electromagnetic waves. Forward Collision-Avoidance Assist may not operate for 15 seconds after the vehicle is started, or the front view camera is initialized. Information This device complies with Part 15 of the B0314KO16 FCC rules.
Page 429 Lane Keeping Assist is designed to help Lane Keeping Assist Settings detect lane markings (or road edges) Lane Safety while driving over a certain speed. Lane Keeping Assist will warn the driver if the vehicle leaves the lane without using the turn signal, or will automatically assist the driver’s steering to help prevent the vehicle from departing the lane.
Page 430 Driver Assistance System Warning Volume Turning Lane Keeping Assist On/Off B0312EU05 B0317KO01 With the engine on, select ‘Driver With the engine on, press and hold the Lane Driving Assist button located on the steering wheel to turn on Lane Keeping menu to change the Warning Volume to Assist.
Page 431 Lane Keeping Assist Operation Lane Keeping Assist Warning and control To warn the driver that the vehicle is departing from the projected lane Lane Keeping Assist will warn and help in front, the green indicator control the vehicle with Lane Departure light will blink on the cluster, and the Warning and Lane Keeping Assist.
Page 432 Driver Assistance System WARNING Information The steering wheel may not be For more details on instrument cluster assisted if the steering wheel is held settings, refer to “LCD display control” very tight or the steering wheel is section in chapter 4. steered over a certain degree.
Page 433 If this occurs, have the roadway, such as a tollgate, sidewalk, vehicle inspected by an authorized curb, etc. HYUNDAI dealer. The distance to the front vehicle is extremely short or the vehicle in front Limitations of Lane Keeping Assist...
Page 434 Driver Assistance System You may not hear the warning WARNING sound of Lane Keeping Assist if the Take the following precautions when surrounding is noisy. using Lane Keeping Assist: If you attach objects to the steering The driver has the responsibility to wheel, steering may not be assisted safely drive and control the vehicle.
Page 435 Blind-Spot Collision Warning is designed to help detect and monitor approaching vehicles in the driver’s blind spot area and warn the driver of a possible collision with a warning message and audible warning. B0319KO02 Blind-Spot Collision Warning helps detect and informs the driver that a vehicle is approaching at high speed from the blind spot area.
Page 436 If the rear corner radars have been replaced or repaired, have the vehicle inspected by an authorized HYUNDAI dealer. Use only genuine HYUNDAI parts to repair the rear bumper where the rear corner radar is located. Rear bumper genuine parts with rear corner radars have proven their performance.
Page 437: Blind-Spot Collision Warning (Bcw)
Blind-Spot Collision Warning Settings Blind-Spot Safety B0320EU02 When activating Blind-Spot Collision Warning or restarting the vehicle with this function activated, the warning B0320EU01 light on the side mirrors will appear for With the engine on, select or deselect approximately 3 seconds. When the vehicle is restarted with Blind-Spot Blind-Spot Safety’...
Page 438 Driver Assistance System Warning Volume Blind-Spot Collision Warning Operation Driving-Warning B0312EU05 With the engine on, select ‘Driver B0321KO02 To warn the driver a vehicle is menu to change the Warning Volume to detected, the warning light on the ‘High’, ‘Medium’, ‘Low’ or ‘Off’ for Blind- side view mirror and head-up display Spot Collision Warning.
Page 439 Collision-avoidance assist (while WARNING parallel parking exit) The detecting range of the rear corner radar is determined by a standard road width, therefore, on a narrow road, Blind-Spot Collision Warning may detect other vehicles two lanes over and warn you. In contrast, on a wide road, Blind-Spot Collision Warning may not be able to detect a vehicle driving in the next...
Page 440 Driver Assistance System When Blind-Spot Collision Warning is operating, braking control by the function will automatically cancel when the driver excessively depresses the accelerator pedal or sharply steers the vehicle. During Blind-Spot Collision Warning operation, the vehicle may stop suddenly injuring passengers and shifting loose objects.
Page 441 ) warning light will illuminate on the When Blind-Spot Collision Warning is not working properly, the ‘Check Blind- cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI Spot Safety system’ warning message will appear on the cluster for several dealer.
Page 442 Blind-Spot Collision Warning will operate properly when such foreign material or trailer, etc., is removed, and then the engine is restarted. If Blind-Spot Collision Warning does not operate properly after it is removed, have the vehicle inspected by an authorized HYUNDAI dealer. 7-40...
Page 443 Limitations of Blind-Spot Collision Your vehicle changes lane Warning Your vehicle has started at the same time as the vehicle next to you and Blind-Spot Collision Warning may not has accelerated operate properly, or it may operate unexpectedly under the following The vehicle in the next lane moves circumstances: two lanes away from you, or when the...
Page 444 Driver Assistance System Blind-Spot Collision Warning may not WARNING operate properly, or it may operate Driving on a curved road unexpectedly when the following objects are detected: A motorcycle or bicycle is detected A vehicle such as a flat trailer is detected A big vehicle such as a bus or truck is detected...
Page 445 Driving where the road is merging/ Driving where the heights of the dividing lanes are different B0322KO07 B0322KO08 Blind-Spot Collision Warning may not Blind-Spot Collision Warning may not operate properly when driving where operate properly when driving where the road merges or divides. The the heights of the lanes are different.
Page 446 Driver Assistance System Information This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
Page 447 Detecting sensor B0323KO01 After the vehicle stops, when an B0323KO03 approaching vehicle from the rear area A : Rear corner radar is detected after a passenger opens the Refer to the picture above for the door, Safe Exit Assist will warn the driver detailed location of the detecting with a warning message and an audible sensors.
Page 448 Driver Assistance System Safe Exit Assist Settings Exit Safety B0312EU05 Warning Volume With the engine on, select ‘Driver B0324EU01 With the engine on, select ‘Driver menu to change the Warning Volume from the Settings menu to turn on Safe ‘High’, ‘Medium’, ‘Low’ or ‘Off’ for Safe Exit Assist and deselect to turn off the Exit Assist.
Page 449 Safe Exit Assist Operation Safe Exit Assist will warn and control the vehicle with Collision warning when exiting vehicle and Safe Exit Assist linked with Electronic child safety lock. Warning and control B0325EU02 Safe Exit Assist linked with Electronic child safety lock When Electric child safety lock is operating and an approaching vehicle from the rear area is detected, the rear...
Page 450 Driver Assistance System CAUTION WARNING If the driver presses the electronic child Take the following precautions when lock button again within 10 seconds using Safe Exit Assist: after the warning message appears, For your safety, only change the Safe Exit Assist judges that the driver Settings after parking the vehicle at a has unlocked the doors acknowledging safe location.
Page 451 ‘Check side view mirror warning light’ warning message will appear on the cluster for several seconds, and the master ) warning light will illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. 7-49...
Page 452 Driver Assistance System Limitations of Safe Exit Assist WARNING Safe Exit Assist may not operate properly, Even though the warning message or it may operate unexpectedly under the does not appear on the cluster, Safe following circumstances: Exit Assist may not properly operate. Getting out of the vehicle where trees Safe Exit Assist may not properly or grass are overgrown...
Page 453: Manual Speed Limit Assist (Msla)
Manual Speed Limit Assist Operation Setting speed limit B0327EU01 Speed Limit indicator Set speed You can set the speed limit when you do B0328KO01 not want to drive over a specific speed. 1. Press and hold Driving Assist If you drive over the preset speed limit, ) button at the desired speed.
Page 454 Driver Assistance System Temporarily pausing Manual Speed Limit Assist B0328EU01 3. The set speed limit will be displayed on the cluster. B0328KO04 If you would like to drive over the Press the switch to temporarily preset speed limit, depress the pause the set speed limit.
Page 455 Resuming Manual Speed Limit Assist Turning off Manual Speed Limit Assist B0348KO05 To resume Manual Speed Limit Assist B0328KO01 after the function was paused, operate Press the Driving Assist ( ) button to the +, -, switch. turn Manual Speed Limit Assist off. The Speed Limit ( ) indicator will go If you push the + switch up or –...
Page 456: Intelligent Speed Limit Assist (Isla)
Driver Assistance System Intelligent Speed Limit Assist uses Intelligent Speed Limit Assist information from the detected road sign Settings and navigation system to inform the Speed Limit driver of the speed limit of the current road. Also, Intelligent Speed Limit Assist helps the driver to maintain within the speed limit of the road.
