Intended use
Use and operation solely with the following machines
3
Intended use
Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations and stand-
ards applicable for use in industry and trade. It may only be used for the welding proce-
dures indicated at the rating plate. Hazards may arise for persons, animals and material
objects if the equipment is not used correctly. No liability is accepted for any damages
arising from improper usage!
•
The equipment must only be used in line with its designated purpose and by trained or
expert personnel!
•
Do not improperly modify or convert the equipment!
3.1
Use and operation solely with the following machines
The following system components can be combined:
This description may be applied only to machines with the RC XQ Expert 2.0 Rob machine control.
Machine control
Description
3.2
Software version
These instructions apply to the following software version:
2.1.0.0
The machine control software version is shown on the screen during the start
process > see 4.3.4 chapter.
3.3
Applications
Device control of multi-process welding machines for arc welding covering the following welding proce-
dures:
Machine series
Titan XQR AC
Titan XQR
3.4
Documents which also apply
•
Operating instructions for the connected welding machines
•
Documents of the optional expansions
12
RC XQ Expert 2.0 Rob RC XQ Expert 2.0 Rob LG RC XQ Expert 2.0 Rob WLG
No network connection
Main procedure for MIG/MAG welding
Standard arc
WARNING
Version with LAN
Pulsed arc
Version with WiFi and LAN
099-00L104-EW501
17.01.2022
