Conventions

1 Conventions
provides the definition of some conventions used in the present document.
Table 1
Jumper JPx ON
Jumper JPx OFF
Solder bridge SBx ON
Solder bridge SBx OFF
6/35

Table 1. ON/OFF conventions

Convention
Jumper fitted
Jumper not fitted
SBx connections closed by solder
SBx connections left open
DocID027213 Rev 1
Definition
