- Page 1 Installation & Operator’s Manual PN 71-1000...
-
Page 2: Safety Warnings
SAFETY WARNINGS PINCH HAZARD ALWAYS USE WINCH ALWAYS WEAR GLOVES DO NOT USE WINCH TO READ INSTRUCTIONS KEEP FINGERS AWAY STRAP TRANSPORT PEOPLE Take time to fully read the manual in order to understand your tool and its operation. Always wear gloves, eye and ear protection, and suitable clothes, cover any long hair. Always fully inspect the tool and accessories before use. - Page 3 SAFETY WARNINGS Never apply load to hook tip or latch. Apply load only to the center of hook. Never use a hook whose throat opening has increased, or whose tip is bent or twisted. Never attempt to tow a vehicle or object with the recovery strap attached directly to the portable winch hook. Never use bungee straps that develop tremendous and potentially dangerous amounts of force when stretched.
- Page 4 INSTRUCTIONS 1 Variable Speed Switch 5 Charging Dock/Remote port 2 Direction Switch 6 Display Screen 3 Power Switch 7 Stopping Plate 8 Rope 4 Swiveling Anchor Hook NOTE: Refer to the actual product Portable winch and accessories ITEM NUMBER ITEM DESCRIPTION QUANTITY ITEM NUMBER ITEM DESCRIPTION QUANTITY...
- Page 5 INSTRUCTIONS Malfunction or Protection Winding Out Winding In Battery Power Display 1. Display of battery power: three grids are green. When the battery power displays only one grid, please charge it soon. 2. Pulling out rope and winding back rope status indicator are displayed in the code #'s. 3.
-
Page 6: Battery Installation
BATTERY INSTALLATION Battery installation and unloading • During the installation, please confirm that the power switch is at “OFF /O” position. Battery release button must be at the top, align the contact point of the battery against the" corresponding contact point on the battery slot, slide the battery in, and gently press until the battery is locked in place. -
Page 7: Protection Functions
CHARGER You need to use the original charger to charge the battery. After the battery is loaded into the portable winch, insert the power cord of the charger into power outlet, and then insert the plug of the charger into the charging port of the portable winch: •... -
Page 8: Wired Remote Control
CHARGER WARNING • Make sure the winch is turned off when charging, this could avoid damaging the winch and battery. • Never use portable winch while charging. • When the battery temperature is higher than 70 °C (158 °F) or below -20 °C (-4 °F), the battery will stop discharge in order to protect the battery, you need to wait for the battery to cool down to room temperature before using the product again. -
Page 9: Wireless Remote Control
REMOTE CONTROL Wireless remote control To start, press and hold ON/OFF button for 2-3 seconds. The red LED will rapidly flash indicating that the portable winch is in operation. To stop, press the ON/OFF button for 3 seconds. Or it will be stopped automatically in 3 minutes if there has been no winching activity. -
Page 10: Operation
OPERATION Before using this winch to lift or pull a load, you should familiarize with your winch. It is important to know how it works. This winch is a portable tool for lifting and pulling. This powerful tool has a power switch, a directional switch and a speed controller. - Page 11 OPERATION Take some time and practice using it before pull or lift a load, that way you will be familiar with all the operations. The following steps describe how to use the tool with single rope. A snatch block can improve the pulling capacity. 1.
- Page 12 OPERATION 9. Plan to pull or lift. Ensure all the connections are 12. Rewind rope. Press the directional secured. Line up your pulling direction as straight as switch to “ ”, then press and hold the speed possible. Side pulls can cause the rope to bunch at controller to slowly wind in the rope.
-
Page 13: Troubleshooting
TROUBLE SHOOTING NUMBER PROBLEM SOLUTIONS The product failure light (red light) This indicates the load reaches more than 80% of the rated lights up and flashes. load, which needs attention. The product stop working, and the Stop using pulling tool until the motor cools to room temperature is too high. -
Page 14: Specifications
SPECIFICATIONS SPECIFICATIONS Rated Line Pull 1000 lbs. (454 kgs) Battery Power Supply 24V DC Rope 5 mm X 12 m Battery Lithium Battery Battery Capacity 2.5AH Battery Charger Input 100-240V AC 50-60 Hz 75 W Battery Charger Output 30 V = 2000 mA Dimensions 24”... - Page 15 PARTS BREAKDOWN & ASSEMBLY ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 71-1000-1 Machine cover 1 71-1000-23 Motor assembly 71-1000-2 Screw M6 71-1000-24 Machine cover 2 71-1000-3 Gear box cover Screw 3.5 X 18 71-1000-25 71-1000-4 Gear box 2 71-1000-26 5 pin socket assembly 71-1000-5 Gear box 1...
-
Page 16: Warranty
Warranty registration must be submitted at MileMarker.com/warranty within 30 days of purchase by the end user. If you discover a hidden defect, Mile Marker will, as its option, repair or replace the product or necessary replacement parts at no charge to you, provided you remove the product from the vehicle and return it prepaid to Mile Marker Industries.
