Excelon XD/XQ Operator's Manual
92

6.3 Adjustment

• Menu Bar  Option  Adjustment
There are several kinds of adjustment for the edger including Size Adjustment,
Margin Adjustment, Axis Adjustment and etc.
• Adjustment values are closely related to the processing quality, so keep the fact
ory default values.
• Before changing these values, ask advice of the service technician of Huvitz or
the technician authorized by Huvitz.

6.3.1 Size Adjustment

Size Adjustment values are closely related to the size of the edged lens. These
values are used to compensate lens size when the tolerance of the edged lens size
was too big because of worn out of the edging wheel.
• Test Pattern
- Use the internal Square(40mm x 40mm) and Circle(Ø 50).
• Test Cases
- Use all kinds of materials such as Plastic, PC, HI-Index, Glass, Trivex® .
- Execute the beveled process and the rimless process for all above kinds of
material.
- Check the adjustment amount for roughing and polishing respectively.
• Adjustment
- Change the value within the tolerance
- Remember that the adjusted values are applied in radius.
!
CAUTION
± 0.1mm.
±