Page 457 Intelligent Speed Limit Assist Operation Warning and control Intelligent Speed Limit Assist will warn and control the vehicle by ‘Displaying speed limit’, ‘Warning overspeed’ and ‘Changing set speed’. Information B0371EU02 Intelligent Speed Limit Assist warning Warning Volume and control are described based on the With the vehicle on, select ‘Driver Offset adjusted to '0'.
Page 458 Driver Assistance System Warning overspeed Set Speed Auto Change (Navigation equipped) B0331EU02 When driving at a speed higher than the B0331EU04 displayed speed limit, the speed limit is Manual Speed Limit Assist or Smart displayed in red. Cruise Control assists the vehicle to adjust its speed according to the speed Changing set speed limit.
Page 459 Intelligent Speed Limit ) warning light will illuminate on the Assist may not operate properly. cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI Information dealer. For more details on Manual Speed Limit Assist operation, refer to “Manual Speed Limit Assist (MSLA)”...
Page 460 - A sign is attached to another vehicle HYUNDAI dealer. The distance between the vehicle and the road signs is too far WARNING The vehicle encounters illuminant...
Page 461 The minimum speed limit sign is on WARNING the road Intelligent Speed Limit Assist is a The brightness changes suddenly, for supplemental function that helps the example when entering or exiting a driver to comply with the speed limit tunnel or passing under a bridge on the road, and may not display the Headlights are not used or the correct speed limit or control the...
Page 462 Driver Assistance System Basic function Driver Attention Warning Settings Driver Attention Warning can help Leading Vehicle Departure Alert determine the driver's attention level With the engine on, select or deselect by analyzing driving pattern and driving time while the vehicle is driven. Driver Warning’...
Page 463: Driver Attention Warning (Daw)
Driver Attention Warning CAUTION Operation Driver Attention Warning may Basic function suggest a break depending on the driver’s driving pattern or habits, even if the driver doesn’t feel fatigue. Driver Attention Warning is a supplemental function and may not be able to determine whether the driver is inattentive.
Page 464 Driver Assistance System Leading Vehicle Departure Alert CAUTION function Leading Vehicle Departure Alert is a supplemental function and may not alert the driver whenever the front vehicle departs from a stop. Always check the front of the vehicle and road conditions before departure.
Page 465 ) warning light will illuminate on the cluster. Driver Attention Warning will cluster. If this occurs, have the vehicle operate properly when snow, rain or inspected by an authorized HYUNDAI foreign material is removed. If Driver dealer. Attention Warning does not operate...
Page 466 Driver Assistance System Limitations of Driver Attention When the vehicle ahead sharply steers Warning Driver Attention Warning may not work properly in the following situations: The vehicle is driven violently The vehicle intentionally crosses over lanes frequently The vehicle is controlled by Driver Assistance system, such as Lane Keeping Assist B0337KO04...
Page 467 When a pedestrian or bicycle is When driving at a tollgate or between you and the vehicle ahead intersection, etc. B0337KO06 B0337KO08 If there is a pedestrian(s) or bicycle(s) If you pass a tollgate or intersection in between you and the vehicle in with lots of vehicles or you drive front, Leading Vehicle Departure Alert where lanes are merged or divided...
Page 468: Blind-Spot View Monitor (Bvm)
Driver Assistance System Blind-Spot View Monitor Settings Setting features Blind-Spot View With the engine on, select ‘Driver View Monitor’ from the Settings menu to turn on Blind-Spot View Monitor and deselect to turn off the function. B0342EU01 Blind-Spot View Monitor Operation B0342EU02 A : Left side, B : Right side...
Page 469 Off conditions not display properly, have the vehicle inspected by an authorized HYUNDAI When the turn signal turns off, the dealer. image on the instrument cluster will turn off.
Page 470 Driver Assistance System Smart Cruise Control is designed to Detecting sensor help detect the vehicle ahead and help maintain the desired speed and minimum distance between the vehicle ahead. Overtaking Acceleration Assist While Smart Cruise Control is operating, if the function judges that the driver is determined to overtake the vehicle in front, acceleration will be assisted.
Page 471 Smart Cruise Control Settings Information Smart Cruise Control While Smart Cruise Control is operating with ‘Based on Driving Style’ selected, if you press and hold the Vehicle Distance ( ) button, 'Based on Driving Style' will change deactivate. If you press and hold the Vehicle Distance ) button again, 'Driving Style Setting' will activate.
Page 472 Driver Assistance System Smart Cruise Control Operation Operating conditions Basic function Smart Cruise Control operates when the following conditions are satisfied. The gear is in D (Drive) The driver’s door is closed EPB (Electronic Parking Brake) is not applied B0312EU05 Your vehicle speed is within the Warning Volume operating speed range...
Page 473 Turning on Smart Cruise Control Operating conditions for Acceleration Assist Overtaking Acceleration Assist operates when the turn signal indicator is turned on to the left while Smart Cruise Control is operating, and the following conditions are satisfied: Your vehicle speed is above 40 mph (60 km/h) A vehicle is detected in front of your vehicle...
Page 474 Driver Assistance System Setting vehicle distance Increasing set speed B0348KO01 B0348KO02 Each time the button is pressed, the Push the + switch up and release headway changes as follows: it immediately. The set speed will increase by 1 mph (1 km/h) each time the switch is operated in this manner.
Page 475 Decreasing set speed Temporarily cancelling Smart Cruise Control B0348KO03 Push the - switch down and release B0348KO04 it immediately. The set speed will Press the switch or depress the decrease by 1 mph (1 km/h) each time brake pedal to temporarily cancel Smart the switch is operated in this manner.
Page 476 Driver Assistance System Turning off Smart Cruise Control Display and Control Basic function You can see the status of the Smart Cruise Control operation in the Driving Assist view on the cluster. Refer to “View Modes” section in chapter 4. Smart Cruise Control will be displayed as below depending on the status of the function.
Page 477 Based on Driving Style operation Information The distance of the front vehicle on the cluster is displayed according to the actual distance between your vehicle and the vehicle ahead. The target distance may vary according to the vehicle speed and the set distance level.
Page 478 Driver Assistance System Temporarily cancelling Smart Cruise Smart Cruise Control conditions not satisfied Control B0348EU05 B0348EU04 If the Driving Assist button, + switch, Smart Cruise Control will be temporarily - switch or switch is operated canceled automatically when: when Smart Cruise Control operating The vehicle speed is above 130 mph conditions are not satisfied, the ‘Smart (210 km/h)
Page 479 Warning road conditions ahead Collision Warning B0348EU07 B0313EU01 In the following situation, the ‘Watch for While Smart Cruise Control is operating, surrounding vehicles’ warning message when the collision risk with the vehicle will appear on the cluster, and an audible ahead is high, the ‘Collision Warning’...
Page 480 Driver Assistance System Smart Cruise Control may not WARNING operate properly if interfered by Take the following precautions when strong electromagnetic waves. using Smart Cruise Control: Smart Cruise Control may not Smart Cruise Control does not detect an obstacle in front and lead substitute for proper and safe to a collision.
Page 481 Have the vehicle inspected by an Smart Cruise Control may not operate authorized HYUNDAI dealer. for 15 seconds after the vehicle is started or the front view camera or front radar is initialized.
Page 482 Driver Assistance System Smart Cruise Control disabled Limitations of Smart Cruise Control Smart Cruise Control may not operate properly, or it may operate unexpectedly under the following circumstances: The detecting sensor or the surroundings are contaminated or damaged Washer fluid is continuously sprayed, or the wiper is on The camera lens is contaminated due to tinted, filmed or coated windshield,...
Page 483 Only part of the vehicle is detected The vehicle in front is bent out of shape The vehicle in front has no tail lights, tail lights are located unusually, etc. The front vehicle’s speed is fast or slow The brightness outside is low, and the tail lamps are not on or are not bright With a vehicle in front, your vehicle changes lane at low speed...
Page 484 Driver Assistance System Driving on a curved road Driving on an inclined road B0349KO07 B0314KO11 On curves, Smart Cruise Control may During uphill or downhill driving, the not detect a vehicle in the same lane, Smart Cruise Control may not detect and may accelerate to the set speed.
Page 485 Changing lanes Situations when detecting are limited B0349KO03 B0314KO16 In the following cases, some vehicles, B0314KO14 pedestrians or animals in your lane A : Your vehicle, B : Lane changing vehicle cannot be detected by the sensor: When a vehicle moves into your lane - Vehicles offset to one side from an adjacent lane, it cannot be - Slow-moving vehicles or sudden...
