Performance Check-PM 101
Item (w/ Tek. Number)
Logic Analyzer (7002) w/Opt. 3
(Expansion)
Oscilloscope mainframe (7603,
7704A, or other appropriate
mainframe)
Oscilloscope, 200 MHz bandwidth,
dual-trace, calibrated 1 ns/div
resolution
P6106 Passive probe 250 MHz,
10X, 10 MO
(Tektronix Part No.
010-6106-03)
Pulse Generator (PG 502)
Pulse Generator (PG 508)
Test Equipment Mainframe
(TM 504)
n
Coaxial cable, 50
Bnc male to dual binding post
adapter (Tektronix Part No.
103-0035-00)
n
50 Feedthrough termination
(Tektronix Part No.
011-0049-01)
Test lead, black
(Tektronix Part No.
012-0426-01)
Test lead, red
(Tektronix Part No.
012-0426-00)
Connecting the Self-Test Stimulus
a. Turn off power to the Logic Analyzer at the os­
cilloscope mainframe.
b. Remove the plastic cover on the back of the
Personality Module using a small screwdriver or Allen
wrench.
5-2
TABLE 5-1

TEST EQUIPMENT REQUIRED

Familiar Name
7002
Mainframe
Test oscilloscope
Oscilloscope probe
PG 502
PG 508
TM 504
Coax cable
Bnc to Binding Post Adapter
n
50 Termination
Black test lead
Red test lead
c. Move the strapping connector from the power-off
position to the power-on position as shown in Fig. 5-2.
d. Connect the Data, Address, Control and Clock
leads on the PM 101 to the Self-Test Stimulus pins, a s
indicated in Table 5-2 and shown in Fig. 5-3.
Purpose
To provide a system for the PM 101
to be a part of.
To provide the facilities necessary
to operate the 7002.
Examination of pulse generator
signals.
Oscilloscope input
(2 required)
To provide clock pulses to the
PM 101.
To provide data pulses to the
PM 101 and triggering for
the PG 502.
To provide facilities necessary to
operate the above two items.
Signal connection.
To make test fixtures
(2 required)
Signal termination
Signal connection
Signal connection.
