5.4.5

Operating panel settings

Menu item / parameter
Type of main screen
Automatic selection of welding power
Display brightness:
Display contrast:
Display negative:
Non-latched selectable
Special non-latched selectable
Spot welding selectable
Special latched selectable
P0 of RC XQ Expert 2.0 Rob can be
changed:
Average value display for superPuls:
Hold function:
Language
Measuring units
Numbering files consecutively
RC XQ Expert 2.0 Rob Reset to factory
settings
Operation using the interface for auto-
mated welding
099-00L104-EW501
17.01.2022
Operating the machine control
Value Comment
1-2
Off–30 s
0-100 %
0-100 %
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
Yes When superPuls is enabled, the welding power
is displayed as an average value.
No The welding power is displayed by program A
even when superPuls is enabled.
On
Off
German
Metric
Imperial
No
Yes
Yes Only parameters that relate to
RC XQ Expert 2.0 Rob are reset (e.g. display
settings, language and texts). System parame-
ters such as Xbutton activation or JOBs are
not affected.
No
No
Yes The mode of operation and welding is imple-
mented using RC XQ Expert 2.0 Rob (robot in-
terface not available).
Machine configuration (system)