Page 486 Driver Assistance System Adjust your vehicle speed by depressing the brake pedal according to the road and driving conditions ahead. In the following cases, the vehicle in front cannot be detected by the sensor: - You are steering your vehicle - Driving on narrow or sharply curved roads B0349KO05...
Page 487 Information Information This device complies with Part 15 of the Radio frequency radiation exposure FCC rules. information: Operation is subject to the following three This equipment complies with FCC conditions: radiation exposure limits set forth for an uncontrolled environment. 1. This device may not cause harmful interference, and This equipment should be installed and operated with minimum distance of 8 in.
Page 488: Navigation-Based Smart Cruise Control (Nscc)
Driver Assistance System Navigation-based Smart Cruise Control Navigation-Based Smart Cruise helps drive at a certain speed according Control Settings to the road conditions when driving on highways (or motorways) by using road information from the navigation system while Smart Cruise Control is operating. Information Navigation-based Smart Cruise Control is available only on controlled access...
Page 489 Navigation-Based Smart Cruise Navigation-based Smart Cruise Control display and control Control Operation Operating conditions When Navigation-based Smart Cruise Control operates, it will be displayed on Navigation-based Smart Cruise Control the cluster as follows: is ready to operate if all of the following conditions are satisfied: Smart Cruise Control is operating Driving on main roads of highways...
Page 490 Driver Assistance System Highway Curve Zone Auto Slowdown WARNING Depending on the curve ahead on the highway (or motorway), the vehicle will decelerate, and after passing the curve, the vehicle will accelerate to Smart Cruise Control set speed. Vehicle deceleration time may differ depending on the vehicle speed and the degree of the curve on the road.
Page 491 Limitations of Navigation-Based Android Auto or Car Play is operating Smart Cruise Control The navigation cannot detect the current vehicle position (for example, Navigation-based Smart Cruise Control elevated roads including overpass may not operate properly under the adjacent to general roads or nearby following circumstances: roads exist in a parallel way) The navigation is not working properly...
Page 492 Driver Assistance System B0353EU01 B0353EU02 : Set route, : Branch line, : Driving route, : Set route, : Branch line, : Driving route, : Main road, : Curved road section : Main road, : Curved road section When there is a difference between When there is a difference between the navigation set route (branch line) the navigation route (main road)
Page 493 WARNING Navigation-based Smart Cruise Control is not a substitute for safe driving practices, but a convenience function. Always have your eyes on the road, and it is the responsibility of the driver to avoid violating traffic laws. The navigation’s speed limit information may differ from the B0353EU03 actual speed limit information on the...
Page 494 Driver Assistance System If the driver accelerates and Information releases the accelerator pedal while This device complies with Part 15 of the Navigation-based Smart Cruise FCC rules. Control is operating, the vehicle may not decelerate sufficiently or may Operation is subject to the following three rapidly decelerate to a safe speed.
Page 495 Lane Following Assist is designed to help Lane Following Assist Settings detect lane markings and/or vehicles on Warning Volume the road, and assists the driver’s steering to help center the vehicle in the lane. Detecting sensor B0312EU05 With the engine on, select ‘Driver B0311KO07 menu to change the Warning Volume to A : Front view camera...
Page 496: Lane Following Assist (Lfa)
Driver Assistance System Lane Following Assist Operation Lane Following Assist Turning Lane Following Assist On/ B0356KO01 If the vehicle ahead and/or both lane markings are detected and your vehicle B0317KO01 speed is below 120 mph (200 km/h), the With the engine on, shortly press the green indicator light illuminates on Lane Driving Assist button located on the...
Page 497 Hands-off warning WARNING The steering wheel may not be assisted if the steering wheel is held very tight or the steering wheel is steered over a certain degree. Lane Following Assist does not operate at all times. It is the responsibility of the driver to safely steer the vehicle and to maintain the vehicle in its lane.
Page 498 If this occur, have the vehicle inspected by The images and colors in the cluster an authorized HYUNDAI dealer. may differ depending on the cluster type or theme selected from the cluster. Limitations of Lane Following Assist...
Page 499 Basic function Highway Lane Change Assist (if equipped) Highway Driving Assist is designed to Highway Lane Change Assist function do the following while driving on the helps change lanes to the direction the highway: driver slightly moves the turn signal switch if the function judges that lane Help detect vehicles ahead change is possible.
Page 500 Driver Assistance System Detecting sensor (if equipped) Highway Driving Assist Settings B0359EU01 B0311KO07 With the engine on, select or Convenience’ from the Settings menu to set whether use each function. Basic function If ‘Highway Driving Assist’ is selected, it helps maintain distance from the vehicle ahead, maintain the set speed, and helps center the vehicle in the lane.
Page 501 Have With the engine on, select ‘Driver the vehicle inspected by an authorized HYUNDAI dealer. menu to change the Warning Volume If the engine is restarted, the functions to ‘High’, ‘Medium’, ‘Low’ or ‘Off’ for will maintain the last setting.
Page 502: Highway Driving Assist (Hda)
Driver Assistance System Highway Driving Assist Information Operation For more details on the display refer Basic function to “Smart Cruise Control (SCC)” and Displaying operating status “Lane Following Assist (LFA)” sections in this chapter. You can see the status of the Highway Driving Assist operation in the Driving The images and colors in the Assist view on the cluster.
Page 503 B0348EU06 B0317EU01 Restarting after stopping Hands-off warning When Highway Driving Assist is If the driver takes their hands off the operating, your vehicle will stop if the steering wheel for several seconds, the vehicle ahead of you stops. Also, if the ‘Keep hands on steering wheel’...
Page 504 Driver Assistance System B360EU03 B0360KO04 Driving speed limit Driving to one side within lane (if equipped) When Highway Driving Assist is canceled by the hands-off warning, The driving When vehicle speed is above 40 mph (60 speed will be limited. km/h), if a vehicle around you is driving at a close distance, your vehicle will While Driving Speed Limit function...
Page 505 Highway Lane Change Assist (if Information equipped) Driving Speed Limit helps you drive Displaying operating status below 40 mph (60 km/h). At this time, You can see the status of the Highway the vehicle decelerates due to the Lane Change Assist function operation in vehicle ahead.
Page 506 Driver Assistance System (4) Message Information Message is displayed when the While Lane Change Assist function function does not operate even is turned on (indicator on), Lane though the turn signal lever is used. Following Assist will not cancel even Message is displayed when if the turn signal indicator or hazard the function is canceled while...
Page 507 Highway Lane Change Assist operating When the turn signal lever is placed at B position for a certain period of time, the green arrow will appear. At this time, even when the lever is released and returns to it’s original position (1), lane change will still be assisted.
Page 508 Driver Assistance System Highway Lane Change Assist standby WARNING Highway Lane Change Assist function While Highway Driving Assist is will be in the standby state when one of operating, the function will cancel if the ready state condition is not satisfied, one of the following occurs: or when entering or driving on one of the - Highway Driving Assist is turned...
Page 509 Highway Lane Change function is not working properly, the ‘Check Highway Driving Assist (HDA) system’ or ‘Check Lane Change Assist function’ warning message will appear, and the warning light will illuminate on the cluster. Have the vehicle inspected by an authorized HYUNDAI dealer. 7-107...
Page 510 Driver Assistance System Highway Driving Assist may WARNING inadvertently operate or turn off The driver is responsible for depending on road conditions controlling the vehicle for safe (navigation information) and driving. surroundings. Always have your hands on the Lane Following Assist function may steering wheel while driving.
Page 511 Limitations of Highway Driving Information Assist This device complies with Part 15 of the Highway Driving Assist and Highway FCC rules. Lane Change function may not operate Operation is subject to the following three properly, or may not operate under the conditions: following circumstances: 1.
Page 512 Driver Assistance System Rear View Monitor shows the area Rear View Monitor Settings behind the vehicle to assist you when Warning Volume parking or backing up. Detecting sensor B0363EU01 With the engine on, select 'Driver B0378KO01 A : Wide-rear view camera the Setting menu.
Page 513 Camera settings Extended Rear View Monitor Keeps displaying the rear view when shifting from R (Reverse) to N (Neutral) or D (Drive). When exceeding a certain speed, the rear view stops displaying. Rear View Parking Guide Lines If ‘Rear view Parking Lines’ is selected, the rear view parking guide lines and reartop view guide lines will be displayed at the left side of the infotainment...
