Rectifying faults
Warnings
Warning
8 Welding circuit
9 WF configuration
10 Partial inverter
11 Excess temperature of the coo-
lant
[1]
12 Welding monitoring
13 Contact error
14 Alignment error
15 Mains fuse
16 Shielding gas warning
17 Plasma gas warning
18 Forming gas warning
19 Gas warning 4
20 Coolant temperature warning
21 Excess temperature 2
22 Excess temperature 3
23 Excess temperature 4
24 Coolant flow warning
25 Flow 2
26 Flow 3
27 Flow 4
28 Wire stock warning
29 Low wire 2
30 Low wire 3
31 Low wire 4
32 Tacho error
33 Excess current on the wire feed
motor
34 JOB unknown
35 Excess current on the wire feed
motor slave
36 Slave tacho error
37 FAST bus failure
56
Possible cause / remedy
The inductance of the welding circuit is too high for the selected
welding task.
Check WF configuration.
One of several partial inverters is not supplying welding current.
Check temperature and switching thresholds.
The actual value of a welding parameter is outside the specified
tolerance field.
The resistance in the welding circuit is too high. Check earth
connection.
Switch the machine off and on. If the error persists, notify Ser-
vice.
The power limit of the mains fuse is reached and the welding
power is reduced. Check the fuse setting.
Check the gas supply.
Check the gas supply.
Check the gas supply.
reserved
Check coolant level and top up if necessary.
reserved
reserved
reserved
Check coolant supply.
Check coolant level and top up if necessary.
Check flow and switching thresholds.
reserved
reserved
reserved
Check wire feeding.
reserved
reserved
reserved
Fault of wire feeder - permanent overload of the wire drive.
Excess current detected on wire feed motor.
JOB Selection was not carried out because the JOB number is
unknown.
Excess current detected on wire feed motor slave (push/push
system or intermediate drive).
Fault of wire feeder - permanent overload of the wire drive
(push/push system or intermediate drive).
Wire feeder not connected (reset by actuating the automatic cir-
cuit-breaker of the wire feed motor).
[2]
[2]