Page 514 Driver Assistance System Rear View Monitor Operation Rear view Parking/View button B0364EU01 Operating conditions B0364KO01 Press the Parking/View button while Shift the gear to R (Reverse), the rear view will appear on the screen. the gear is in P (Park) to turn on Rear View Monitor.
Page 515 When Rear View Monitor is not working properly, or the screen flickers, or the camera image does not display properly, have the vehicle inspected by an authorized HYUNDAI dealer. Limitations of Rear View Monitor When the vehicle is stopped for a long B0364EU02...
Page 516 Driver Assistance System Surround View Monitor can assist in Surround View Monitor Settings parking by allowing the driver to see Warning Volume around the vehicle. Detecting sensor B0363EU01 With the engine on, select 'Driver B0366KO01 the Setting menu. If 'Parking Safety Priority' is selected, the vehicle lowers all other audio volumes when Surround View Monitor is operating for safe parking.
Page 517 Camera settings Rear View Parking Guidance When the ‘Rear View Parking Lines’ is selected, parking guidance is displayed in the rear view. Information The horizontal guideline shows the distance of 1.6 ft. (0.5 m), 3.3 ft. (1 m) and 7.6 ft. (2.3 m) from the vehicle. B0367EU02 You can change Surround View Monitor ‘Display Contents’...
Page 518: Surround View Monitor (Svm)
Driver Assistance System Surround View Monitor Front view Operation Parking/View button B0368EU01 The front image is displayed on the screen when the gear is in N (Neutral) or B0364KO01 D (Drive) to assist in parking. Using the Press the Parking/View button to turn view button you may select top view,...
Page 519 Rear view 3D view The rear image is displayed on the screen The 3D view shows the image around the when the gear is in P (Park) to assist in vehicle from various angles. parking. Using the view button You can change angles by tapping the may select top view, front view, side view screen.
Page 520 HYUNDAI dealer. The image shown on the screen may differ from the actual distance of the Limitations of Surround View object.
Page 521 Rear Cross-Traffic Collision-Avoidance Detecting sensor Assist is designed to help detect vehicles approaching from the rear left and right side while your vehicle is reversing, and warn the driver that a collision is imminent with a warning message and an audible warning. Also, braking is assisted to help prevent collision.
Page 522 Driver Assistance System Rear Cross-Traffic Collision- Avoidance Assist Settings Setting features B0371EU02 Warning Volume With the engine on, select ‘Driver B0371EU01 Rear Cross-Traffic Safety menu to change the Warning Volume to With the engine on, select ‘Driver ‘High’, ‘Medium’, ‘Low’ or ‘Off’ for Rear Cross-Traffic Collision-Avoidance Assist.
Page 523 Rear Cross-Traffic Collision- Rear Cross-Traffic Collision-Avoidance Assist will operate when all the Avoidance Assist Operation following conditions are satisfied: Rear Cross-Traffic Collision-Avoidance - The gear is shifted to R (Reverse) Assist will warn and help control the - Vehicle speed is below 5 mph (8 vehicle depending on collision risk level: km/h) ‘Collision Warning’, ‘Emergency Braking’...
Page 524 Driver Assistance System Emergency Braking Rear Cross-Traffic Collision-Avoidance Assist will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) - Vehicle speed is below 5 mph (8 km/h) - The approaching vehicle is within approximately 5 ft.
Page 525 Stopping vehicle and ending brake You may not hear the warning sound of Rear Cross-Traffic Collision- control Avoidance Assist if the surrounding is noisy. Rear Cross-Traffic Collision- Avoidance Assist may not operate if the driver applies the brake pedal to avoid collision.
Page 526 ‘Check side view mirror warning light’ warning message will appear on the cluster for several seconds, and the master ) warning light will illuminate on the cluster. If this occur, have the vehicle inspected by an authorized HYUNDAI dealer. 7-124...
Page 527 The tire pressure is low or a tire is Assist does not operate properly after it damaged is removed, have the vehicle inspected The braking system has been modified by an authorized HYUNDAI dealer. Remote Smart Parking Assist is operating (if equipped) WARNING Even though the warning message...
Page 528 Driver Assistance System When the vehicle is in a complex WARNING parking environment Driving near a vehicle or structure B0373KO04 B0373KO03 Rear Cross-Traffic Collision- Avoidance Assist may detect vehicles A : Structure which are parking or pulling out Rear Cross-Traffic Collision- near your vehicle (for example, a Avoidance Assist may be limited vehicle leaving beside your vehicle,...
Page 529 When the vehicle is parked When the vehicle is on or near a diagonally slope B0373KO05 B0373KO06 Rear Cross-Traffic Collision- Rear Cross-Traffic Collision- Avoidance Assist may be limited Avoidance Assist may be limited when backing up diagonally, when the vehicle is on a uphill or and may not detect the vehicle downhill slope, or near it, and may approaching from the left or right.
Page 530 Driver Assistance System Pulling into the parking space where When the vehicle is parked rearward there is a structure B0373KO08 B0373KO07 Rear Cross-Traffic Collision- Avoidance Assist may detect vehicles A : Structure, B : Wall passing by behind you when parking Rear Cross-Traffic Collision- in reverse into a parking space.
Page 531 Information This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
Page 532 Driver Assistance System Parking Distance Warning will help warn Reverse Parking Distance the driver if an obstacle is detected Warning Settings within a certain distance when the Warning volume vehicle is moving forward or in reverse at low speeds. Detecting sensor B0371EU02 With the vehicle on, select ‘Driver Settings menu to change the Warning...
Page 533 Parking Distance Warning Reverse Parking Distance Warning Operation Reverse Parking Distance Warning will operate under the following conditions. Parking Safety button The gear is shifted to R (Reverse). Vehicle speed is below 6 mph (10 km/h). Warning indicator Distance Warning when from object sound...
Page 534 If it still does not work Warning system limited. Ultrasonic properly, have the vehicle inspected by sensor blocked’ warning message an authorized HYUNDAI dealer. appears on the instrument cluster. The audible warning does not sound. Parking Distance Warning will operate properly when snow, rain or foreign The buzzer sounds intermittently.
Page 535 Limitations of Parking Distance The following objects may not be detected: Warning - Sharp or slim objects, such as ropes, Parking Distance Warning may not chains or small poles. operate properly when: - Narrow objects, such as corners of a - Moisture is frozen to the sensor square column - Sensor is covered with foreign...
Page 536 It varies depending on the speed of the vehicle or the shape of a person, animal, or object. If the Parking Distance Warning does not operate properly, have the vehicle inspected by an authorized HYUNDAI dealer. 7-134...
Page 537 Forward/Reverse Parking Distance Forward/Reverse Parking Warning can help warn the driver if an Distance Warning Settings obstacle is detected within a certain Warning Volume distance when the vehicle is moving forward or in reverse at low speeds. Detecting sensor B0371EU02 Volume’...
Page 538 Driver Assistance System Forward/Reverse Parking Forward Parking Distance Warning Distance Warning Operation Forward Parking Distance Warning will operate when one of the condition is Parking Safety button satisfied. The gear is shifted from R (Reverse) to D (Drive) with Reverse Parking Distance Warning on The gear is in D (Drive) and the Parking Safety button indicator light...
Page 539 When ‘Parking Distance Warning Auto Reverse Parking Distance Warning On’ is deselected, and the vehicle’s Reverse Parking Distance Warning will forward speed is above 18 mph (30 operate under the following conditions. km/h), the Parking Safety button The gear is shifted to R (Reverse). indicator will turn off.
Page 540 The ‘Ultrasonic sensor error or operate properly after obstruction (snow, blockage’ warning message appears rain, or foreign material) is removed on the cluster. (including trailer, carrier, etc., from the rear bumper), have the vehicle inspected by an authorized HYUNDAI dealer. B0377EU01 B0377EU02 7-138...
Page 541 - Attaching equipment or accessories the vehicle or the shape of a person, next to the ultrasonic sensors animal, or object. If the Parking Distance Warning does not operate properly, have the vehicle inspected by an authorized HYUNDAI dealer. 7-139...
Page 542 Driver Assistance System Reverse Parking Collision-Avoidance Reverse Parking Collision- Assist can warn the driver or assist with Avoidance Assist Settings braking to help reduce the possibility of Parking Safety collision with a pedestrian or an object With the engine on, select or deselect while driving at low speed.
Page 543 Reverse Parking Collision- Operating conditions Avoidance Assist Operation If Reverse Parking Collision-Avoidance Assist detects a risk of collision behind the vehicle with a pedestrian or an object, Reverse Parking Collision- Avoidance Assist will warn the driver with an audible warning and warning message on the cluster.
Page 544 Parking Collision-Avoidance Assist will you with braking. Braking assist is turn off automatically. Have the vehicle released after 5 minutes. Immediately inspected by an authorized HYUNDAI depress the brake pedal and check dealer. vehicle surroundings. Braking assist is also released in the following conditions...
Page 545 Reverse Parking Collision-Avoidance Limitations of Reverse Parking Assist disabled Collision-Avoidance Assist Reverse Parking Collision-Avoidance Assist may not assist braking or warn the driver even if there are pedestrians or objects under the following circumstances: Problems with vehicle - Any non-factory equipment or accessory is installed - Your vehicle is unstable due to an accident or other causes...
Page 546 Driver Assistance System Problems with pedestrian or object Reverse Parking Collision-Avoidance Assist may unnecessarily warn the driver - The pedestrians are difficult to or assist with braking even if there are detect- There is ground height no pedestrians or objects under the difference between the vehicle and following circumstances: the pedestrian...
Page 547 Noise may be heard when sudden WARNING braking occurs to avoid a collision. Take the following precautions when If any other warning sound such using Reverse Parking Collision- as the seat belt warning chime is Avoidance Assist: already generated, Reverse Parking Always exercise extreme caution Collision-Avoidance Assist warning while driving.
Page 548 Reverse Parking Collision-Avoidance Assist may not operate properly if the wide angle cameras or the ultrasonic sensor(s) is forcibly moved out of proper alignment. Have the vehicle inspected by an authorized HYUNDAI dealer. 7-146...
Page 549 Take the following precautions to maintain optimal performance of the detecting sensors: Never disassemble the detecting sensor or sensor assembly, or cause any damage to it. If the detecting sensors need repair, have the vehicle inspected by an authorized HYUNDAI dealer. 7-147...
Page 550 Driver Assistance System Remote Smart Parking Assist Remote Smart Parking Assist may malfunction if the vehicle Settings bumper height or ultrasonic sensor Warning Volume installation has been modified or damaged. Any non-factory installed equipment or accessories may also interfere with the sensor performance.
Page 551 Remote Smart Parking Assist Operation Remote Smart Parking Assist button Parking/View button Parking Safety button Smart key B0384KO01 B0376KO01 B0384KO02 Location Name Symbol Description Press and hold the Parking/View button to turn Parking/View on Remote Smart Parking Assist. Also, Forward/ button Reverse Parking Distance warning will automatically Inside...
Page 552 Driver Assistance System Remote Operation Operating order Remote Operation operates in the following order: 1. Getting ready to remotely move forward and backward 2. Remotely moving forward and backward 1. Getting ready to remotely move forward B0384KO04 and backward There are two ways to operate Remote Operation function.
Page 553 2. Remotely moving forward and Information backward Remote Operation can control the vehicle remotely using the smart key outside the vehicle. Check that all smart keys are outside the vehicle when using Remote Operation function. Remote Operation function will operate only when the smart key is within 13 ft.
Page 554 Driver Assistance System Remote Operation function operation WARNING status When using Remote Operation function, make sure that all Hazard Operation passengers have gotten out of the Smart key LED warning status vehicle. light If the vehicle’s battery is discharged Green LED Under or Remote Smart Parking Assist continuously...
Page 555 How to turn off Remote Operation The function will cancel in the following function while operating conditions when: Press the Parking/View ( ) button When Remote Operation function is while the infotainment system screen canceled, the vehicle will automatically guides the driver using method 2. stop, shift the gear to P (Park) and engage EPB (Electronic Parking Brake).
Page 556 Parking Assist. Always look around and Remote Smart Parking Assist, and have pay attention when using Remote Smart the vehicle inspected by an authorized Parking Assist. HYUNDAI dealer. B0387EU03 Remote Smart Parking Assist standby ‘Parking Assist Conditions Not Met’ message appears when Parking/View...
Page 557 Limitations of Remote Smart Parking There is a circular pillar or narrow pillar, or a pillar surrounded by objects Assist such as fire extinguisher, etc., near the In the following circumstances, Remote parking space Smart Parking Assist performance to The road surface is bumpy (curbstone, park or exit the vehicle may be limited, speed bump, etc.) there may be a risk of collision, or...
Page 558 Driver Assistance System Remote Smart Parking Assist may not Parking behind a truck operate properly under the following circumstances: Parking on inclines B0387KO06 Do not use Remote Smart Parking Assist around vehicles with higher ground clearance, such as a bus, B0387KO04 truck, etc.
Page 559 Parking in a parking space with a Parking in snow vehicle on one side only B0387KO11 Snow may interfere with sensor B0387KO08 operation, or Remote Smart Parking If Remote Smart Parking Assist is Assist may cancel if the road is used, when parking in a parking space slippery while parking.
Page 560 Parking Distance Warning sounds Have the vehicle inspected by an while Remote Smart Parking authorized HYUNDAI dealer. Assist is operating, it means the Noise may be heard when braking obstacle detected is close to your occurs by Remote Smart Parking vehicle.
Page 561 Front Radar - For Canada The radio frequency components complies: - For USA OANATEL343 OANATEL342 7-159...
Page 562 Driver Assistance System Front Corner Radar/Rear Corner - For Canada Radar The radio frequency components complies: - For USA OANATEL353 OANATEL352 7-160...
Page 563: Emergency Situations
8. Emergency Situations Hazard Warning Flasher ................... 8-2 In Case of an Emergency While Driving ............8-2 If the Engine Stalls While Driving ................8-2 If the Engine Stalls at a Crossroad or Crossing ............8-2 If You Have a Flat Tire While Driving ................8-3 If the Engine Will Not Start ................
Page 564: Hazard Warning Flasher
Turn on your hazard warning flasher. Try to start the engine again. If your vehicle will not start, contact an authorized HYUNDAI dealer or seek B0389KO01 other qualified assistance. The hazard warning flasher serves as...
Page 565: If You Have A Flat Tire While Driving
Drive off the If the vehicle still does not start, call road as far as possible and park on an authorized HYUNDAI dealer for firm, level ground. If you are on a assistance. divided highway, do not park in the...
Page 566: Jump Starting
Emergency Situations JUMP STARTING Jump starting can be dangerous if done If acid gets into your eyes, flush your incorrectly. Follow the jump starting eyes with clean water for at least 15 procedure in this section to avoid serious minutes and get immediate medical injury or damage to your vehicle.
Page 567 Jump starting procedure 1. Position the vehicles close enough that the jumper cables will reach, but do not allow the vehicles to touch. 2. Avoid fans or any moving parts in the engine compartment at all times, even when the vehicles are turned off. 3.
Page 568 WARNING vehicle checked by an authorized While jump starting your vehicle, avoid HYUNDAI dealer. the positive (+) and negative (-) cables to come in contact. A spark could cause Disconnect the jumper cables in the personal injury.
Page 569: If The Engine Overheats
5. If engine coolant is leaking out, stop is safe to do so. the engine immediately and call the nearest authorized HYUNDAI dealer 2. Shift the gear to P (Park) and set the for assistance. parking brake. If the air conditioning is ON, turn it OFF.
Page 570 7. Proceed with caution, keeping alert for further signs of overheating. If overheating happens again, call an authorized HYUNDAI dealer for assistance. B0406KO01 CAUTION Serious loss of coolant indicates a...
Page 571: Check Tire Pressure
Check Tire Pressure Tire Pressure Monitoring System WARNING Over-inflation or under-inflation can reduce tire life, adversely affect vehicle handling, and lead to sudden tire failure that may cause loss of vehicle control resulting in an accident. Each tire, including the spare (if provided), should be checked monthly B0091EU12 when cold and inflated to the inflation...
Page 572: Low Tire Pressure Indicator
If any of the below happens, have displayed on the cluster LCD display, the system checked by an authorized one or more of your tires is significantly HYUNDAI dealer. under-inflated. The Low Tire Pressure 1. The Low Tire Pressure Telltale/ TPMS Position Telltale will indicate which...
Page 573: Tpms (Tire Pressure Monitoring System) Malfunction Indicator
Monitoring System. you have the low pressure tire repaired Have the system checked by an and replaced on the vehicle. authorized HYUNDAI dealer as soon as possible. CAUTION NOTICE In winter or cold weather, the Low Tire...
Page 574: Changing A Tire With Tpms
Each wheel is equipped with a tire on. Have the flat tire repaired by an pressure sensor mounted inside the tire authorized HYUNDAI dealer as soon as behind the valve stem (except for the possible or replace the flat tire with the spare tire).
Page 575 IF YOU HAVE A FLAT TIRE WARNING WARNING Tampering with, modifying, or disabling the Tire Pressure Monitoring System Changing a tire can be dangerous. (TPMS) components may interfere Follow the instructions in this section with the system’s ability to warn the when changing a tire to reduce the risk driver of low tire pressure conditions of serious injury or death.
Page 576: Jack And Tools
Emergency Situations Jack and Tools Removing and Storing the Spare Tire B0413EU01 B0413EU04 Your spare tire is stored underneath your vehicle, directly below the cargo area. To remove the spare tire: 1. Open the liftgate. 2. Find the plastic hex bolt cover and remove the cover with a coin or flat- blade screwdriver.
Page 577: Changing Tires
Changing Tires WARNING A vehicle can slip or roll off of a jack causing serious injury or death to you or those nearby. Take the following safety precautions: Never place any portion of your body under a vehicle that is supported by B0413EU06 a jack.
Page 578 Emergency Situations Follow these steps to change your vehicle’s tire: 1. Park on a level, firm surface. 2. Move the shift button into P (Park), apply the parking brake, and place the ignition switch or press Engine Start/ Stop button in the LOCK/OFF position. 3.
Page 579 Make sure the vehicle is stable on the until they are tight. After changing jack. tires, have an authorized HYUNDAI dealer tighten the lug nuts to their 9. Loosen the lug nuts with the wheel proper torque as soon as possible. The...
Page 580 Consult an authorized HYUNDAI dealer for assistance. If any of the equipment such as the jack, wheel nuts, studs, or other equipment...
Page 581 NOTICE When driving with the compact spare tire mounted to your vehicle: When the original tire and wheel are Check the tire pressure after installing repaired and reinstalled on the vehicle, the compact spare tire. The compact the lug nut torque must be set correctly. spare tire should be inflated to 60 psi The correct lug nut tightening torque is (420 kPa).
Page 582: Jack Label
Emergency Situations Jack Label OOS067043 The actual Jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack. Model Name Maximum allowable load When using the jack, set your parking brake. When using the jack, stop the engine.
Page 583: Towing
B0412EU02 : Dollies If emergency towing is necessary, we recommend having it done by an authorized HYUNDAI dealer or a commercial tow-truck service. Proper lifting and towing procedures are necessary to prevent damage to the vehicle. The use of wheel dollies or flatbed is recommended.
Page 584 Emergency Situations CAUTION WARNING Do not tow the vehicle with the front If your vehicle is equipped with a wheels on the ground as this may rollover sensor, place the ignition cause damage to the vehicle. switch or press Engine Start/Stop button in the LOCK/OFF or ACC position when the vehicle is being towed.
Page 585: Removable Towing Hook
Removable Towing Hook 3. Install the towing hook by turning it clockwise into the hole until it is fully secured. 4. Remove the towing hook and install the cover after use. NOTICE Failure to properly tighten the towing hook may result in vehicle damage and deformation of related parts.
Page 586: Emergency Towing
B : Rear communicate with each other frequently. If towing is necessary, have it done by an authorized HYUNDAI dealer or a Before emergency towing, check that commercial tow truck service. the hook is not broken or damaged. If towing service is not available in...
Page 587 NOTICE To avoid damage to your vehicle and vehicle components when towing: Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. Do not use the towing hooks to pull a vehicle out of mud, sand or other conditions from which the vehicle cannot be driven out under its own...
Page 588: Maintenance
9. Maintenance Engine Compartment ..................9-3 Maintenance Services ..................9-4 Owner’s Responsibility ....................9-4 Owner Maintenance Precautions ................9-4 Owner Maintenance ..................9-5 Owner Maintenance Schedule ................... 9-6 Scheduled Maintenance Services ..............9-7 Normal Maintenance Schedule .................. 9-8 Maintenance Under Severe Usage Conditions ............9-11 Explanation of Scheduled Maintenance Items ..........9-13 Engine Oil ......................9-15 Checking the Engine Oil Level ...................
Page 589 Tires and Wheels ....................9-31 Tire Care ........................9-31 Recommended Cold Tire Inflation Pressures ............9-31 Check Tire Inflation Pressure ..................9-32 Tire Rotation .......................9-33 Wheel Alignment and Tire Balance ................9-34 Tire Replacement .......................9-34 Wheel Replacement ....................9-35 Tire Traction ........................9-35 Tire Maintenance......................9-35 Tire Sidewall Labeling ....................9-36 Tire Terminology and Definitions ................9-39 All Season Tires ......................
Page 590 ENGINE COMPARTMENT The actual engine compartment in the vehicle may differ from the illustration. A0419KO02 1. Engine coolant reservoir 6. Engine oil dipstick 2. Radiator cap 7. Windshield washer fluid reservoir 3. Brake fluid reservoir 8. Fuse/relay box 4. Air cleaner 9.
Page 591: Maintenance Services
HYUNDAI’s high service quality procedures can be done only by an standards and receives technical support authorized HYUNDAI dealer with special from HYUNDAI in order to provide you tools. with a high level of service satisfaction. Your vehicle should not be modified in any way.
Page 592: Owner Maintenance
OFF position. inspections that should be performed Block the tires (front and back) to by the owner or an authorized HYUNDAI prevent the vehicle from moving. dealer at the frequencies indicated to Remove loose clothing or jewelry...
Page 593: Owner Maintenance Schedule
Maintenance Owner Maintenance Schedule At least monthly: When you stop for fuel: Check coolant level in the engine coolant reservoir. Check the coolant level in the engine coolant reservoir. Check the operation of all exterior lights, including the stoplights, turn Check the windshield washer fluid signals and hazard warning flashers.
Page 594: Scheduled Maintenance Services
SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. Repeated driving short distance of less than 5 miles (8 km) in normal temperature or less than 10 miles (16 km) in freezing temperature Extensive engine idling or low speed driving for long distances Driving on rough, dusty, muddy, unpaved, graveled or salt-spread roads...
Page 595 Maintenance...
Page 597 Maintenance 9-10...
Page 598: Maintenance Under Severe Usage Conditions
Maintenance Under Severe Usage Conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Driving Maintenance item...
Page 599 Maintenance Severe driving conditions A. Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature or less than 10 miles (16 km) in freezing temperature B. Extensive engine idling or low speed driving for long distances C.
Page 600: Explanation Of Scheduled Maintenance Items
Check the fuel lines, fuel hoses and The automatic transmission fluid level connections for leakage and damage. does not need to be checked under Have an authorized HYUNDAI dealer normal usage conditions. replace any damaged or leaking parts Have the automatic transmission fluid immediately.
Page 601 Maintenance NOTICE Propeller Shaft The use of a non-specified fluid could Check the propeller shaft, boots, clamps, result in transmission malfunction and rubber couplings and center-bearing failure. rubber for cracks, deterioration, or damage. Replace any damaged parts Use only specified automatic and if necessary, repack the grease.
Page 602: Engine Oil
ENGINE OIL Checking the Engine Oil Level Engine oil is used for lubricating, cooling, and operating various hydraulic components in the engine. Engine oil consumption while driving is normal, and it is necessary to check and refill the engine oil regularly. Also, check and refill the oil level within the recommended maintenance schedule to prevent deterioration of oil performance.
Page 603: Checking The Engine Oil And Filter
Therefore, it is recommended that you inspect the Have engine oil and filter changed engine oil level regularly and refill it by an authorized HYUNDAI dealer if necessary. according to the Maintenance Schedule at the beginning of this chapter.
Page 604 CAUTION The engine oil is very hot immediately after the vehicle has been driven and can cause burns during replacement. Replace the engine oil after the engine oil has cooled down. WARNING Used engine oil may cause irritation or cancer of the skin if left in contact with the skin for prolonged periods of time.
Page 605: Engine Coolant
If the coolant level is low, add enough distilled (deionized) water to bring the level to the F mark, but do not overfill. If frequent additions are required, see an authorized HYUNDAI dealer for a cooling system inspection. 9-18...
Page 606 WARNING Information The coolant level is influenced by the Make sure the coolant cap is properly closed after refilling coolant. Otherwise engine temperature. Before checking or refilling the coolant, turn the engine off. the engine could be overheated whilst driving. WARNING The electric motor for the cooling fan may continue to...
Page 607: Changing Coolant
When adding coolant, use only Have coolant changed by an authorized deionized water, distilled water or soft HYUNDAI dealer according to the water for your vehicle and never mix Maintenance Schedule at the beginning hard water in the coolant filled at the of this chapter.
Page 608: Brake Fluid
If the fluid level is excessively low, have Use only the specified brake fluid (refer the system be checked by an authorized to “Recommended Lubricants and HYUNDAI dealer. Capacities” section in chapter 2). WARNING If the brake system requires frequent additions of fluid this could indicate a leak in the brake system.
Page 609: Washer Fluid
Maintenance WASHER FLUID Checking the Washer Fluid Level WARNING To prevent serious injury or death, take the following safety precautions when using washer fluid: Do not use engine coolant or antifreeze in the washer fluid reservoir. Engine coolant can severely obscure visibility when sprayed on the windshield and may cause loss of vehicle control resulting in an accident or damage to...
Page 610: Air Cleaner
B0446KO02 enter the air intake, or damage may 1. Pull down the air cleaner filter cover result. Use HYUNDAI genuine parts. Use of non-genuine parts could damage the engine. Do not blow the inner part of the air filter with compressed air. Dust or dirt may enter the air intake.
Page 611: Cabin Air Filter
Maintenance CABIN AIR FILTER Filter Inspection The cabin air filter should be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air- polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced sooner.
Page 612: Wiper Blades
WIPER BLADES Blade Inspection Front windshield wiper blade replacement Contamination of either the windshield or the wiper blades with foreign matter can reduce the effectiveness of the windshield wipers. Common sources of contamination are insects, tree sap, and hot wax treatments used by some commercial car washes.
Page 613 5. Rotate back the blade assembly so that it aligns with the wiper arm. To prevent damage to the wiper arms or other components, have the wiper blades replaced by an authorized HYUNDAI dealer. 9-26...
Page 614: Battery
BATTERY When lifting a plastic-cased battery, WARNING excessive pressure on the case may To prevent SERIOUS INJURY or DEATH cause battery acid to leak. Lift with a to you or bystanders, always follow battery carrier or with your hands on these precautions when working near opposite corners.
Page 615: For Best Battery Service
Maintenance NOTICE For Best Battery Service Always follow these instructions when handling your vehicle’s battery to prevent damage to your battery: When you do not use the vehicle for a long time in a low temperature area, disconnect the battery and keep it indoors.
Page 616: Battery Capacity Label
1. Turn off the battery charger main switch. 2. Unhook the negative clamp from the negative battery terminal. 3. Unhook the positive clamp from the positive battery terminal. Always use a Genuine HYUNDAI dealer approved battery when you replace the battery. 9-29...
Page 617: Reset Items
AGM battery be serviced Driving info/Since refueling/ by an authorized HYUNDAI dealer. Accumulated info (see chapter 4) For charging your AGM battery, use Integrated memory system (see only fully automatic battery chargers...
Page 618: Tires And Wheels
TIRES AND WHEELS Tire Care WARNING For proper maintenance, safety, and Tire failure may cause loss of maximum fuel economy, you must vehicle control resulting in an always maintain recommended accident. To reduce risk of SERIOUS tire inflation pressures and stay INJURY or DEATH, take the within the load limits and weight following precautions:...
Page 619: Check Tire Inflation Pressure
If you overfill the tire, release air by it checked by an authorized pushing on the metal stem in the HYUNDAI dealer. center of the tire valve. Recheck the Over-inflation produces a harsh tire pressure with the tire gauge. Be...
Page 620: Tire Rotation
Tire Rotation Information To equalize tread wear, HYUNDAI The outside and inside of the recommends that the tires unsymmetrical tire is distinguishable. be rotated according to the When installing an unsymmetrical maintenance schedule or sooner if tire, be sure to install the side marked irregular wear develops.
Page 621: Wheel Alignment And Tire Balance
Tires degrade over time, even when they are not being used. Regardless of the remaining tread, HYUNDAI recommends that tires be replaced after six (6) years of normal service. Heat caused by hot climates or frequent high loading conditions B0462KO01 can accelerate the aging process.
Page 622: Wheel Replacement
Compact spare tire replacement Wheel Replacement (if equipped) When replacing the metal wheels A compact spare tire has a shorter for any reason, make sure the new tread life than a regular size tire. wheels are equivalent to the original Replace it when you can see the factory units in diameter, rim width tread wear indicator bars on the tire.
Page 623: Tire Sidewall Labeling
Maintenance Tire Sidewall Labeling Example tire size designation: (These numbers are provided as This information identifies and an example only; your tire size describes the fundamental designator could vary depending on characteristics of the tire and also your vehicle.) provides the tire identification number (TIN) for safety standard 245/60 R18 105H certification.
Page 624 DOT : XXXX XXXX OOOO Tire speed ratings The chart below lists many of the The front part of the DOT shows a different speed ratings currently plant code number, tire size and being used for passenger vehicle tread pattern and the last four tires.
Page 625 Maintenance 5. Maximum permissible inflation Tread wear pressure The tread wear grade is a comparative rating based on the This number is the greatest amount wear rate of the tire when tested of air pressure that should be put in under controlled conditions on a the tire.
Page 626: Tire Terminology And Definitions
Tire Terminology and Definitions Temperature - A, B & C The temperature grades are A (the Air pressure highest), B and C representing the The amount of air inside the tire tire’s resistance to the generation pressing outward on the tire. Air of heat and its ability to dissipate pressure is expressed in pounds per heat when tested under controlled...
Page 627 Maintenance Bias ply tire Intended outboard sidewall A pneumatic tire in which the plies The side of an asymmetrical tire, are laid at alternate angles less than that must always face outward when 90 degrees to the centerline of the mounted on a vehicle.
Page 628 Maximum loaded vehicle weight Pneumatic tire The sum of curb weight; accessory A mechanical device made of rubber, weight; vehicle capacity weight; and chemicals, fabric and steel or other production options weight. materials, that, when mounted on an automotive wheel provides the Normal occupant weight traction and contains the gas or fluid that sustains the load.
Page 629: All Season Tires
Uniform Tire Quality Grading Standards is a tire information Summer Tires system that provides consumers HYUNDAI specifies summer tires on with ratings for a tire’s traction, some models to provide superior temperature and treadwear. performance on dry roads. Summer...
Page 630: Snow Tires
Snow Tires Longer wearing tires can be more susceptible to irregular tread wear. If you equip your car with snow It is very important to follow the tire tires, they should be the same size rotation interval in this chapter to and have the same load capacity as achieve the tread life potential of the original tires.
Page 631: Low Aspect Ratio Tires
If the tire is subjected to a severe impact, have the tire and wheel inspected by an authorized HYUNDAI dealer. 9-44...
Page 632: Fuses
If the replacement fuse blows, this indicates an electrical problem. Avoid using the system involved and B0466KO02 immediately consult an authorized HYUNDAI dealer. WARNING NEVER replace a fuse with anything but another fuse of the same rating. A higher capacity fuse could cause damage and possibly cause a fire.
Page 633: Instrument Panel Fuse Replacement
If it fits loosely, consult an authorized HYUNDAI dealer. In an emergency, if you do not have a spare fuse, use a fuse of the same rating from a circuit you may not need for operating the vehicle, such as the cigarette lighter fuse.
Page 634: Engine Compartment Panel Fuse Replacement
3. Remove the fuse panel cover by If the multi fuse is blown, consult an pressing the tap and pulling up. authorized HYUNDAI dealer. 4. Check the removed fuse; replace it if it is blown. To remove or insert the fuse, use the fuse puller in the engine compartment fuse panel.
Page 635: Fuse/Relay Panel Description
Maintenance Fuse/Relay Panel Description Information Instrument panel fuse panel Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. B0469KO01 Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/...
Page 636 Instrument panel fuse panel Fuse Fuse Name Protected Component Rating Passenger Abag Indicator Seat Belt Indicator MODULE 4 7.5A Data Link Connector Stop Lamp Switch Driver Door Module SRS Control Module AIR BAG1 Passenger Occupant Detection Sensor BRAKE 7.5A SWITCH Stop Lamp Switch Low DC-DC Converter (Audio) A/V &...
Page 637 Maintenance Fuse Fuse Name Protected Component Rating Crash Pad Switch Front Console Switch Lane Keeping Assist Unit (Line) MODULE 5 7.5A ADAS-PARKING UNIT ADAS-DRIVING UNIT Smart Cruise Control Radar AWD ECM IBU 2 Ignition Switch Driver/Passenger DIGITAL Key Outside Handle SUNROOF 2 Panoramic Sunroof MODULE 1...
Page 638 Fuse Fuse Name Protected Component Rating A/V & Navigation Head Unit Electro Chromic Mirror Low DC-DC Converter (Audio/AMP) Front Wireless Charger Front/Rear A/C Control Module MODULE 6 7.5A Center Facia Keyboard 1ST Air Ventilation Seat Control Module 1ST Seat Warmer Control Module 2ND Air Ventilation Seat LH/RH Control Module 2ND Seat LH/RH Warmer Control Module WASHER...
Page 639 Maintenance Engine compartment fuse panel Information (Engine room junction block) Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
Page 640 Engine compartment fuse panel Fuse Fuse Name Protected Component Rating MDPS 100A MDPS Unit COOLING FAN 1 Cooling Fan Relay (600W) EPB 1 EPB Control Module ICU Junction Block ICU Junction Block MULTI FUSE-1 ICU Junction Block (IPS 2,8,9,10,11,13) Electronic Oil Pump Module Not Used TRAILER 1 Trailer Lamp...
Page 641 Maintenance Fuse Fuse Name Protected Component Rating PTC HEATER 2 PTC Heater Relay PTC HEATER 3 PTC Heater Relay TRAILER 5 Trailer Lamp FUEL PUMP Fuel Pump Relay AWD ECM HEATED NOZZLE Heated Nozzle Unit B/ALARM Burglar Alarm Horn Relay HORN ACC 3 2ND USB Charger...
Page 642 Fuse Fuse Name Protected Component Rating POWER 2ND POWER OUTLET#2 OUTLET 2 POWER 2ND POWER OUTLET#1 OUTLET 1 PCB Block (ACC FUSE - AMP, ETC) SENSOR 1 Fuel Pump Relay [L3.8 GDI] A/C Comp Relay, Variable Intake Solenoid Valve #1/#2, Oil Pump Solenoid Valve, Oxygen Sensor Down #1/#2, Oil SENSOR 2 Control Valve #1/#2(Intake/Exhaust),...
Page 643: Light Bulbs
Maintenance LIGHT BULBS Consult an authorized HYUNDAI dealer Information - Headlight to replace most vehicle light bulbs. It is desiccant (if equipped) difficult to replace vehicle light bulbs because other parts of the vehicle must This vehicle is equipped with desiccant to...
Page 644: Headlight, Position Lamp, Turn Signal Lamp, Daytime Running Light (Drl) Replacement
If the LED lamp does not operate, have assembly is reinstalled. the system inspected by an authorized HYUNDAI dealer. The LED lamps cannot be replaced as a single unit because it is an integrated unit. The LED lamps has to be replaced with the unit. A skilled...
Page 645: Side Repeater Lamp Replacement
If the LED lamp does not operate, have Tail lamp the system inspected by an authorized Tail/Stop lamp retailer of HYUNDAI dealer. Turn signal lamp The LED lamps cannot be replaced as Side marker a single unit because it is an integrated Reverse lamp, Reflex reflector unit.
Page 646 Tail lamp, stop lamp, turn signal lamp and garnish lamp (Type B) If the LED lamp does not operate, have the system checked by an authorized HYUNDAI dealer. B0474EU01 The LED lamps cannot replaced as a 1. Turn off the engine.
Page 647: High Mounted Stop Lamp Replacement
If the LED lamp does not operate, have the system inspected by an authorized 2. Using a flat-blade screwdriver, gently HYUNDAI dealer. pry the lens cover from the lamp housing. The LED lamps cannot be replaced as a single unit because it is an integrated 3.
Page 648: Interior Light Replacement
Interior Light Replacement 1. Using a flat-blade screwdriver, gently pry the lens from the interior lamp Map lamp, room lamp and luggage housing. compartment lamp (Bulb type) WARNING Prior to working on the Interior Lights, ensure that the “OFF” button is depressed to avoid burning your fingers or receiving an electric shock.
Page 649 C : Luggage compartment lamp If the LED lamp does not operate, have the system checked by an authorized HYUNDAI dealer. The LED lamps cannot be replaced as a single unit because it is an integrated unit. The LED lamps has to be replaced with the unit.
Page 650: Appearance Care
APPEARANCE CARE Exterior Care Insects, tar, tree sap, bird droppings, industrial pollution and similar deposits can damage your vehicle’s finish if not NOTICE removed immediately. If you park your vehicle near a stainless Even prompt washing with plain water steel sign or glass facade building, the may not completely remove all these vehicle’s exterior plastic parts such deposits.
Page 651 Maintenance NOTICE NOTICE Do not use strong soap, chemical Matte paint finish vehicle (if equipped) detergents or hot water, and do not Automatic car wash which uses rotating wash the vehicle in direct sunlight brushes should not be used as this can or when the body of the vehicle is damage the surface of your vehicle.
Page 652 This may your vehicle maintained and repaired result in damage to the protective by an authorized HYUNDAI dealer. Take coating and cause discoloration or extreme care, as it is difficult to restore paint deterioration.
Page 653 If these and construction practices to combat materials are not removed, accelerated corrosion, HYUNDAI produces vehicles rusting can occur on underbody parts of the highest quality. However, this is such as the fuel lines, frame, floor pan only part of the job.
Page 654 If you live in a high-corrosion area — Moisture breeds corrosion where road salts are used, near the Moisture creates the conditions in ocean, areas with industrial pollution, which corrosion is most likely to occur. acid rain, etc.—, you should take extra For example, corrosion is accelerated care to prevent corrosion.
Page 655: Interior Care
Maintenance Keep paint and trim in good condition Cleaning the upholstery and interior trim Scratches or chips in the finish should be covered with “touch-up” paint as Vehicle interior surfaces (if equipped) soon as possible to reduce the possibility Remove dust and loose dirt from interior of corrosion.
Page 656 Caring for the leather seats Leather (if equipped) Features of seat leather - Vacuum the seat periodically to remove dust and sand on the seat. It - Leather is made from the outer skin will prevent abrasion or damage of of an animal, which goes through a the leather and maintain its quality.
Page 657 Therefore, you should immediately have the damaged interior wooden trim replaced by an authorized HYUNDAI dealer. Cleaning the seat belt webbing Clean the belt webbing with any mild soap solution recommended for cleaning upholstery or carpet.
Page 658: Emission Control System
The vehicle inspected and maintained ORVR system is designed to allow the by an authorized HYUNDAI dealer in vapors from the fuel tank to be loaded accordance with the maintenance into a canister while refueling at the gas schedule in this manual.
Page 659 Maintenance 3. Exhaust Emission Control WARNING System CALIFORNIA PROPOSITION 65 The Exhaust Emission Control System is WARNING a highly effective system which controls Engine exhaust and a wide variety of exhaust emissions while maintaining automobile components and parts, good vehicle performance. including components found in the When the engine starts or fails to start, interior furnishings in a vehicle, contain...
Page 660 Have all inspections and do not coat the vehicle for corrosion adjustments made by an authorized control. It may present a fire risk HYUNDAI dealer. under certain conditions. Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, damaging the catalytic converter.
Page 661: California Perchlorate Notice
Maintenance CALIFORNIA PERCHLORATE NOTICE Perchlorate Material-special handling may apply, See: www.dtsc.ca.gov/ hazardouswaste/perchlorate. Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a). 9-74...

Hyundai Palisade 2023 Owner's Manual

Table of Contents

2. Vehicle Information, Consumer Information and Reporting Safety Defects

3. Seats & Safety System

4. Instrument Cluster

5. Convenience Features

6. Driving Your Vehicle

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Hyundai Palisade 2023

Summary of Contents for Hyundai Palisade 2023
